- Page 1 1HP Dust Collector Model: 60-100 Record the serial number and date of purchase in your manual for future reference. Serial number: Date of purchase: For more information: www.rikontools.com info@rikontools.com For Parts or Questions: techsupport@rikontools.com or 877-884-5167 Part # 60-100M2...
-
Page 2: Safety Warnings
Operator Safety: Required Reading IMPORTANT! Safety is the single most important consideration in the operation of this equipment. The following instructions must be followed at all times. There are certain applications for which this tool was designed. We strongly recommend that this tool not be modified and/or used for any other application other than that for which it was designed. -
Page 3: Dust Collector Safety Rules
ALWAYS DISCONNECT TOOLS. Disconnect tools before servicing and when changing accessories such as blades, bits, and cutters. ALWAYS AVOID ACCIDENTAL STARTING. Make sure switch is in “OFF” position before plugging in cord. NEVER LEAVE TOOLS RUNNING UNATTENDED. ALWAYS CHECK FOR DAMAGED PARTS. Before initial or continual use of the tool, a guard or other part that is damaged should be checked to assure that it will operate properly and perform its intended function. -
Page 4: Table Of Contents
Table of Contents Safety Warnings.............................2-3 Dust Collector Safety Rules ........................3 Specifications ............................4 Contents of Package ............................5 Assembly ...........................6-8 Operation......................9 Dust Hazards and Safety......................9 Electrical Requirements ..........................10 Trouble Shooting...............................11 Wiring Diagram............................11 Parts List .............................12 Parts Explosion............................13 Warranty .............................14 Notes............................15 Specifications... -
Page 5: Contents Of Package
Contents of Package When unpacking, check to make sure the following parts are included. If any parts are missing or broken, please call RIKON Power Tools at the number on the cover of this manual as soon as possible. Upper bag support... -
Page 6: Assembly
Assembly Installing Casters to Base Locate the four swivel casters, four M5 hex nuts, four 5MM flat washers and four M5X8MM hex head screws from the hardware pack. M5 Nut 1. Turn over the base plate and align the holes on 5MM Washer base plate with the holes from swivel caster. - Page 7 Installing the Vertical Supports Vertical Locate the two vertical support bars, two M8X10MM supports hex bolts and two 8MM washers. 1. Hold the vertical support bar upright over the hole located at the corner of the base as shown. 2. Place a washer onto a hex bolt and insert into the bottom hole of the verticle support and into the threaded hole in the base (Fig.
-
Page 8: Assembly
Assembly Continued Threading Band Straps in Filter Bags 1.) Unfold both bags and lay on a flat surface. 2.) Locate the slit on the right side of the top lip of each bag. 3.) Start the slotted catch end of the band strap through the right slit (Fig. -
Page 9: Operation
Operation On/Off Locking Switch Caution: Make sure that the On/Off locking switch is in the “Off” position before plugging the dust collector into a power source. The On/Off Locking Switch has a center key that can be used to prevent unauthorized use of the dust collector. -
Page 10: Electrical Requirements
Electrical Requirements In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into a matching outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 11: Troubleshooting
Troubleshooting Wiring Diagram... -
Page 12: Parts List
Parts List Part No. Description Part No. Description Base plate Flat washer Column Hex socket head screw Flat washer Housing cover Pan head screw Upper bag support Switch Filter bag Motor Handle Hex bolt Hex nut Spacer Rubber gasket Vertical support Dust bag Hex bolt Hex nut... -
Page 13: Parts Explosion
Parts Explosion... -
Page 14: Warranty
Warranty 2-Year Limited Warranty RIKON Power Tools Inc. (“Seller”) warrants to only the original retail consumer/purchaser of our products that each product be free from defects in materials and workmanship for a period of two (2) years from the date the product was purchased at retail. This warranty may not be transferred. -
Page 15: Notes
