Page 1: Color Monitor
Color Monitor English User's Guide... - Page 3 Lenovo may make improvements and/or changes in the product(s) and/or program(s) at any time. It is possible that this publication may contain reference to, or information about, Lenovo products (machines and programs), programming, or services that are not announced in your country.
-
Page 4: Notices And Trademarks
Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. - Page 5 Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in the United States, other countries, of both. Other company, product, and service names may be trademarks or service marks of other. © Copyright Lenovo 2005; portion (c) IBM Corp. 2004. All rights reserved.
-
Page 6: Help And Service Information
Call CUSTOMER SUPPORT CENTER In the US call 1-800-426-7378 In Canada(Toronto Only) call 416-383-3344 In Canada(all other) call 1-800-565-3344 In other countries contact your dealer, retailer, or other Lenovo authorized If possible, stay by your Servicer. computer. Your Technical Support Representative may... -
Page 7: Table Of Contents
Table of Contents Precautions..................A2 Workplace Preparation ..............A2 Working Practices .................A2 Monitor Driver Installation............A4 Driver installation for Windows 95 or Windows 98 ......A4 Driver installation for Windows 2000 or Windows Me ....A5 Driver installation for Windows XP ..........A6 Control Panel Function..............A7 Front Panel Controls..............A7 On Screen Display (OSD) Control Adjustment......A8 On Screen Display (OSD) Selection and Adjustment....A9... -
Page 8: Precautions
Precautions Workplace Preparation Positioning the Monitor Choose a suitable place to position the monitor where it is not near fluorescent desk lighting or any equipment that produces magnetic fields that could cause interference. Ensure that the furniture or equipment can support the weight of the monitor. - Page 9 Precautions Screen settings Set the screen brightness and contrast to a comfortable level. You may have to adjust this as the lighting changes during the day. Many application programs let you select color combinations which can help you to view in comfort. Power Cord For safe operation, use the power cord supplied with the unit.
-
Page 10: Monitor Driver Installation
Click OK. Ensure that the CD drive letter is selected. Choose E50 monitor and Click OK. The files will be copied from the CD to your hard disk drive. Close all open windows and remove the CD. Restart the system. -
Page 11: Driver Installation For Windows 2000 Or Windows Me
Click OK. Ensure that the CD drive letter is selected. Choose E50 monitor and Click OK. The files will be copied from the CD to your hard disk drive. Close all open windows and remove the CD. Restart the system. -
Page 12: Driver Installation For Windows Xp
Click OK. Ensure that the CD drive letter is selected. Choose E50 monitor and Click OK. The files will be copied from the CD to your hard disk drive. Close all open windows and remove the CD. Restart the system. -
Page 13: Control Panel Function
Control Panel Functions Front Panel Controls SELECT MENU Control Function Power Button Use this button to turn the monitor on or off. This Indicator lights up green when the monitor Power Indicator operates normally. If the monitor is in power saving mode, this indicator color changes to flicking. -
Page 14: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment NOTE Allow the monitor to stabilize for at least 30 minutes before making image adjustments. To make adjustments in the On Screen Display, follow these steps: Press the MENU Button, then the main menu of the OSD appears. To access a control, use the Buttons. -
Page 15: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Icon Main menu Icon Main menu Contrast H Moire Brightness V Moire H Position COLOR 9300 H Size 6500 V Position V Size R G B Pincushion... - Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. 1 0 2 4 X 7 6 8 / 7 5 H z Icon Sub menu...
- Page 17 On Screen Display(OSD) Selection and Adjustment Icon Sub menu Description To correct an irregular distortion of the displayed image. BOTTOM CORNER This item allows you to reduce the degree of moire. (Moire is caused by interference Horizontal Scan H MOIRE Line with the periodical dot screen).
- Page 18 On Screen Display(OSD) Selection and Adjustment Icon Sub menu Description • OK Return to all factory default settings except "LANGUAGE": • CANCEL Brightness, Contrast, Color 9300, Video Level, OSD Time, Moire (These reset options may differ depending on the RESET mode selected: Preset, User, or New).
-
Page 19: Troubleshooting
Troubleshooting No image appears ❐ Is the power cord of the • Check and see if the power cord is connected properly to monitor connected? the power outlet. ❐ Is the power indicator light • Press the Power button. ❐ Is the power on and the •... - Page 20 Brighten the screen and use the ' M OIRE' icon on the screen adjustment menu to adjust the screen. Have you installed the monitor driver? ❐ Have you installed the • Be sure to install the monitor driver from the Lenovo Monitor CD that comes with your monitor. monitor driver?
-
Page 21: Specifications
Specifications Picture Tube 15 inches (13.7 inches viewable) 90 degree deflection 0.28mm diagonal, 0.25mm horizontal dot pitch AGAS(Anti-Glare Anti-Static) coating Horizontal Freq. 30 - 54kHz (Automatic) Sync Input Vertical Freq. 50 - 120Hz (Automatic) Input Form Separate TTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input Input Form... -
Page 22: Preset Modes (Resolution)
46.88 VESA 800 x 600 VESA 53.68 800 x 600 Service Information The following parts are for use by Lenovo services, or Lenovo authorize dealers, to support customer warranty. Parts are for service use only. DESCRIPTION MODEL COLOR MACHINE PART...
