- Page 1 Electronic Service Manuals This electronic document is provided as a service to our customers. We do not create the contents of the information contained in this docu- ment. Should you have detailed questions pertaining to the information contained in this document, you may contact Michco, or the manufac- turer which provided the original information in this electronic deliver- able.
- Page 2 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 3: Table Of Contents
This Owner's Manual/Safety Procedures Guide has been prepared for the promotion of educational purposes only and Clarke does not claim or assume any responsibility for the operator's actions or safety. To be completely aware of what local authorities may require, contact the Fire Marshal of your community. -
Page 4: Engine Emissions And Co Safety
ALTO U.S. is dedicated to our customers, their safety, and providing information, services, and products that meet those needs. Information provided in this document is current as of the date written November 1997. ® Propane Burnishers Operator's Manual Page 3 Clarke... - Page 5 Nitrous Oxide (NOx) from the engine exhaust providing the lowest possible emissions, high cubic feet per minute (CFM) fans (forced air mixing), and digital combustion analyzers for tail pipe emissions monitoring. Page 4 Clarke ® Propane Burnishers Operator's Manual...
- Page 6 0.1% (1000ppm) in inspired air the blood will contain 50 to 80% carboxyhemoglobin which results in coma, convulsions, respiratory failure and death. On inhalation of high concentrations of CO, saturation of the blood proceeds so rapidly that unconsciousness may occur suddenly without warning. ® Propane Burnishers Operator's Manual Page 5 Clarke...
- Page 7 (less floor space for the same time). As shown in Model 1, the CO concentrations rise much quicker as the “Effective Operating Zone” is a very small area compared to the total building size. Page 6 Clarke ® Propane Burnishers Operator's Manual...
- Page 8 Note the “Dividing Zone” shown above, this is the line where airflow changes direction. In Model 4, air changes are full as forced air mixing has moved and mixed the CO between all air zones. ® Propane Burnishers Operator's Manual Page 7 Clarke...
- Page 9 1 c h a n g e s /h r 2 0 0 2 c h a n g e s /h r 1 5 0 1 0 0 T im e (h o u r s ) Page 8 Clarke ® Propane Burnishers Operator's Manual...
- Page 10 T i m e ( h o u r s ) The Graph above depicts the relationships of air exchange to time and CO ppm with cubic feet area and percent CO emissions remaining constant. ® Propane Burnishers Operator's Manual Page 9 Clarke...
- Page 11 Maintenance And Adjustments schedule found in the Propane Floor Equipment Operator’s Manual that were supplied with the equipment. Additional manuals may be obtained by contacting Clarke at 1-800-545-3454 or write to Clarke Customer Service, 2100 Hwy. 265, Springdale AR 72764.
-
Page 12: Operator Safety Instructions
Failure to read the Owner's Manual prior to operating or attempting any service or mainte- nance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it. -
Page 13: Introduction
In addition, overfilling allows liquid propane to Clarke propane floor care equipment is manufactured in enter the fuel control system, possibly ruining two basic concepts: the buffer/burnisher and the floor the lockoff/regulator assembly. This voids the stripper. Both of these designs are truly PORTABLE warranty on affected parts of the machine. -
Page 14: Propane Safety Information
VOID the WARRANTY on these components. will cause the moisture vapor to chill and remain in the cylinder. LPgas liquid also expands 270 times to vapor making the purge process ineffective. Use LP- gas vapor only! ® Propane Burnishers Operator's Manual Page 13 Clarke... -
Page 15: How To Operate The Machine
REMEMBER, when you are finished with the machine, store Eccentricity of the pad should not exceed 1/4 of an inch. the propane tank outside the building, in a safe place away from heat or direct sunlight. Page 14 Clarke ® Propane Burnishers Operator's Manual... -
Page 16: Trouble Shooting
Place the buffer on its side (with the muffler down) and reset by taking up the slack in the belt and tighten the Lovejoy Tensioner. ® Propane Burnishers Operator's Manual Page 15 Clarke... - Page 17 Remove the sparkplug lead from the DOES NOT, contact our customer service department sparkplug and replace the boot with a new one. The for further assistance. engine should now run normally. IF IT DOES NOT NOTES Page 16 Clarke ® Propane Burnishers Operator's Manual...
-
Page 18: Section Ii - Parts Manual
Propane Floor Burnisher Equipment Section II Parts Manual (70076A) Clarke ® Propane Burnishers Operator's Manual Page 17... -
Page 19: Frame Assembly
® Clarke 21", 24" and 27" Frame Assemby 2/07 Page 18 Clarke ® Propane Burnishers Operator's Manual... - Page 20 85834A Bolt , -16 x 2.5 Hx Hd. 170883 Lock Washer, 170863 Washer, Flat 61486A Tension, Rotary 70468A Label, Clarke 61485A Spacer 77336A Label, Danger 98436A Bumper Strip 6 ft. 10633A Wheel Bracket Kit (incl. 19a,19b,19c) 99074A Bracket, Wheel 19B 98447A Bolts, Flat Head, -18 x 1.50...
-
Page 21: Handle Assembly 8/00
Clarke ® Handle Assembly 8/00 Fig. 1 Fig. 2 Centrifugal Clutch Electric Clutch (UL listed Machine) (UL listed machines) Fig. 3 Fig. 4 Single Cylinder Non-Clutch V-Twin Non-Clutch Page 20 Clarke ® Propane Burnishers Operator's Manual... - Page 22 Clarke ® Handle Assembly 8/00 Ref # Part No. Description 50024A Cable, U.L. Throttles KAW. Twins (W710) 52960A Cable, Throttle KAW. Single 98487A Screw, #8 x 0.75 98618A Lever, Bar, U.L. (W40U) 52041A Plug, ½ Button 98622A Grip Tube, Handle (W431)
-
Page 23: Engine Assembly (Kawasaki Fh 500 V "V" Twin)
® Clarke Engine Assembly 1/07 KAWASAKI FH451V, FH500V and FH541V "V" Twin Page 22 Clarke ® Propane Burnishers Operator's Manual... - Page 24 ® Clarke Engine Assembly 1/07 KAWASAKI FH451V, FH500V and FH541V "V" Twin Ref # Part No. Description 50028A Bonnet KAWASAKI 60047A Bonnet Cage 920110 Nut, Lock, 170860 Washer, Flat, 98978A Velcro Stud 52553A Cable Clamp 47436A Oil Switch 852841 Elbow St.
-
Page 25: Engine Assembly (Kawasaki Fh 381 V "V" Twin)
® Clarke 13 HP Engine Assembly 9/04 KAWASAKI FH 381V "V" Twin Page 24 Clarke ® Propane Burnishers Operator's Manual... - Page 26 ® Clarke 13 HP Engine Assembly 9/04 KAWASAKI FH 381V "V" Twin Ref # Part No. Description 53388A Bonnet KAWASAKI 52553A Cable Clamp 50360A Adaptor 852841 Elbow St. 47436A Oil Switch 10805A Carburator FH381V 80074A Washer, Wave, 60003A Spud 50027A...
-
Page 27: Volt Fuel System
® Clarke 12 Volt Fuel System 8/01 14 23 5 12 NOER notenoter Ref. Part # Description Qty. Ref. Part # Description Qty. 40004A 14 HP Wiring Harness 60006A Switch Cover 40000A 17 HP Wiring Harness 50299A Hose, 3/8" LP... -
Page 28: Vacuum Fuel System 7/03
® Clarke Vacuum Fuel System 7/03 (A, B, & C) Ref. Part # Description Qty. Ref. Part # Description Qty. Page 11 Carrier, Bottle (Ref) 98472A Screw, Button, ¼-20 x 0.62 98421A (MAC815) Tank, Aluminum, Polished 980657 (H040) Washer, Lock, ¼... -
Page 29: Bearing Assembly 21", 24", 27
Clarke ® Bearing Assembly Burnisher 2/00 w/o Jet Stream vvvvvv NOTE: 10643A Kit, Bearing (4A,5,6,7) assembled 10644A Kit, Bearing Jet-Stream (4B,5,6, & 7) assembled 10683A Kit, Bearing, Onan 27" (4c, 5, 6 &7) 10130A Kit, Bearing, 1.5 Deg. (4a, 5a, 6 & 7) Ref # Part No. -
Page 30: Pad Driver Assembly 11/05
® Clarke Pad Driver Assembly 11/05 (A,B,C) 9 (A, B, C) Flex Pad Driver Steel Pad Driver Ref # Part No. Description Qty. 920110 Nut, Lock, 5/16 -18 x x x 170860 Washer, Flat 5/16 x x x Burnishing Pads... -
Page 31: Belt Selection Chart
21 w/Clutch 21 w/Battery 21 Strip 21" Combo 22 Standard 22 w/Clutch 22 Strip 24 Standard 24 w/Clutch 24 w/Battery 24 Strip 27 Standard 27 w/Battery 28 Strip Strip/Buff 24 Onan 27 Onan Page 30 Clarke ® Propane Burnishers Operator's Manual... -
Page 32: Pulley Chart 7/03
® Clarke Pulley Chart 7/03 Engine Shaft Part # Description Where Used 98579A 3.5 x 1 Pulley (W11) All Burnishers w/o clutch 98583A Electric Clutch (W14) All Burnishers w/electric clutch 98585A Centrifugal Clutch (W142) (2250) All Burnishers w/centrifugal clutch (except Onan) -
Page 33: Electrical Schematic 120V A.c. System 2/00
® Clarke Electrical Schematic 120V A.C. System 2/00 Page 32 Clarke ® Propane Burnishers Operator's Manual... -
Page 34: Electrical Schematic 14 Hp Single 12Vdc
® Clarke KAWASAKI 14 HP Single Electrical Schematic 12V D.C. System 5/99 ® Propane Burnishers Operator's Manual Page 33 Clarke... -
Page 35: Electrical Schematic 14 Hp Single 12Vdc Envirogard Iii
® Clarke KAWASAKI 14 HP Single Electrical Schematic Enivorgard III 12V D.C. System 5/99... -
Page 36: Electrical Schematic 17 Hp Twin 12Vdc
® Clarke Electrical Schematic KAWASAKI 17 HP TWIN 12 V. DC Fuel System 5/99 Page 35 Clarke ® Propane Burnishers Operator's Manual... -
Page 37: Electrical Schematic 17 Hp Twin Envirogard
® Clarke KAWASAKI 17 HP TWIN Envirogard IV 12 Vdc System Electrical Schematic 8/01 ® Clarke Propane Burnishers Operator's Manual Page 36... -
Page 38: Onan 12V Dc Electrical Shcematic
® Clarke Onan P248 LP Engine 12V DC Fuel System Electrical Schematic 6/98 Page 37 Clarke ® Propane Burnishers Operator's Manual... - Page 39 NOTES Page 38 Clarke ® Propane Burnishers Operator's Manual...
- Page 40 +49 0180 5 37 37 37 29815 John R. (810) 544-6300 ALTO Cleaning Systems (UK) Ltd., Penrith Gilwilly Industrial Estate ® American Lincoln / Clarke, Marietta, Georgia 30066 Penrith 1455 Canton Road Cumbria CA11 9BN (770) 973-5225 +44 1768 868 995 ALTO France S.A. Strasbourg SALES AND DISTRIBUTION CENTER B.P.
- Page 41 BATTERY WARRANTY The battery will be warranted by Clarke for a period of 6 months from the machine date of purchase. The defective battery must be returned to Clarke. Returned batteries that are only in need of recharging will not be warranted.
