Operator's Manual
Manual del Operador
Manuel de l'operateur
MODELS: 04147R, 04148R, 04156R, 04157R, 04157RHD
READ THIS BOOK
LEA ESTE MANUAL
LISEZ CE MANUEL
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your Clarke machine
could result in injury to you or to other personnel; damage to the machine or to other property could occur
as well. You must have training in the operation of this machine before using it. If your operator(s) cannot
read English, have this manual explained fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
Form No. 70416A 10/08 revised 10/10
BEXT
BEXT
BEXT
BEXT
BEXT
150H, 300HV
150H, 300HV
150H, 300HV
150H, 300HV
150H, 300HV
Extractor's
Extractor's
Extractor's
Extractor's
Extractor's
EN
English
ES
Español
FR
Français
Clarke
®
® ® ® ® ®
-100, 100H,
-100, 100H,
-100, 100H,
-100, 100H,
-100, 100H,
120V
120V
120V
120V
120V
Advertisement
Table of Contents
Related Manuals for Clarke 04147R
Summary of Contents for Clarke 04147R
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
It is the purchaser’s responsibility to know the content of, and to comply with, any laws and regulations relating to the use of these Products in such environments. The Manufacturer disclaims any responsibility to advise purchasers of any specific requirements that may be applicable to the use of the Products in such environments. Clarke ® ®... -
Page 3: Bext ® -100, 100H 150H, 300Hv Operator's Manual Form No. 70416A
Diagrama Esquemático Eléctrico BEXT 100 120V ........... 45 Diagrama Esquemático Eléctrico BEXT 100H 120V ..........46 Diagrama Esquemático Eléctrico BEXT 150H 120V ..........47 Diagrama Esquemático Eléctrico BEXT 300HV 120V ..........48 Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 3... - Page 4 Schéma des circuits électriques BEXT 100 120V ............ 45 Schéma des circuits électriques BEXT 100H 120V ..........46 Schéma des circuits électriques BEXT 150H 120V ..........47 Schéma des circuits électriques BEXT 300HV 120V ..........48 Clarke ® ® 4 - FORM NO. 70416A...
-
Page 5: Operator Safety Instructions
Keep all fasteners tight. Keep the adjustments according to specifications. WARNING: Make sure that all the labels, decals, warnings, cautions and instructions are fastened to the machine. Replace them when necessary by ordering them from Clarke. WARNING: Do not use water that is hotter than 120 °... -
Page 6: Introduction And Machine Specifications
SPECIFICATIONS Bext 100 Bext 100H Bext 150H Bext 300H Part Number 04156R 04157R / 04157RHD 04147R 04148R Solution Tank 9 gallon rotationally molded 13 gallon rotationally molded Solutin Pump 100 psi demand pump 150 psi demand pump 300 psi demand pump Vacuum Motor 5.7", 3 stage... -
Page 7: Instrucciones De Seguridad Para El Operador
ADVERTENCIA: Compruebe que todas las etiquetas, calcomanías, advertencias, precauciones e instrucciones estén bien aseguradas a la máquina. Reemplácelas cuando sea necesario para lo cual debe solicitarlas a Clarke Technology. ADVERTENCIA: No utilice agua cuya temperatura supere los 120º F (40º C). -
Page 8: Introducción Y Especificaciones Técnicas De La Máquina
Bext 100 Bext 100H Bext 150H Bext 300H Número de pieza 04156R 04157R / 04157RHD 04147R 04148R Depósito de solución 9 galones - moldeado racionalmente 13 galones - moldeado racionalmente Bomba para la solución 100 psi bomba de demanda 150 psi bomba de demanda 300 psi bomba de demanda Motor de aspiración... - Page 9 Gardez toutes les fixations biens resserrées. Maintenez les ajustages conformément aux spécifications. AVERTISSEMENT: Assurez-vous que toutes les étiquettes, décalcomanies, avertissements, indications et instruc- tions sont bien fixés à la machine. Remplacez-les lorsque nécessaire en les commandant à Clarke Technology. AVERTISSEMENT: N'utilisez pas de l'eau d'une température supérieure à 40°C.
- Page 10 Bext 100H Bext 150H Bext 300H Numéro de pièce 04156R 04157R / 04157RHD 04147R 04148R Réservoir de la solution 40 l moulé par rotation 59 l moulé par rotation Pompe de la solution Pompe à la demande de 100 psi Pompe à...
- Page 11 N O T E S Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 11...
-
Page 12: Controls And Machine Features
The Machine Power Cord (Red "H") See Figure 1I This cord powers all machine functions except the heater. Figure 2 The Heater Power Cord See Figure 1J This cord powers heater only. Clarke ® ® 12 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 13: Controles Y Características De La Máquina
El cable de alimentación del calentador. Voir Figure 1J. Ce câble alimente l'appareil de chauffage Vea la Figura 1J. Este cable alimenta sólo el calentador. uniquement. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 13... -
Page 14: How To Prepare The Machine For Operation
Try other outlets until the light comes on. CAUTION: If both cords are plugged into the same circuit breaker, the breaker may blow when operating with the heater Clarke ® ® 14 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 15: Preparación De La Máquina Para Ponerla En Marcha
PRECAUCIÓN: Si ambos cables están conectados al de sauter lorsqu'il fonctionne avec mismo disyuntor el mismo puede l'appareil de chauffage allumé. accionarse cuando funciona con el calentador encendido. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 15... -
Page 16: Ext -100 Control Panel
PUMP SWITCH (3): This switch will illuminate when the pump is on. HEAT SWITCH (4): The heat switch will illuminate when it is activated and will turn the heater on. Clarke ® ® 16 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 17: Panel De Control Del Modelo Bext -100H
CONMUTADOR DE CALOR (4): El conmutador de calor se iluminará COMMUTATEUR DE CHAFFAGE (4): Le commutateur de chauffage cuando se activa y enciende el calentador. s'allume lorsqu'il est enclenché et allume le chauffage. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual... -
Page 18: Ext -150H Control Panel
HEAT LIGHT MODE ( 6 ) : The light will only illuminate when the heater uis heating and will turn off when it reaches operating temperature. Clarke ® ® 18 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 19: Panel De Control Del Modelo Bext -150H
Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 19... -
Page 20: Extension Cords - 120V
12 AWG. Be sure your extension cord is no longer than 50 ft. Do not join two extension cords. Clarke ® ® 20 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 21: Prolongaciones - 120V
15 m et n'utilisez pas deux calibres de alambres y de chapas). rallonges bout à bout. Compruebe que su prolongación no mide más de 50 pies. No una dos prolongaciones. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 21... -
Page 22: Machine Operating Instructions
8. As you make passes, repeat one inch of the area already cleaned. 9. Make more passes until all of the room is cleaned. CAUTION: Clarke will not be held liable for damage to the carpet, or poor results because of the operator's lack of ability. Clarke ®... -
Page 23: Instrucciones Para El Funcionamiento De La Máquina
Continuez à effectuer des passages jusqu'à ce que la totalité habitación. de la pièce soit nettoyée. ATTENTION: Clarke ne sera pas tenu PRECAUCIÓN: Clarke no se responsabiliza por los daños a las alfombras o por los responsable de tous dégâts resultados insatisfactorios que survenus à la moquette ou de se generen por la falta de pericia résultats médiocres causés... -
Page 24: Maintenance
WARNING: Maintenance and repairs must be done by authorized person- nel only. Keep all fasteners tight. Use only genuine Clarke parts. WARNING: Do not operate this machine un- less it is completely assembled. NOTE: For maintenance of the floor tools read the manual given with the tools. -
Page 25: Mantenimiento
Tenez toutes les fixations Mantenga ajustados todos los bien resserrées. N'utilisez sujetadores. Utilice que des pièces Clarke solamente piezas originales authentiques. de Clarke. ATTENTION: Ne faites pas fonctionner la machine avant qu'elle ne soit ADVERTENCIA: No opere esta máquina hasta... -
Page 26: How To Prevent Damage From Freezing Temperatures
(see figures 9a & 9b): 1. Empty both tanks. 2. Unlatch tanks from base. 3. Tilt tanks back. 4. Disconnect hoses from tanks. 5. Open up for service. Clarke ® ® 26 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 27: Medidas Para Evitar Los Daños Que Producen Las Temperaturas De Congelación
4. Desconecte las mangueras de los depósitos. 4. Déconnectez les flexibles des réservoirs. 5. Ábralos para realizar las reparaciones. 5. Ouvrez afin de procéder à l'entretien. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 27... -
Page 28: How To Check The Commutator And The Carbon Brushes
5. Disconnect the ground wire. 6. Remove the plastic motor cover. 7. Inspect the commutator. See figure 10. Take the IRREGULAR AGUJEROS machine to a Clarke authorized repair location if you EN BUEN EN BUEN PEQUEÑOS see any of the following conditions:... - Page 29 7. Inspectez le commutateur. Voir Figure 10. Amenez la 7. Revise el conmutador. Vea la Figura 10. Lleve la machine à un centre de réparation Clarke agréé si máquina a un centro de reparaciones autorizado vous observez l'une des conditions suivantes :...
-
Page 30: How To Correct Problems In The Machine
2. There is too much foam. 2. Put defoamer in the solution. Order P/N 398420. 3. The float gasket is dirty or damaged. 3. Clean the gasket. Replace if damaged. Clarke ® ® 30 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 31: Corrección De Los Problemas De La Máquina
2. Coloque desespumante en la solución. Solicite el se desborda. producto número 398420. 3. La junta del flotador está sucia o dañada. 3. Limpie la junta. Reemplácela si está dañada. Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 31... - Page 32 2. Ajoutez l'antimousse à la solution. Commande pièce déborde n°398420 3. Le joint du flotteur est sale ou endommagé 3. Nettoyez le joint. Remplacez-le s'il est endommagé Clarke ® ® 32 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual...
-
Page 33: Ext
100, 100H, 150H, 300HV 100, 100H, 150H, 300HV 100, 100H, 150H, 300HV - - - - - Extractor Extractor Extractor Extractor Extractor Section II Parts and Service Manual (70416A) Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 33... -
Page 34: Ext -100 Assembly Drawing
Clarke ® -100, 120V ® Assembly Drawing Clarke ® ® 34 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 35: Parts List
10/10 ® Clarke -100, 120V ® Assembly Drawing Ref # Part No. Description Ref # Part No. Description 53876A Drain Gate 80335A Lock Nut, ¼-20 80331A Screw, 8-32 x " 53885A Quick Disconnect, Male ¼ PT 52636A Latch 53895A... -
Page 36: Ext -100H Assembly Drawing
Clarke ® -100H, 120V ® Assembly Drawing Clarke ® ® 36 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 37: Parts List
10/10 Clarke ® -100H, 120V ® Assembly Drawing Ref # Part No. Description Ref # Part No. Description 53876A Drain Gate 80335A Lock Nut, ¼-20 80331A Screw, 8-32 x " 80340A Quick Disconnect, Male ¼ PT 52636A Latch 53895A... -
Page 38: Ext -150H Assembly Drawing
Clarke ® -150H, 120V ® Assembly Drawing Clarke ® ® 38 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 39: Parts List
Clarke ® -150H, 120V ® revised 10/10 Assembly Drawing Ref # Part No. Description Ref # Part No. Description 59721A Valve-Drain 962098 Screw, ¼ -20 x 3/4 53606A Elbow-45 Degree, Drain 52840A Quick Disconnect 962929 Screw, 10-32 x 52672A Flange, Exhaust... -
Page 40: Ext -300Hv Assembly Drawing
Clarke ® -300HV, 120V ® Assembly Drawing Clarke ® ® 40 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 41: Parts List
Heat Repair Kit w/Thermostat & Cutout Asm. * Items 6, 7 & 104 must be ordered as a set when replacing any original Label, Clarke 6 Adapter and: 3 - 85522A Screws, 1 - 962109 Screw, 1 - 920296 Nut. -
Page 42: Ext -100 Accessories
10/10 Clarke ® -100 Accessories ® Drawing & Parts List WARNING : Do not use Bext 100 accessories on heated units (Bext 100H, 150H & 300HV). Injury to operator or bystanders could occur. Damage to the machine could occur. -
Page 43: Ext -100H Accessories
7/10 Clarke ® 100H, 150H Detailer Accessories ® Drawing & Parts List Part No. Description 9 11 61394A 12" Wand 52840A Nipple Quick Connect 56102874 Hose Asm., Solution 52544A Valve Body 52996A Nozzle, Spray 52469A Hose 15' 53172A Quick Coupling Female 52833A Tool, 3½... -
Page 44: Ext -300Hv Accessories
7/10 ® Clarke 300HV Accessories ® Drawing & Parts List Part No. Description 61395A 12" Wand 56102874 Hose Asm., Solution 52544A Valve Body 52996A Nozzle, Spray 52469A Hose 15' 52833A Tool, 3½ HP 398426 Defoamer *1 case 398425 Extractor, Concentrate... -
Page 45: Electrical Schematic Bext100 120V
® Clarke -100, 120V ® Wiring Diagram Clarke ® ® -100, 100H 150H, 300HV Operator's Manual FORM NO. 70416A - 45... -
Page 46: Electrical Schematic Bext 100H 120V
Clarke ® -100H, 120V ® Wiring Diagram Clarke ® ® 46 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... -
Page 47: Electrical Schematic Bext 150H 120V
Clarke ® -150H, 120V ® Wiring Diagram BEXT-150H EXTRACTOR WIRING DIAGRAM 120V BLACK CORD 1 WHITE GROUND ORANGE VAC 1 VAC 2 ORANGE WHITE BLUE PUMP DUAL CORD BLACK SENSOR BYPASS SWITCH CIRCUIT BOARD MODE LIGHT BLACK LOCATOR LIGHT HEATER... -
Page 48: Electrical Schematic Bext 300Hv 120V
® Clarke -300HV, 120V ® Wiring Diagram Clarke ® ® 48 - FORM NO. 70416A -100, 100H 150H, 300HV Operator's Manual... - Page 50 14600 21st Avenue North Plymouth, MN 55447-3408 www.clarkeus.com Phone: 800-253-0367 Fax: 800-825-2753 ©2010 Nilfi sk-Advance, Inc. A Nilfi sk-Advance Brand...
