- Page 1 1F95W-80 OPERATION GUIDE 7 Day Multi-stage Electronic Digital Thermostat with Programmable Fan WHITE-RODGERS Operator: Save this booklet for future use!
-
Page 2: About Your New Thermostat
About Your New Thermostat . . . Your new Digital COMFORT SET II Multi-stage Thermostat uses the technology of a solid-state microcomputer to provide precise time/temperature control. The COMFORT SET II Thermostat offers you the flexibility to design heating and cooling programs that fit your needs. Please read this manual thoroughly before operating or programming your thermostat. - Page 3 In This Guide . . . YOUR NEW THERMOSTAT'S Program Heating and Cooling FEATURES ........... 4 Temperatures OPERATING YOUR THERMOSTAT ..5 Enter Heating Program PARTS OF THE THERMOSTAT Enter Cooling Program The Back Of the Thermostat Body Using the COPY Button The Display CHECK YOUR PROGRAMMING The Thermostat Buttons...
-
Page 4: Your New Thermostat's Features
YOUR NEW THERMOSTAT’S FEATURES • Computed Energy Management Recovery • Compressor short cycle protection (EMR) • Blower delay in the cooling cycle • Automatic changeover • Up to 2 stages of heat and up to 2 stages of • Two hour temperature override cool •... -
Page 5: Operating Your Thermostat
OPERATING YOUR THERMOSTAT Before you begin programming your thermo- The subbase is attached to the wall, but you can stat, you should be familiar with its features and remove the thermostat body for easy program- with the display and the location and operation ming. -
Page 6: Parts Of The Thermostat
PARTS OF THE THERMOSTAT If the word BATTERY is flashing in the display window, the battery is low and should The Back of The Thermostat Body be replaced with a fresh 9 volt Energizer ® alkaline battery. The battery will provide Turn the thermostat body over. - Page 7 The buttons (other than ) are 4-pin connector Battery located behind the thermostat door. To open the door, use your fingernail in the indentation at the top center of the door. Pull the door out, then swing the door down on its hinges. Following are brief descriptions of the display and the thermostat buttons.
- Page 8 The Display FAN AUTO is displayed during automatic fan operation (when the blower cycles with Continuously displays system mode (HEAT, the heating or cooling system). PRG FAN is OFF, COOL, AUTO, HOLD). During pro- displayed when the fan has been pro- gramming, the day of the week is displayed grammed to run continuously during the (MO, TU, WE, etc.).
- Page 9 5 DAY FAN AUTO HOLD SYSTEM TIME VIEW CLOCK PRGM HEAT - OFF - COOL - AUTO COPY TIME VIEW BACK TEMP PRGM ON - AUTO FAN AUTO BATTERY FAN ON...
- Page 10 The Thermostat Buttons gram; use to view programming for Sets the system mode (HEATing, OFF, following days). COOLing, or AUTOmatic changeover). Used with to select setpoint Selects fan operation (see #5, above). This temperatures. button is also used to program the fan to run Used to manually override programming to continuously during a program period.
- Page 11 (Blue arrow) Lowers temperature setting Red indicator is lit when heating or cooling (40°F or 4°C minimum). is in operation. Yellow indicator is lit when the second stage of heating or cooling is in operation. 5 DAY FAN AUTO SYSTEM HOLD TIME VIEW...
-
Page 12: Operating Features
programmed a temperature of 70°F. The OPERATING FEATURES thermostat will automatically activate the Now that you are familiar with the thermostat heating system at about 5:00 AM, so that display and buttons, read the following informa- the programmed 70°F temperature is tion to learn about the many features of the reached by about 6:00 AM. - Page 13 position (see figure below). Remove the OFF (down) position. Remove the battery battery for at least two minutes, to allow the and allow at least two minutes for the ther- thermostat to reset itself. Replace the bat- mostat to reset itself. Replace the battery, tery and put the thermostat back on the wall.
- Page 14 selected temperature for two hours. After NOTE two hours, the thermostat will automatically If the thermostat is configured for automatic revert to the program. changeover, the thermostat will not allow the temperature separation between the highest NOTE heat setting and the lowest cool setting to be This feature will not work in the AUTO mode.
- Page 15 • HOLD TEMPERATURE — The thermostat • ADJUSTABLE HEATING AND COOLING can hold any temperature within its range CYCLE TIMES (ANTICIPATION) — If the for an indefinite period, without reverting to heating/cooling system is turning on and off too often (short cycles) or not often enough the program.
- Page 16 increase the cycle time. If the heat cycles • BACKLIT DISPLAY — When you press any button on the thermostat, the display is are too long, press to decrease the TIME BACK lit for approximately eight seconds (this fea- cycle time. To set cooling anticipation, press ture works only when the thermostat is at the same time again.
- Page 17 • SYSTEM INDICATOR LIGHTS — The red TOTAL KEYPAD LOCKOUT (ON) indicator light comes on when the heating or cooling system is operating. The yellow indicator light comes on when the second stage of heating or cooling is operating. Switch #1 set at installation (DO NOT CHANGE) •...
-
Page 18: Programming Your Thermostat
temperature for the time period, press override constant fan, press until ON - AUTO until PRG FAN is displayed. To FAN AUTO is displayed. ON - AUTO PROGRAMMING YOUR THERMOSTAT Now you are ready to program your thermostat. PLANNING FOR YOUR NEEDS This section will help you plan and program your First, answer the following questions to help you thermostat to meet your needs. - Page 19 Now look at the factory preprogrammed times thermostat can be programmed. You may select and temperatures shown below. If this program up to two heating temperatures (HEAT O for occupied temperature and HEAT U for unoccu- will suit your needs, simply press to begin PRGM pied temperature), and up to two cooling tem-...
- Page 20 Heating/Cooling Schedule Plan Heating Program Cooling Program Occupied Occupied Unoccupied Unoccupied Occupied Occupied Unoccupied Unoccupied Period Heating Period Heating Period Cooling Period Cooling Start Time Temp. Start Time Temp. Start Time Temp. Start Time Temp. Monday Tuesday Wednesday Thursday Friday Saturday Sunday NOTE: Damper operation is linked to occupied or unoccupied temperature settings, not time periods.
- Page 21 SAMPLE Joe’s Restaurant Heating/Cooling Schedule Plan Open: Mon-Sat 10:00 AM to 9:30 PM Sun 12:00 PM to 6:00 PM Heating Program Cooling Program Occupied Occupied Unoccupied Unoccupied Occupied Occupied Unoccupied Unoccupied Period Heating Period Heating Period Cooling Period Cooling Start Time Temp.
-
Page 22: Entering Your Program
Set Current Time and Day ENTERING YOUR PROGRAM Follow these steps to enter the heating/cooling 1. Press once. The display will show CLOCK program you have selected. minutes only. NOTE EXAMPLE: We recommend that you remove the thermostat 2. Press and hold either TIME until you TIME... - Page 23 5. Press once. The display will show the gramming after this happens, press VIEW until CLOCK PRGM day of the week as an abbreviation (MO for you are at the point where you stopped program- Monday, TU for Tuesday, etc.). ming.
- Page 24 4. Press once. The letter O will change to 10. Press once. Press to set VIEW VIEW TEMP TEMP the letter U, representing the unoccupied your selected COOL U (unoccupied cool- heating temperature (HEAT U). ing) setting. 5. Press either to change the 11.
- Page 25 display will alternate between the HEAT O EXAMPLE: and HEAT U temperatures you previously This display window shows that for Monday’s selected). occupied heating period, the start time is 8:00 AM, 70° is the programmed tempera- NOTE ture, and the fan is set to PRG FAN (continu- Damper operation is linked to the occupied or ous fan operation);...
- Page 26 same program you set for Monday. You may press VIEW . The currently programmed start PRGM also choose to use the HOLD button to copy any time and heating temperature for Monday’s COPY unoccupied heating period will be dis- day’s heating and cooling program into any played.
- Page 27 Enter Cooling Program SYSTEM 1. Press until COOL is displayed. HEAT - OFF - COOL - AUTO CAUTION 2. Press once. MO, the abbreviation for VIEW PRGM ° If outside temperature is below 50 F, we Monday, and the letter O, representing the recommend that you remove the thermo- occupied cooling period, will appear in the stat from the wall before proceeding with...
- Page 28 you continue to press , the 6. After selecting the desired cooling tempera- display will alternate between the COOL O ture for Monday’s occupied cooling period, and COOL U temperatures you previously press . The currently programmed start VIEW PRGM selected).
- Page 29 9. After you enter or copy heating and cooling NOTE programs for all 7 days, press to begin PRGM For most efficient programming, you should program operation. enter both the heating and cooling programs for the day you wish to copy FROM before using the Using The COPY Button COPY function, since the COPY function copies You can copy the entire heating/cooling pro-...
-
Page 30: Check Your Programming
Wednesday is 3, etc.). For example, if in CHECK YOUR PROGRAMMING step 2 you displayed Wednesday’s pro- Follow these steps to check your thermostat gram, when you press HOLD , COPY 3 will programming one final time before beginning COPY thermostat operation. - Page 31 programming instructions to correct the er- SYSTEM Press until OFF is displayed. Reattach HEAT - OFF - COOL - AUTO ror (you can change any part of your pro- thermostat to subbase. Then press SYSTEM gram while you are reviewing it). HEAT - OFF - COOL - AUTO select the operation mode you want (HEAT, 6.
-
Page 32: Questions And Answers
QUESTIONS AND ANSWERS 1. How can I permanently change a part of programming, press until VIEW PRGM my program? you return to the point where you stopped programming. Then you may continue to Press until you reach the VIEW PRGM program the thermostat normally. - Page 33 a cooling temperature of 82°F until you re- ever, if there is power to the thermostat and enter your program. Setpoint temperature the display is blank or frozen, static dis- will not be displayed. charge is probably the cause. ® If a fresh 9 volt Energizer alkaline battery is During periods of low humidity (especially...
- Page 34 ture higher. To set a lower cooling tempera- to begin the factory preset program. PRGM ture, you must select a lower heating tem- Or you may reprogram the thermostat, then perature. See PROGRAMMING YOUR replace it on the wall. THERMOSTAT. To prevent further static discharge prob- 7.
- Page 35 8. The display is flashing BATTERY. What CAUTION does this mean? ° If the outside temperature is below 50 The 9 volt battery installed in the thermostat DO NOT use the button to move the is low and should be replaced with a fresh 9 temperature below the setpoint tempera- ®...
- Page 36 • You have programmed the incorrect day 11. Why does the blower fan keep running or time. Check your programming (be after the system has turned off? sure that the times you programmed are • The fan is programmed to run continu- correct AM or PM times).
- Page 37 13. Between heating and cooling seasons, I 14. I live in an area where daylight savings want to turn my system off. Can I do this time is observed. How do I change the without affecting my thermostat program- thermostat clock twice a year without ming? affecting thermostat programming? Any time you wish to turn your system off,...
- Page 38 about one minute if there is no battery whether your programming was maintained. installed or if the installed battery is dead. If the thermostat retains programming, press If you are changing the battery after seeing SYSTEM until OFF is displayed, put the ther- HEAT - OFF - COOL - AUTO a flashing BATTERY on the display, the mostat back on the wall, press...
- Page 39 NOTES...
- Page 40 If you need further information on programming or operation, please write to us at: White-Rodgers Division, Emerson Electric Co. 9797 Reavis Road St. Louis, MO 63123-5398 Attention: Technical Service Department WHITE-RODGERS DIVISION Part No. 37-5523A EMERSON ELECTRIC CO. 9797 REAVIS ROAD ST.
