  • Page 1 For Help Call 1.800.241.6264 Monarch Pathfinder 6039 Quick Start More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time...

  • Page 2: Quick Reference

    Your System Administrator must have already loaded an application in the printer before you can use it. Monarch®, Pathfinder® Ultra®, 6039, 9462, and 9465 are trademarks of Avery Dennison Retail Information Services, LLC.. Avery Dennison® is a trademark of Avery Dennison Corporation.
  • Page 3 A t t a c h i n g t h e S a f e t y S t r a p 1. Turn the printer upside down, resting its top in the table. 2. Remove the stylus strap from the loop.
  • Page 4 2. Turn the printer upright, holding your palm beneath the open battery compartment. Hit the printer on your hand and catch the battery as it slides out. 3. Insert a new battery into the compartment (connector end first). 4. Slide the compartment door shut until it clicks into place.

  • Page 5: Loading For Non-Peel Mode

    6. Place a roll of supply in the supply holder so it unrolls from the bottom. 7. Load the supplies for the printing mode you want: Peel or Non- Peel. Loading for Non-Peel Mode 1. Feed the supply under the applicator roller and over the label deflector.
  • Page 6 6. Pull the backing paper over the guide roller, down to the pinch and feed rollers. Guide Roller (behind suppl y) Feed Roller (behind Pinch Roller) Pinch Roller 7. Hold the backing paper edge between the feed and pinch rollers and press the trigger. 8.
  • Page 7 U s i n g t h e K e y p a d The printer’s keypad appears below. Key(s) Description Enter Accepts data or a menu selection. Tabs to the next tab stop or the next field. Pressing Fct + Tab backspaces a tab stop or returns to the previous field.

  • Page 8: Entering Data

    Entering Data Entering data using the keypad is similar to entering data on a cell phone. There are three data entry modes: Normal (Numeric) mode – Default. Press the key to display what appears on the face of the key (numbers). Lower-Case Alphabetic mode –...

  • Page 9: Cleaning The Pinch And Feed Rollers

    5. Clean the printhead area of all adhesive and label particles using a Monarch Cleaning Pen (#114226) or a soft cloth moistened with isopropyl alcohol. Allow the printer to dry before reloading supplies. Cleaning the Pinch and Feed Rollers 1. Turn off the printer and open the supply cover.

  • Page 10: Cleaning The Platen Roller

    Cleaning the Platen Roller Platen Roller Clean the platen roller when you see significant adhesive build-up or when a label is wrapped around the platen roller. 1. Turn off the printer and open the supply cover. 2. Remove the supplies. See “Removing Supplies” in Chapter 3 for more information.

  • Page 11: Clearing Supply Jams

    Cleaning the Scanner Window and Display Screen 1. Moisten a soft cloth with distilled water. 2. Wipe the window and the display screen until they are clean. Clearing Supply Jams 1. Turn off the printer. 2. Open the supply cover completely. 3.
  • Page 12 Problem Solution Print has voids or is too Load the supply correctly / light. Check for damage. Close the supply cover completely. Switch to a fully-charged battery. Clean the printhead. Printer partially prints Re-load the supply or load new and fails to respond to supplies.

  • Page 13: Error Codes

    Error Codes Following are some common error codes you may receive. See your System Administrator if you receive any codes not listed here. Code(s) Description 004 – 005 Supply size is incorrect. Reload the correct supplies. 267 – 271 Communication error. See your System 410 –...
