  • Page 1 Q-SUB Manual (2.2 EN)

  • Page 2: Table Of Contents

    Information regarding use of loudspeakers..........3 Q-SUB..................4 Connections......................4 Operation with D6 or D12................5 Operation with E-PAC..................5 Technical specifications..................6 Q-SUB and Q1 cabinets..................7 Q-SUB and Q7 cabinets..................7 Manufacturer's declarations..........8 EU conformity of loudspeakers (CE symbol)..........8 WEEE Declaration (Disposal)................8 General Information Q-SUB Manual Version 2.2 EN, 03/2008, D2042.E.02...

  • Page 3: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. Q-SUB Manual (2.2 EN) Safety precautions - 1...

  • Page 4: Q-Sub

    Z5013 Loudspeaker stand for the deployment of full range cabinets. The Q-SUB has a total of 10 sockets in the front grill and side panels to accept the Z5153 Locking pins 8 mm that connect to the array links of the Q1 system.

  • Page 5: Operation With D6 Or D12

    Within the D12 amplifier this is available in "Dual Channel" and "Mix TOP/SUB" mode. Selecting Q-SUB mode in the D6 or D12 enables up to two Q-SUB cabinets to be driven by the respective channel. Selecting the Q-SUB configuration along with the CSA mode enables up to two Q-SUB cabinets to be driven by the respective channel.

  • Page 6: Technical Specifications

    100 Hz settings ........................optional 2 x NL4 Pin assignments..............EP5: 3/4, SenseDrive pin 5 ..........................NL4: 2+/2– Weight......................42 kg (92.6 lb) 580 [22.83"] 668 [26.30"] 773 [30.42"] Fig. 5: Q-SUB cabinet dimensions in mm [inch] Q-SUB Manual (2.2 EN) Page 6 of 8...

  • Page 7: Q-Sub And Q1 Cabinets

    Q-SUB cabinets MUST be positioned at the top of the column. Q1 and Q-SUB cabinets use the same sockets in the front grill and side panels to accept the Z5153 Locking pin 8 mm. Located on the top of the side panels of the Q-SUB cabinet is an additional socket that enables the Q1 cabinet to be tilted downwards up to 6°...

  • Page 8: Manufacturer's Declarations

    Manufacturer's declarations EU conformity of loudspeakers (CE symbol) This declaration applies to - Q-SUB Z0510 manufactured by d&b audiotechnik GmbH. All production versions of this type are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
