Summary of Contents for d&b audiotechnik SL Z5731
- Page 1 Z5731 Rigging manual 1.1 en...
- Page 2 General information Z5731 Rigging manual Version: 1.1 en, 03/2020, D2739.EN .01 Copyright © 2020 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.
-
Page 3: Table Of Contents
Contents Contents Z5731 KSL Stacking frame..........4 1.1 Scope of supply................4 1.2 Safety precautions and intended use........4 Assembly/Disassembly............. 5 2.1 Operational safety..............5 2.2 Tension mode rigging..............5 2.3 First cabinet to frame - Instruction label........5 2.4 Adding further cabinets.............. 6 2.5 Safety and system checks............ -
Page 4: Z5731 Ksl Stacking Frame
Z5731 KSL Stacking frame Z5731 KSL Stacking frame 1.1 Scope of supply The Z5731 KSL Stacking frame is equipped and supplied with the following components. Please verify the shipment for completeness and proper condition of the items. Pos. Qty. Description Z5731 KSL Stacking frame Including: Rubber feet... -
Page 5: Assembly/Disassembly
Assembly/Disassembly Assembly/Disassembly 2.1 Operational safety The assembly should always be carried out by two persons. During assembly pay attention to the possible risk of crushing. Wear suitable protective clothing. Observe all instructions given on the respective instruction labels of the rigging components and loudspeaker cabinets. 2.2 Tension mode rigging NOTICE! For safety and stability reasons, KSL-TOP cabinets must always be... -
Page 6: Adding Further Cabinets
Assembly/Disassembly 7. At the center rear Splay link slot of the frame, release the bottom Locking pin [2]. 8. Use the upper Locking pin [1] to set the desired tilt angle (e.g. –10°) on the upper hole grid. 9. Lower the cabinet and insert the Splay link into the slot. 10. - Page 7 Assembly/Disassembly 6. On the bottom cabinet, release Locking pin [2]. 7. Use Locking pin [1] to set the desired splay angle (e.g. 5°) on the upper hole grid of the bottom cabinet. 8. Lower the upper cabinet and insert the Splay link into the rear rigging strand of the bottom cabinet.
-
Page 8: Safety And System Checks
Assembly/Disassembly 2.5 Safety and system checks Recheck the actual status of the entire assembly as follows: Mechanical setup 1. Ensure the stacking frame is properly secured against movement and possible tipping over using appropriate rachet straps and fixing points. 2. Ensure the Locking pins of the front fixing support to the first cabinet are fully inserted and properly locked on both sides. -
Page 9: Care And Maintenance
Care and maintenance Care and maintenance 3.1 Transport / Storing During transport ensure the stacking frame is not stressed or damaged by mechanical forces. Use suitable transport cases. Due to their surface treatment the rigging components are temporarily protected against moisture. However, ensure the components are in a dry state while stored or during transport. -
Page 10: Manufacturer's Declarations
Manufacturer's declarations Manufacturer's declarations 4.1 EU conformity (CE symbol) This declaration applies to: d&b Z5731 KSL Stacking frame (Including all additional items) d&b KSL/KSLi TOP loudspeaker cabinets (With integrated rigging components) ▪ Z0780 KSL8 ▪ Z0781 KSL12 ▪ Z0790 KSLi8 ▪... - Page 11 www.dbaudio.com...
