2.2.2. Print Density Configuration

In this section, you can configure the print density of all printed information.
This configuration is very important when you use different paper thicknesses.
You can configure to Normal, Strong, Very Strong, Very Weak or Weak Print Density.
The factory default setting is Normal.

2.2.3. Near End Paper Sensor Configuration

In this section, you can configure the ability to use the Near End Paper Sensor.
You can disable it to turn off the sensor or enable it to detect the end of paper roll with
the sensor and report the status to the host system. You can adjust the paper length at
the sensor indication by following the proper steps.
The factory default setting is Enable.

2.2.4. Adjusting the Paper Length in the Near-End-Paper Sensor Indicator

The printer has the option to change the response of the Near-End-Paper Sensor,
allowing adjustments in the remaining length of the paper roll, according to your needs.
Please use a slotted screwdriver to change this setting as indicated in the picture above.
Move the sensor position up to have more paper left or down to have less paper left.

2.2.5. Paper Width / Print Width Configuration

In this section, you can configure the paper width used and the print width adopted by
the software in the printer.
You can configure to:
You must also adjust the paper roll spacer located inside the printer, as described
below:
18
Paper Width (mm)
58
76
76
80
80
80
82.5
82.5
82.5
82.5
Print Width (mm)
48
64
72
64
72
76
64
72
76
80
