Page 14
ENGLISH

Section 7. Product Specifications and Technical Data

7.1

Replacement Parts List

To order or purchase parts for Jandy Pro Series pumps, contact your nearest Zodiac dealer. If the Zodiac dealer cannot
supply you with what you need, contact Zodiac technical support at 1.800.822.7933, or send an e-mail message to
productsupport@zodiac.com.
Key
No. Description
1 Single-speed Motor & Hardware, FHP
1 Single-speed Motor & Hardware, FHP
1 Single-speed Motor & Hardware, FHP
1 Single-speed Motor & Hardware, FHP
1 Single-speed Motor & Hardware, FHP
1 2-Speed Motor & Hardware, FHP
1 2-Speed Motor & Hardware, FHP
1 2-Speed Motor & Hardware, FHP
2 Backplate, FHP (Backplate w/Hardware, Backplate O-ring & Mechanical Seal)
3 Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring)
3 Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring)
3 Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring)
3 Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring)
3 Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring)
4 Diffuser, FHP (Diffuser w/O-ring, Hardware & Backplate O-ring)
4 Diffuser, FHP (Diffuser w/O-ring, Hardware & Backplate O-ring)
5 Mechanical Seal, Carbon and Ceramic (1 Set)
6 Pump Body, FHP (Body and Backplate O-ring)
7 Motor Mounting Foot, FHP
8 Lid w/Locking Ring, FHP (Lid w/Locking Ring & Lid O-ring)
9 Pump Debris Filter Basket, FHP
10 Drain Plug w/ O-ring (Set of 2)
11 Tail Piece, O-ring & Union Nut (Set of 2)
12 Lid O-ring, FHP
13 Backplate O-ring, FHP
14 Diffuser/Impeller Hardware (Diffuser O-ring, Screws (2), Screw w/O-ring & Backplate O-ring)
15 Backplate Hardware, FHP (Backplate Hardware & Backplate O-ring)
16 Motor Hardware Kit
17 Tailpiece O-ring (Set of 2)
18 Small Base Spacer
19 Large Base Spacer (optional)
Jandy Pro Series FHPM Pump
®
|
Installation & Operation Manual
Model No. (HP)
1.0, 1.0-2
1.5, 1.5-2
2.0, 2.0-2
0.75, 1.0, 1.0-2
1.5, 1.5-2, 2.0, 2.0-2, 2.5
Order Part
No.
0.75 R0479310
1.0 R0479311
1.5 R0479312
2.0 R0479313
2.5 R0479314
1.0 R0479306
1.5 R0479307
2.0 R0479308
All R0479500
0.75 R0479601
R0479602
R0479603
R0479604
2.5 R0479605
R0479702
R0479701
All R0479400
All R0479800
All R0479900
All R0480000
All R0480100
All R0446000
All R0327301
All R0480200
All R0480300
All R0480400
All R0480500
All R0446700
All R0337601
All R0486700
All R0546400
