Chapter 2 Installing Bundled Software
(b) Status Bar
The status bar (below figure), which is located at the bottom of the Active Upgrade Console window, reports a
quick summary of the status of the upgrade.
1 Configuration file name
2 Hardware State
3 Upgrade State
4 Operational State
5 Partner State
Configuration file name
Shows configuration file name to be upgraded.
Hardware State
The Hardware State reports hardware state and where your applications are running.
Hardware State
Fault-tolerant
Production Side
Upgrade State
The Upgrade State reports the progress of upgrade process.
Upgrade State
Idle
Prepare Split
Split
Prepare Merge
Merge
Commit
Abort
Express5800/R320c-E4, R320c-M4, R320d-E4, R320d-M4 Installation Guide (Windows)
Status Bar
Status: Hardware State
The system is duplexed.
The system is currently running in split mode, and your applications are running
from the Production Side (the original copy of your software). The Upgrade Side is
available for upgrade tasks.
Status: Upgrade State
The current upgrade session is idle. The Active Upgrade process has just finished,
or it has not been initiated yet.
The Active Upgrade Console is preparing to split the system.
If the operational state is Ready, the system is running in split mode. Otherwise,
the Active Upgrade Console is in the process of initiating split mode.
The Active Upgrade Console is preparing to merge the system.
If the operational state is Ready, the system is merged. Otherwise, the Active
Upgrade Console is in the process of merging the system.
The Active Upgrade Console is in the process of committing your changes (making
them permanent).
The upgrade process has been aborted, and the Active Upgrade Console is in the
process of restoring the system to its previous state.
1. Bundled Software for the Server
Description
Description
263
