Maintenance

There are only a few simple steps to maintaining your ROBO-KLEEN
PLUS.
1) Filter Bag
a. Place ROBO-KLEEN PLUS upside
down. Push the locking tabs to
the side to unlock the bottom lid.
Remove the bottom lid.
b. Pull one of the 4 red tabs out and
remove the filter bag from the bottom lid.
Turn the filter bag inside out. Use a garden
hose to wash it thoroughly. The bag should
be laundered periodically, using a regular
wash cycle.
c. Rinse the bottom lid parts and bottom brushes.
d. Refit the filter bag with the fluffy surface
inward. Start from one corner - align one of
the red tabs with the corner. Gently insert the
stitched edge of the filter bag into the double
walls (groove) of the bottom lid, and work your
way around.
e. Replace the bottom lid assembly in the body of
the unit and lock in place.
2) Impeller
Occasionally hair or linen may get caught in the impeller. If that
happens, take the top grill off by removing the 2 screws from the top.
MAKE SURE THE TRANSFORMER IS UNPLUGGED. Remove the
debris. Replace the top grill and tighten the 2 screws.
3) Front Drive Wheels and Rear Idler Wheels
Remove debris or tree leaves caught in the axle bearing. CAUTION: Do
not turn the drive wheels by force. This may cause damage to the
drive gear train.
4) Winterization
Do not store ROBO-KLEEN PLUS where the temperature drops below
40˚ F. Freezing temperatures can affect seals and lubricants used in
the mechanism.
7
