1. Tap the MENU button until "DISP" is displayed, press ENTER.
2. Press ENTER to "flip" the display. Press ENTER to "flip" it again. Press ENTER when you have made your
desired setup.
SYSTEM MENU (continued)
FADJ
- This function will give you a you are able to focus the lens for a clear LED output.
1. Tap the MENU button until "FADJ" is displayed, press ENTER. The fixture will turn a different way each time
the ENTER button is pressed.
2. With the spot pointed at a flat wall or surface, at the distance it will be set up, you can turn the lens to adjust
the clarity. Press MENU to exit.
TEST
- This function will run a self test program. The test program will test pan/tilt movement and
colors.
1. Tap the MENU button until "TEST" is displayed, press ENTER.
2. The fixture will now run a self test.
TEMP
- With this function you can check the temperature of the fixture.
1. Tap the MENU button until "TEMP" is displayed, press ENTER.
2. The temperature of the fixture will now be displayed. Press MENU to exit.
FHRS
- With this function you can display the running time of the unit.
1. Tap the MENU button until "FHRS" is displayed, press ENTER.
2. The running time of the fixture will now be displayed. Press MENU to exit.
VER
- With this function you can display the version software of the unit.
1. Tap the MENU button until "VER" is displayed, press ENTER.
2. The software version will now be displayed. Press MENU to exit
RSET
- Use this function to reset the unit.
1. Tap the MENU button until "RSET" is displayed, press ENTER.
2. The fixture will now reset
OTIL
- With this function you can adjust and set the fixtures home position.
1. Press the ENTER button for at least 5 seconds to enter into offset mode.
2. Press the UP or DOWN buttons until "OTIL" is displayed, and press ENTER. The display will begin to flash.
3. Press the UP or DOWN buttons to adjust to your desired home position. Once you have found your desired
position press the ENTER button to set and save, or press the MENU button to return to return to offset
functions without any changes. If you do not press any buttons for 8 seconds the fixture will return to the offset
functions automatically.
