TEMPERATURE AND HUMIDITY WEATHER STATION
Model WS9123IT Instruction Manual
!!Please read carefully before operating!!
INTRODUCTION:
Congratulations on purchasing this tiny 915MHz Temperature and Humidity Weather
Station which displays the time, indoor temperature, and up to three outdoor temperatures
and humidity readings. With only two easy to use keys, this product is ideal for use in the
home or office.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS9123IT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for La Crosse Technology WS9123IT

Summary of Contents for La Crosse Technology WS9123IT

  • Page 1 TEMPERATURE AND HUMIDITY WEATHER STATION Model WS9123IT Instruction Manual !!Please read carefully before operating!! INTRODUCTION: Congratulations on purchasing this tiny 915MHz Temperature and Humidity Weather Station which displays the time, indoor temperature, and up to three outdoor temperatures and humidity readings. With only two easy to use keys, this product is ideal for use in the...

  • Page 2: La Crosse Technology

    « Instant Transmission+» is the up and coming state-of-the-art new wireless transmission technology, exclusively designed and developed by LA CROSSE TECHNOLOGY. “IT +” offers you an immediate update of all your outdoor data measured from the transmitters: follow your climatic variations in real-time!
  • Page 3 FEATURES: The Temperature Station Hanging Hole Battery Display compartment cover Function Removable Keys stand...
  • Page 4 Quartz clock in 12 or 24-hour time display (hour and minute, manually set) Indoor and outdoor temperature reading in degree Celsius (°C) or Fahrenheit (°F) Outdoor humidity reading in %RH Can receive up to three outdoor transmitters Minimum and Maximum records of indoor temperature, outdoor temperature and outdoor humidity Low battery indicator Table standing or wall mountable...
  • Page 5 The Outdoor Thermo-Hygro Transmitter Remote transmission of outdoor temperature and humidity to Temperature Station by 915 MHz signals Displays alternately the measured temperature and humidity readings on LCD Shower proof casing Wall mounting case. Mounting at a sheltered place. Avoid direct rain and sunshine.
  • Page 6 SETTING UP: When one transmitter is to be used First, insert the batteries to the transmitter (see “How to install and replace batteries in the Thermo-hygro transmitter” below). Within 2 minutes of powering up the transmitter, insert the batteries to the Temperature Station (see “How to install and replace batteries in the Temperature station”...
  • Page 7 displayed on the Temperature station. If this does not happen after 2 minutes, the batteries will need to be removed from both units and reset from step 1. In order to ensure sufficient 915 MHz transmission however, this should under good conditions be a distance no more than 100 metres between the final position of the Temperature Station and the transmitter (see notes on “Positioning”...
  • Page 8 light up briefly. Following the indoor temperature and the time as 12:00 will be displayed. If they are not displayed in the LCD after 60 seconds, remove the batteries and wait for at least 60 seconds before reinserting them. The outdoor temperature and humidity from the first transmitter (channel 1) should then be displayed on the Temperature station.
  • Page 9 The outdoor temperature and humidity from the second transmitter and the "channel 2" icon should then be displayed on the Temperature station. If this does not happen after 2 minutes, the batteries will need to be removed from all the units and reset from step 1.

  • Page 10: How To Install And Replace Batteries In The Temperature Station

    HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION The Temperature Station uses 2 x AAA, IEC LR3, 1.5V batteries. When batteries need to be replaced, the low battery icon will appear on the LCD. To install and replace the batteries, please follow the steps below: Lift up the battery compartment cover.
  • Page 11 HOW TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO TRANSMITTER The Thermo-hygro transmitter uses 1 x CR2032, 3.0V Lithium battery. When the battery needs to be replaced, the low battery icon will appear on the LCD of the Temperature Station. To install and replace the batteries, please follow the steps below: Unload the battery holder at the bottom of the transmitter.

  • Page 12: Battery Change

    security code is assigned by the transmitter at start-up and this code must be received and stored by the Temperature Station in the first few minutes of power supplying. BATTERY CHANGE: It is recommended to replace the batteries in all units at least every 12 months to ensure optimum accuracy of these units.

  • Page 13: Function Keys

    FUNCTION KEYS: Temperature Station: The Temperature Station has only two easy to use function keys. min/ max/ + Set/ ch key Set/ch key (Setting/Channel) Press and hold for about 3 seconds to enter the Manual setting mode.
  • Page 14 Used to toggle between the data of different outdoor transmitters (channel) "1", "2" and "3", when more than 1 transmitter is used. min/max/+ key (Min/ Max temperature) Used to toggle between the minimum and maximum recorded readings of indoor & outdoor temperature and outdoor humidity.

  • Page 15: Lcd Screen And Settings

    LCD SCREEN AND SETTINGS: Indoor Temperature in °C Outdoor Outdoor humidity %RH Temperature in °C Outdoor Reception Transmitter identification Signal icon* (channel No.) Transmitter Low battery indicator Receiver Low battery indicator...

  • Page 16: Section 1 - Time

    *When the signal is successfully received by the temperature station, the Outdoor reception icon will be switched on. (If not successful, the icon will not be shown in LCD) So the user can easily see whether the last reception was successful (icon on) or not (icon off).

  • Page 17: Section 3 - Outdoor Temperature And Outdoor Humidity

    Section 3 - OUTDOOR TEMPERATURE AND OUTDOOR HUMIDITY Display of the outdoor temperature and humidity. MANUAL SETTING: 12 / 24- HOUR TIME DISPLAY SETTING AND TEMPERATURE UNIT ( C/ F) SETTING User may choose to display the time in 12-hour or 24-hour mode: Note: When the time display is set as 12-hour mode, the temperature unit will be fixed to F;...

  • Page 18: Manual Time Setting

    Press the min/max/+ key to set the desired time display mode. Press shortly the set key to advance to the MANUAL TIME SETTING. MANUAL TIME SETTING User shall manually set the time of Temperature Station by the following steps: The hour digit of the time display will be flashing. Press the min/max/+ key to adjust the hour.
  • Page 19 VIEWING THE MINIMUM AND MAXIMUM READINGS: User may view the minimum and maximum temperature and humidity data records of the indoor or outdoor channels by the following steps: In normal display, press set/ch key to choose the desired channel (transmitter). Press the min/max/+ key once to view the minimum indoor temperature, minimum outdoor temperature and minimum outdoor humidity of the selected channel.
  • Page 20 Press the min/max/+ key once more to view the maximum indoor temperature, maximum outdoor temperature and maximum outdoor humidity of the selected channel. Selected channel No. Maximum icon...

  • Page 21: Thermo-Hygro Transmitter

    RESETTING THE MINIMUM AND MAXIMUM READINGS: User may reset the minimum and maximum temperature and humidity data to the current value by the following step: Press and hold the min/max/+ key for about 3 seconds to reset all the minimum/ maximum data of all channels and the indoor sensor to the current values in a single action.
  • Page 22 915 MHz RECEPTION CHECK The Temperature Station should receive the temperature and humidity data within a few minutes after set-up. If the temperature and humidity data is not being received 5 minutes after setting up (the display shows “- - -” after consecutive failures in receiving signal), please check the following points: The distance of the Temperature Station or transmitter should be at least 1.5 to 2 metres away from any interfering sources such as computer monitors or TV sets.
  • Page 23 Neighbours using electrical devices operating on the 915MHz signal frequency can also cause interference. Note: When the 915MHz signal is received correctly, do not re-open the battery cover of either the transmitter or Temperature station, as the batteries may spring free from the contacts and force a false reset.
  • Page 24 POSITIONING THE TEMPERATURE STATION: The Temperature Station comes with detachable stand, which provides the option of table standing the unit in addition to wall mounting. Before wall mounting, please check that the outdoor temperature values can be received from the desired locations.
  • Page 25 To wall mount: Fix a screw (not supplied) into the desired wall, leaving the head extended out by about 5mm. Hang the Temperature Station onto the screw. Remember to ensure that it locks into place before releasing.
  • Page 26 POSITIONING THE REMOTE TEMPERATURE TRANSMITTER: The remote temperature transmitter can be placed onto any flat surface or wall mounted using the bracket which doubles as a stand or wall mount base.
  • Page 27 To wall mount: Secure the bracket onto a desired wall using the screws and plastic anchors. Clip the remote temperature transmitter onto the bracket.

  • Page 28: Care And Maintenance

    Note: The mounting surface can affect the transmission range. If, for instance, the unit is attached to a piece of metal, it may then either reduce or increase the transmitting range. For this reason, we recommend not to place the unit on any metal surfaces or in any position where a large metal or highly polished surface is in the immediate vicinity (garage doors, double glazing, etc.).
  • Page 29 When cleaning the display and casings, use a soft damp cloth only. Do not use solvents or scouring agents as they may mark the LCD and casings. Do not submerge the unit in water. Immediately remove all low powered batteries to avoid leakage and damage. Replace only with new batteries of the recommended type.

  • Page 30: Specifications

    SPECIFICATIONS: Temperature measuring range Indoor :-9.9ºC to +59.9ºC with 0.1ºC resolution (“OFL” displayed if outside this range) Outdoor :-39.9ºC to +59.9ºC with 0.1ºC resolution (“OFL” displayed if outside this range) Outdoor Humidity measurement 1 to 99% (Displays "1%" when 1%; displays "99%"...

  • Page 31: Liability Disclaimer

    Battery life cycle (Alkaline batteries recommended): Temperature Station approximately 24 months Outdoor Temperature Transmitter approximately 12 months Dimensions (L x W x H) Temperature Station 58.2 x 17.6 x 118.4 mm Outdoor Temperature Transmitter 36.6 x 13.5 x 87.9 mm LIABILITY DISCLAIMER: Please ensure that all discarded packaging and unwanted electrical items are discarded in a correct and responsible manner.
  • Page 32 As stated on the gift box and labelled on the product, reading the “User manual” is highly recommended for the benefit of the user. This product must however not be thrown in general rubbish collection points. The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences that occur should an inaccurate reading take place.
  • Page 33 This product is guaranteed for the period of 12 months from date of purchase against failure to operate correctly to its listed specifications due to any manufacturing defects. Distributed by: Sontax Australia Phone: 1800 653 238 Email: sales@sontax.com.au Website: www.sontax.com.au...
