Summary of Contents for La Crosse Technology WS-9125TWC-IT
Page 1
Contents Language Page ________________________________________________ English French Spanish...
Page 2
WIRELESS 915 MHz TEMPERATURE STATION Instruction Manual INTRODUCTION Congratulations on purchasing this compact 915MHz Temperature Station which displays indoor and outdoor temperature readings. With two easy to use keys, this product is ideal for use in the home or office.
Page 3
INSTANT TRANSMISSION is the state- This product offers: of-the-art new wireless transmission technology, exclusively designed and developed by LA CROSSE TECHNOLOGY. INSTANT TRANSMISSION offers you an immediate update (every 16 seconds!) of all your outdoor data measured from the transmitters: follow your...
Page 4
FEATURES Hanging Hole Display Battery compartment Function cover Keys Removable stand...
Page 5
The Temperature Station • Indoor and outdoor temperature reading in Fahrenheit (°F) or Celsius (°C) • Can receive up to three outdoor sensors • Wireless transmission at 915 MHz • Signal reception intervals at 16 seconds • Minimum and Maximum records of indoor and outdoor temperature •...
Page 6
The Outdoor Temperature Sensor • Remote transmission of outdoor temperature to Temperature Station by 915 MHz transmission • Water resistant casing • Wall hanging or free standing...
Page 7
SETTING UP: When one sensor is used First, insert the batteries to the sensor (see “How to install and replace batteries in the temperature sensor” below). Within 30 seconds of powering up the sensor, insert the batteries to the Temperature Station (see “How to install and replace batteries in the Temperature Station”...
Page 8
is displayed user may proceed to the next step. After the batteries are inserted, the Temperature Station will start receiving data signal from the sensor. The outdoor temperature should then be displayed on the Temperature Station. If this does not happen after 2 minutes, the batteries will need to be removed from both units and reset from step 1.
Page 9
Using Multiple Sensors with One Temperature Station User shall remove all the batteries from the Temperature Station and sensors and wait 60 seconds if setting has been done with one sensor before. Insert the batteries to the first sensor. Within 30 seconds of powering up the first sensor, insert the batteries to the Temperature Station.
Page 10
The outdoor temperature from the first sensor (channel 1) should then be displayed on the Temperature Station. Also, the signal reception icon will be displayed. If this does not happen after 2 minutes, the batteries will need to be removed from both units and reset from step 1.
Page 11
Insert the batteries to the third sensor immediate after (in 10 seconds after) inserting battery to the second sensor. Then within 2 minutes, the channel 3 outdoor data from the third sensor will be displayed and the channel icon will shift back to "1" once the third sensor is successfully received.
Page 12
After the three sensors have been set up, user may need to check the readings displayed on the temperature station against those being shown on the sensor displays, in order to recognize on which channel each sensor is being presented. IMPORTANT: Transmission problems will arise if the setting for additional sensors is not followed as described above.
HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION The Temperature Station uses 2 x AAA, Alkaline batteries. When batteries will need to be replaced, the low battery icon will appear on the LCD. To install and replace the batteries, please follow the steps below: Lift up the battery compartment cover.
Page 14
HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE SENSOR The temperature sensor uses 1 x CR2032, 3.0V battery. When battery needs to be replaced, the low battery icon will appear on the LCD of the Temperature Station-or replace battery every 12 months. To install and replace the batteries, please follow the steps below: Pull out the battery holder at the bottom of the sensor.
Note: In the event of changing batteries in any of the units, all units need to be reset by following the setup procedures. This is because a random security code is assigned by the sensor at start-up and this code must be received and stored by the Temperature Station in the first few minutes of power supplying.
Please participate in the preservation of the environment. Return used batteries to an authorized depot. FUNCTION KEYS Temperature Station: The Temperature Station has two easy to use function keys.
Page 17
MIN/ MAX/ + key SET/ CH key SET/CH key (Setting/Channel) • Press and hold for about 3 seconds to toggle between the temperature units (°F) or (°C).
Page 18
• Press shortly to toggle between different channel readings. MIN/MAX/+ key (Min/ Max temperature) • Use to toggle between the minimum and maximum recorded readings of indoor & outdoor temperature. • Press and hold to reset minimum and maximum record (when min or max record is shown).
LCD SCREEN AND SETTINGS: Indoor Temperature in °F Receiver Low Transmitter Low battery indicator battery indicator Outdoor Channel No. Outdoor Temperature in °F Outdoor Reception Signal icon...
* When the signal from the sensor is successfully received by the Temperature Station, this icon will be switched on. (If not successful, the icon will not be shown on the LCD). User can therefore easily see whether the last reception was successful (“ON” icon) or not (“OFF” icon). On the other hand, the short blinking of the icon shows that a reception is being done at that time.
Section 2 - OUTDOOR TEMPERATURE • Display of outdoor temperature. MANUAL SETTING: TEMPERATURE UNIT (°F) OR (°C) • User may choose to display the temperature readings in the unit of degree Fahrenheit (°F) or Celsius (°C). By pressing and holding the SET/CH key for about 3 seconds, the temperature unit of the displayed readings will shift between (°F) and (°C).
Page 22
VIEWING THE MINIMUM AND MAXIMUM READINGS: User may consult the minimum and maximum recordings for indoor temperature, and outdoor temperature by following these steps: Press the “MIN/MAX/+” key once to view the minimum indoor temperature and minimum outdoor temperature. Minimum icon...
Page 23
Press the “MIN/MAX/+” key once more to view the maximum indoor temperature and maximum outdoor temperature. Maximum icon Outdoor Channel...
Page 24
RESETTING THE MINIMUM AND MAXIMUM READINGS: User may reset the minimum and maximum temperature data to the current value by the following steps: Press the “MIN/MAX/+” key once to display the minimum data. Press and hold the “MIN/MAX/+” key for about 3 seconds to reset all the minimum / maximum data to the current values in a single action.
TEMPERATURE SENSOR: The outdoor temperature is measured and transmitted to the Temperature Station approximately every 16 seconds. The range of the temperature sensor may be affected by the temperature. Cold temperatures may decrease the transmitting distance. Please bear this in mind when placing the sensor. 915 MHz RECEPTION CHECK The Temperature Station should receive the outdoor temperature data within a few minutes after setup.
Page 26
The distance of the Temperature Station or sensor should be at least 5 to 6.5 feet (1.5 to 2 meters) away from any interfering sources such as computer monitors or TV sets. Avoid positioning the Temperature Station onto or in the immediate proximity of metal window frames.
Page 27
for 45 seconds, the frequency is changed to 920MHz and the learning is tried another 45 seconds. If still not successful the reception is tried for 45 seconds on 910MHz. This will also be done for re-synchronization. When the 915MHz signal is received correctly, do not re-open the battery cover of either the sensor or the Temperature Station, as the batteries may spring free from the contacts and force a false reset.
Page 28
possible despite the observation of these factors, all system units have to be reset (see Setting up above). POSITIONING POSITIONING THE TEMPERATURE STATION: The Temperature Station comes attached with a table stand, which provides the option of table standing the unit in addition to wall mounting.
Page 29
To wall mount: Fix a screw (not supplied) into the desired wall, leaving the head extended out by about 5mm. Hang the Temperature Station onto the screw. Remember to ensure that it locks into place before releasing.
Page 30
POSITIONING THE REMOTE TEMPERATURE SENSOR The remote temperature sensor can be placed onto any flat surface or wall mounted using the bracket which doubles as a stand or wall mount base.
Page 31
To wall mount: Secure the bracket onto a desired wall using the screws and plastic anchors. Clip the remote temperature sensor onto the bracket.
Page 32
Note: The mounting surface can affect the transmission range. If, for instance, the unit is attached to a piece of metal, it may then either reduce or increase the transmitting range. For this reason, we recommend not to place the unit on any metal surfaces or in any position where a large metal or highly polished surface is in the immediate vicinity (garage doors, double glazing, etc.).
CARE AND MAINTENANCE • Extreme temperatures, vibrations and shocks should be avoided as these may cause damage to the unit and give inaccurate forecasts and readings. • When cleaning the display and casings, use a soft damp cloth only. Do not use solvents or scouring agents as they may mark the LCD and casings.
Page 34
• Immediately remove all low powered batteries to avoid leakage and damage. Replace only with new batteries of the recommended type. • Do not make any repair attempts to the unit. Return them to their original point of purchase for repair by a qualified engineer. Opening and tampering with the unit may invalidate their guarantee.
SPECIFICATIONS Temperature measuring range Indoor 14.1ºF to +139.8ºF with 0.2ºF resolution (-9.9 to +59.9°C with 0.1°C resolution) (“OF.L” displayed if outside this range) Outdoor -39.8°F to 139.8°F with 0.2ºF resolution (-39.9°C to +59.9°C with 0.1°C resolution) (“OF.L” displayed if outside this range) Indoor Temperature checking interval every 15 seconds Outdoor data checking interval...
Page 36
Power Supply Temperature Station 2 x AAA, IEC LR3, 1.5V Temperature Sensor 1 x CR2032, 3.0V Battery life cycle (Alkaline batteries recommended) Temperature Station : approximately 24 months Temperature Sensor : approximately 12 months Dimensions (L x W x H) Temperature Station 2.29”...
Page 37
La Crosse Technology, Ltd provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. This limited warranty begins on the original date of purchase, is valid only on products purchased and used in North America and only to the original purchaser of this product.
Page 38
Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
Page 39
The owner must pay any shipping charges incurred in getting your La Crosse Technology, Ltd product to a La Crosse Technology, Ltd authorized service center. La Crosse Technology, Ltd will pay ground return shipping charges to the owner of the product to a USA address only.
Page 40
(5) damage resulting from the performance of repairs or alterations by someone other than an authorized La Crosse Technology, Ltd authorized service center; (6) units used for other than home use (7) applications and uses that this product was not intended or (8) the products inability to receive a signal due to any source of interference..
Page 41
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR INCIDENTAL, CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE OPERATION OR MALFUNCTION OF THIS PRODUCT.
Page 42
State. Some States do no allow the exclusion of consequential or incidental damages therefore the above exclusion of limitation may not apply to you. For warranty work, technical support, or information contact: La Crosse Technology, Ltd 2809 Losey Blvd. S. La Crosse, WI 54601 Phone: 608.782.1610...
Page 43
Fax: 608.796.1020 e-mail: support@lacrossetechnology.com (warranty work) sales@lacrossetechnology.com (information on other products) web: www.lacrossetechnology.com...
Page 44
Question? Instructions? Please visit: www.lacrossetechnology.com/9125 All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or duplicated or processed using electronic, mechanical or chemical procedures without written permission of the publisher. This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue.
