La Crosse Technology WS-9119U Instruction Manual

Intelligent weather station
Hide thumbs
Table of Contents

Advertisement

Quick Links

INTRODUCTION:
Congratulations on purchasing this state-of-the-art weather station as an example of excellent design and innovative
measuring technique. Featuring radio controlled time, date, calendar, weather forecast, moon phase, indoor and
outdoor temperature and humidity, air pressure and various alarm settings for different weather conditions, this weather
station will never keep you guessing on current and future weather conditions. Operation of this product is simple and
straightforward. By reading this operating manual, the user will however receive a better understanding of the Intelligent
Weather Station together with the optimum benefit of all its features.
FEATURES:
The Intelligent Weather Station
LCD Display
Weather
information text
Function Keys
•
WWVB Radio-controlled time with manual setting option
•
WWVB reception ON/OFF (user selectable)
•
12/24 hour time display
•
Time zone option ±12 hours
•
Calendar display (weekday, date, month, year)
•
Time alarm settings
•
12 Moon phases display throughout the year
•
Weather forecasting with 4 weather icons and weather tendency indicator
•
Temperature display in °F/ºC
•
Humidity display as RH%
•
Indoor temperature and humidity display with MIN/MAX and time/date of recording
•
Indoor comfort indicator
•
Low/High indoor temperature alarm
•
Low/High indoor humidity alarm
•
Outdoor temperature and humidity display with MIN/MAX and time/date of recording
•
Low/High outdoor temperature alarm
•
Low/High outdoor humidity alarm
•
Relative air pressure unit in hPa, inHg, or mmHg
•
Air pressure tendency indicator for last 36h (bar graph format)
•
Low pressure alarm
•
"Intelligent" weather information display
•
Can receive up to 3 transmitters
WS-9119U
INTELLIGENT WEATHER STATION
Instruction Manual
Hanging hole
Battery
compartment
Removable Stand
1

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology WS-9119U

Summary of Contents for La Crosse Technology WS-9119U

  • Page 1 WS-9119U INTELLIGENT WEATHER STATION Instruction Manual INTRODUCTION: Congratulations on purchasing this state-of-the-art weather station as an example of excellent design and innovative measuring technique. Featuring radio controlled time, date, calendar, weather forecast, moon phase, indoor and outdoor temperature and humidity, air pressure and various alarm settings for different weather conditions, this weather station will never keep you guessing on current and future weather conditions.
  • Page 2 • LCD contrast selectable • Low battery indicator • EL back-light • Display in 3 languages selectable: English, German and French • Wall mounting or table standing The Remote Temperature/Humidity Sensor • Remote transmission of outdoor temperature and humidity to weather station by 433 MHz signal •...

  • Page 3: Battery Change

    HOW TO INSTALL AND REPLACE BATTERIES IN THE INTELLIGENT WEATHER STATION The intelligent weather station uses 3 AA (alkaline recommended) batteries. When the batteries need to be replaced the low battery symbol will appear on the LCD. To install and replace the batteries, please follow the steps below: Insert finger or other solid object in the space at the bottom center of the battery compartment and lift up to remove the cover.

  • Page 4: Function Keys

    FUNCTION KEYS: Intelligent Weather Station: The intelligent weather station has 6 easy to use function keys on the bottom front and 1 key on the top front. ALM STOP key ALM TIME key DATA SET key CH key MAX/+ key MIN/- key SET key •...

  • Page 5: Lcd Screen

    ALM TIME key • Enter the alarm time setting mode • Stop the alarm during the time alarm or weather alarm ringing • Back-light on ALM Data key • Enter the weather alarm time setting mode • Stop the alarm during the time alarm or weather alarm ringing •...

  • Page 6: Lcd Contrast Setting

    MANUAL SETTINGS: The following manual settings can be changed when pressing and holding the SET key for approximately 4 seconds: • LCD contrast setting • 12/24 hour time display • Time zone setting • Manual time setting • Calendar setting •...

  • Page 7: Calendar Setting

    Press again the SET key to switch to the minutes. The minute digits start flashing. Use the MAX/+ or MIN/- key to set the minutes. Confirm with the SET key and enter the Calendar setting. Note: The unit will still try to receive the signal between 2:00 and 6:00 am every day despite it being manually set, if the WWVB reception function has been set ON.

  • Page 8: Relative Air Pressure Unit Setting

    RELATIVE AIR PRESSURE UNIT SETTING Flashing The relative air pressure unit can be set in inHg, hPa or mmHg unit. (default unit is inHg). Use the MAX/+ or MIN/- key to toggle between “inHg”, “hPa” or “mmHg” Confirm with the SET key and enter the Relative Pressure Value setting. Note: The default reference pressure value of the barometer is 29.91 inHg (1013 hPa).

  • Page 9: Time Alarm Setting

    TIME ALARM SETTING Time alarm icon Alarm time The alarm time can be set when pressing the ALM TIME key. Press and hold the ALM TIME key until the “ALARM” digits are shown and flash. Use the MAX/+ or MIN/- key to set the alarm ON/OFF.
  • Page 10 Use the MAX/+ or MIN/- key to set the alarm value. Press the SET key to confirm and enter the HIGH indoor temperature alarm setting. If no LOW indoor temperature setting is needed, please press the ALM DATA key to enter the HIGH indoor temperature alarm setting.
  • Page 11 III. Set the alarm value (default 86ºF) Press the SET key to enter the alarm value setting (alarm value flashing) Use the MAX/+ or MIN/- key to set the alarm value. Press the SET key to confirm and enter the LOW indoor humidity alarm setting. If no HIGH outdoor temperature setting is needed, please press the ALM DATA key to enter the LOW indoor humidity alarm setting.
  • Page 12 Set the alarm ON/OFF: Press the MAX/+ or MIN/- key to activate the alarm ON/OFF. III. Set the alarm value (default 20%) Press the SET key to enter the alarm value setting (alarm value flashing) Use the MAX/+ or MIN/- key to set the alarm value. Press the SET key to confirm and enter the HIGH outdoor humidity alarm setting.

  • Page 13: General Alarm

    WEATHER ALARM OPERATIONS WEATHER ALARMS The Weather alarms are settable for when certain weather conditions are met according to the users requirements. For example, the user can set the thresholds for the outdoor temperature to +104°F (+40°C) (high) and +14°F (-10°C) (low), whilst only enabling the high alarm and disabling the low alarm (i.e.

  • Page 14: Moon Phase

    General Alarm Icon The general indoor alarm icon will flash when indoor temperature alarm, indoor humidity alarm or air pressure alarm occur. The general outdoor alarm icon will flash when the outdoor temperature and humidity alarm occurs. To switch off the general alarm icon, press the ALM DATA key. Additionally, the trigged alarm value and time will then be displayed briefly for 2 seconds on the bottom part of the weather station LCD.
  • Page 15 WEATHER FORECAST AND WEATHER TENDENCY: WEATHER FORECASTING ICONS: There are 4 weather icons in the fourth section of LCD that can be displayed in any of the following combinations: Sunny Cloudy with sunny intervals Cloudy Rainy For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent the change in weather.

  • Page 16: Bar Graph Display

    AIR PRESSURE The 5 and 6 sections of the sections of the LCD show the relative air pressure and the air pressure history. Air pressure changes in hPa Air pressure over the last 12 hours The reference relative air pressure can be set between 28.35 to 30.72 inHg (960 to 1040hPa). See “Relative pressure value setting”...
  • Page 17 COMFORT LEVEL INDICATOR: : the “Dry” indicator will appear when the relative humidity range is lower than 45%. Comfort : the “Comfort” indicator will appear when the relative humidity range is between 45% and 65% and the temperature range is between 68ºF and 78.6ºF (20.0ºC and 25.9ºC). : the “Wet”...

  • Page 18: Outdoor Channel Re-Learn Mode

    TO RESET THE MIN/MAX VALUES TO CURRENT VALUES: To reset individual indoor and outdoor MIN/MAX values to current values: Press the MAX/+, MIN/- and CH key to select the desired MIN/MAX value. Press the SET key to reset the selected value to current value Note: To reset all indoor and outdoor MIN/MAX values to current values, press and hold the MAX/+ or MIN/- key for 3 seconds.
  • Page 19 “INTELLIGENT” WEATHER DISPLAY The “Intelligent” weather text display located at the last section of the LCD will display the weather forecast based on data received from channel 1 and the air pressure. The intelligent weather station will automatically display the following information: •...
  • Page 20 DETAILED INFORMATION SHOWN IN THE WEATHER DISPLAY: Language selected English German French Timeframe for weather Forecast period 6 hours Vorhersagedauer 6 Period prevision 6 heures forecast Stunden 12 hours 12 Stunden 12 heures 24 Stunden 24 heures 36 Stunden 36 heures 48 Stunden 48 heures Probability of weather...
  • Page 21 Avoid positioning the intelligent weather station onto or in the immediate proximity of metal doors or window frames. Using other electrical products such as headphones or speakers operating on the same signal frequency (433MHz) may prevent correct signal transmission and reception. Neighbors using electrical devices operating on the 433MHz signal frequency can also cause interference.

  • Page 22: Care And Maintenance

    Note: Before permanently fixing the remote temperature/humidity sensor wall base, pace all units in the desired locations to check that the outdoor temperature and humidity readings are receivable. In event that the signal is not received, relocate the remote temperature/humidity sensor or move them slightly as this may help the signal reception. CARE AND MAINTENANCE: •...
  • Page 23 La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd.
  • Page 24 All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or duplicated or processed using electronic, mechanical or chemical procedures without written permission of the publisher. This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue.
