Summary of Contents for Polaroid SprintScan 4000
- Page 1 SprintScan 4000 Installation Quickstart...
- Page 2 SprintScan 4000 English_______________________________3 Deutsch _____________________________17 Español _____________________________31 Français _____________________________45 Italiano _____________________________59...
-
Page 3: System Requirements
English System Requirements Macintosh Systems • Apple Macintosh or PowerBook computer with PowerPC or later processor • 32 MB available RAM • 40 MB available hard disk space • Macintosh Operating System 7.5 or later PC Systems • An IBM PC or compatible with Pentium-class processor •... -
Page 4: Unpack The Box
Contact Polaroid Technical Support or your dealer if the scanner is malfunctioning. (To contact Polaroid from within the U.S.A., call 1-800-432-5355. Outside the U.S.A., see Getting assis- tance in the online user’s guide or visit www.polaroid.com on the World Wide Web.) English... -
Page 5: Position The Scanner
English Position the Scanner Place the scanner at a convenient working height. Allow sufficient clearance front and rear for the film carriers as shown. 6 in. 16cm 14 in. 36cm... -
Page 6: Install The Software
Install the Software Turn the computer on. Close any applications that may be running. Insert the Polaroid PolaColor Insight CD into the drive. Power Mac or Power PC Windows 95, 98 or NT Select Polaroid Pola- Wait for the install Color Insight Installer. -
Page 7: Connect The Scanner To The Computer
Make sure the scanner is turned off and set the address switch to a value not used by any other device. the Computer The SprintScan 4000 requires a SCSI host adapter in your com- SCSI puter. If your computer does not have an adapter, you must install... - Page 8 Connect the SCSI cables: pins pins pins pins Place the scanner at the end of the SCSI chain or between the computer and other SCSI devices as shown in the following dia- grams. Use the shortest possible cables. Turn the computer, scanner and all other SCSI devices off Note: before connecting or disconnecting any cables.
- Page 9 English Set termination: 50-pin Centronics F SCSI connector DB-25 F SCSI connector Set the termination of the scanner and all other SCSI devices as shown in the appropriate diagram in the previous section. The last device in the SCSI chain must be terminated (or termination on), while all other devices must be unterminated (or termina- tion off).
-
Page 10: Connect The Scanner To Ac Power And Turn On
Connect the Scanner to The green LED indicates power on. The yellow LED blinks while the scanner initializes, remaining steady when the AC Power and Turn On scanner is ready. (The yellow LED also blinks while scan- ning.) Connect the power cord as shown. Turn the computer on. -
Page 11: Preview-Scan An Image
(b). The emulsion (dull) side of the film Double-click PolaColor Select Programs from should face downward. Insight. the Start menu. Point to Polaroid Pola- To start the Photoshop Color Insight, then plug in within another select PolaColor application, select Import Insight. -
Page 12: Enhance And Final-Scan The Image
Windows 95, 98 or NT Double-click PolaColor Select Programs from Insight, launching the the Windows Start PolaColor Insight pro- menu. gram. Point to Polaroid Pola- Select PolaColor Insight Color Insight and select Help from the Help User's Guide. menu. English... -
Page 13: Remove The Carrier From The Scanner
English Remove the Carrier from the Scanner Select Eject Film from the Scanner menu. -
Page 14: Limited Warranty
Installing a SCSI Host Adapter Limited Warranty The SprintScan 4000 connects to a SCSI host adapter in your Polaroid Corporation warrants the SprintScan 4000 scanner computer. Most Macintosh computers have a SCSI adapter built against defects in manufacture or workmanship for a period of in, but most IBM PC compatible computers do not. -
Page 15: Radio And Television Interference
© Copyright Polaroid Corporation, 1999. All rights reserved. • Consult the dealer or an experienced radio/TV technician for “Polaroid” and “SprintScan” are trademarks of Polaroid Corporation, Cam- help. bridge, MA, U.S.A. All other product names may be trademarks of their respective...
