- Page 1 Installation Quickstart...
-
Page 2: System Requirements
System Requirements Macintosh Systems • A Power Macintosh computer (includes Power Macintosh G3 and G4 computers) or compatible with a PowerPC processor and 64 megabytes (MB) of RAM. • Apple system software version 7.6 or later. • 400 MB of free disk space. •... -
Page 3: Unpack The Box
Do not disassemble the scanner. Doing so could result in severe electrical shock and damage to the scanner. This action may also void your warranty. Contact Polaroid Technical Support or your dealer if the scanner is malfunctioning. (To contact Polaroid from 1-800-432-5355 within the U.S.A., call... -
Page 4: Position The Scanner
3 Install the Software Turn the computer on. Close any applications that may be running. Insert the Polaroid PolaColor Insight CD into the drive. Power Mac or PowerPC Windows 95, 98 or NT Select Polaroid Wait for the install PolaColor Insight program to start. -
Page 5: Connect The Scanner To The Computer
4 Connect the Scanner to the Computer The SprintScan 45 Ultra requires a SCSI host adapter in your computer. If your computer does not have an adapter, you must install one (see page 17). If your computer is a PC-compatible with a SCSI adapter, but the adapter is connected to a hard drive or CD-ROM drive, installing a second adapter is recommended. - Page 6 SCSI address switch Power switch Power connector Connect the SCSI Cables Place the scanner at the end of the SCSI chain or between the computer and other SCSI devices as shown in the following diagrams. Use the shortest possible cables. Note:...
- Page 7 You may need additional cables or adapters to connect the scanner. Your cable must have a 50-pin Centronics M or DB-25 M connector at one end for attachment to the scanner, and the cable should be as short as possible. To determine the connector you need for attachment to your SCSI adapter, refer to instructions with the adapter.
-
Page 8: Connect The Scanner To Ac Power And Turn On
(The yellow light also blinks during scanning.) Turn the computer on. Wait for the system to install the scanner driver and display the normal desktop. Power connector English... -
Page 9: Loading The Film Carriers
6 Loading the Film Carriers The Four-Slide Film Carrier With the text facing up and the hinge at the top, open the carrier flat as shown. Place up to four mounted 35mm slides in the spaces pro- vided. Be sure the slide mounts fit properly in the recessed areas. - Page 10 Open the carrier flat. Insert a 4x5 chrome or negative so that the left edge is against the positioning pins. Position the film so the image is right-reading and right-side up (emulsion- side down). The emulsion side is the dull side. Note: Pins Close the carrier.
- Page 11 Secure the film with the two magnets provided, on the top and bottom edges. Be sure the magnets are also within the raised ridges. Place the adapter in the 4x5 carrier, sliding the notches into the pins on the left edge. The film and magnets should be face up, as shown.
- Page 12 If the film is unmounted or the mount is thin, use the slide spacer provided. Position the slide spacer on top of the slide. The film should fit snugly into the adapter. (The spacer also ensures that the image will be at the correct distance from the scanning mechanism.) Place the adapter in the 4x5 carrier, sliding the notches into the pins on the left edge.
- Page 13 Insert the carrier gently and firmly into the carrier slot as shown, until you feel it stop. Close the carrier access door. The scanner will not scan if the door is open. Do not open the carrier access door while a scan is in Note: process;...
- Page 14 8 Preview an Image Load the film or slide into the film carrier (as described previously). Insert the carrier into the scanner (as described previously). Start the PolaColor Insight program: Power Mac or PowerPC Windows 95, 98 or NT Double-click PolaColor Select Programs from Insight.
-
Page 15: Remove The Carrier
Double-click PolaColor Select Programs from Insight, launching the the Windows Start PolaColor Insight menu. program. Point to Polaroid Pola- Select PolaColor Insight Color Insight and select Help from the Help User's Guide. menu. 10 Remove the Carrier When the scan is complete, open the door and remove the carrier. -
Page 16: Installing A Scsi Host Adapter
Installing a SCSI Host Adapter The SprintScan 45 Ultra connects to a SCSI host adapter in your computer. Most Macintosh computers have a SCSI adapter built in, but most IBM PC compatible computers do not. If you must install a SCSI adapter, turn the computer off and follow instructions provided by the adapter manufacturer. -
Page 17: Radio And Television Interference
© 2000 Polaroid Corporation, Cambridge, MA 02139, U.S.A. All rights reserved. “Polaroid”, “SprintScan”, and “PolaColor” are trademarks of Polaroid Corporation. All other product names may be trademarks of their respective owners. - Page 18 Installation Quickstart Errata...
- Page 19 SprintScan 45 Ultra Installation Quickstart Errata English ......3...
-
Page 20: About This Document
About This Document This document provides corrections and updates for SprintScan 45 Ultra Installation Quickstart packaged with the scanner. System Requirements (Page 3) Macintosh Systems • A Power Macintosh computer (includes Power Macintosh G3 and G4 computers) or compatible with a PowerPC processor, and 64 megabytes (MB) of RAM. - Page 21 4 Connect the Scanner to the Computer (Page 6) The SprintScan 45 Ultra scanner SCSI address is set to 6 at the factory. Do not change it unless another device is using that address. Do not use address switch setting 7, 8 or 9.
- Page 22 "THIS SIDE UP" face upward. © 2000 Polaroid Corporation, Cambridge, MA 02139 USA. "Polaroid", "PolaColor" and "SprintScan" are trademarks of Polaroid Corporation. All other product names may be trademarks of their respective owners. All rights reserved. PL-000000-0 English...
