I MB-75 FLUSH MOUNT KIT

The MB-75 is used to mount the DS-100 DSC CON-
TROLLER flush to a flat surface such as an instrument panel.
• Supplied accessories
Clamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 set

MB-75 (OPTION)

• Instructions
q Using the template (p. 29), carefully cut a hole into the in-
strument panel (or wherever you plan to mount the con-
troller) and slide the controller through the hole on the rear
panel.
w Attach the 2 supplied bolts on either side of the DS-100
(See next page.)
