Maxon MM-6854 Application Notes

Gsm dual-band data modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MM-6854 / MM-6864
GSM Dual-Band Data Modem
MM-6854
MM-6864

Application Notes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MM-6854 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maxon MM-6854

Summary of Contents for Maxon MM-6854

  • Page 1: Application Notes

    MM-6854 / MM-6864 GSM Dual-Band Data Modem MM-6854 MM-6864 Application Notes...
  • Page 2 Any queries regarding information in this manual, please contact the Technical Services Group Leader at the above address. Information provided in this document is believed correct at time of printing but is subject to change without notice. Maxon will not accept liability for any loss, damage or costs howsoever caused as a result of the information provided.
  • Page 3 Never operate the modem without the correct Maxon antenna, or a suitable artificial load, connected. Never modify a modem, or accessory, except as instructed by Maxon in a formal communication as this may invalidate any warranty, guarantee or type approval.
  • Page 4 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page ii 03/00...

  • Page 5: Table Of Contents

    MM6854/64 Dual Band GSM Data Modem TABLE OF CONTENTS INTRODUCTION Overview How this document is organised What are the MM6854/64 Recommended Procedures Contact Information Summary SPECIFICATIONS Basic Specifications Summary SYSTEM APPLICATIONS 3.1.1 GSM / GPS Application OPERATION Introduction Network Connection 4.2.1 Inserting the SIM card Turning on the modem...
  • Page 6 MM6854/64 Dual Band GSM Data Modem 5.1.31 AT+CEER – Displays why last call was disconnected 5.1.32 AT+CMGD – Delete messages 5.1.33 AT+CMGF – Message format 5.1.34 AT+CMGL – List messages 5.1.35 AT+CMGR – Read messages 5.1.36 AT+CMGS – Send messages 5.1.37 AT+CMGW –...
  • Page 7 Figure 4-1 - Location of SIM card ........................7 Figure 4-2 - Securing of SIM card........................8 Figure 7-1 - Fixing centres for MM-6854 modem .................... 40 LIST OF TABLES Table 7-1 - 9 pin D-type socket connections ....................41 Table 7-2 - 25 pin D-type plug connections .....................
  • Page 8 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page vi 03/00...

  • Page 9: Introduction

    1 INTRODUCTION 1.1 Overview This document provides Application information for the MM-6854/64 GSM Dual-Band Data Modem and refers to software version 1.07 onwards. This first section provides a brief overview of the products. Further sections go into more detail on the various functions that are available and how they can be applied.

  • Page 10: Summary

    MM6854/64 Dual Band GSM Data Modem 1.6 Summary This section has provided a basic introduction to the products. ME 820047 Issue 1.0 Page 2 03/00...

  • Page 11: Specifications

    MM6854/64 Dual Band GSM Data Modem 2 SPECIFICATIONS 2.1 Basic Specifications Performance 91/263/EEC Specifications ETS 300 342-1 ETSI GSM 0707/05 AT commands plus Extended SMS GSM rec. 7.05 including PDU mode GSM 04.21 transparent data GSM 04.22 non-transparent data Frequency Range 890 to 960MHz 1710 to 1880MHz RF Output Power...

  • Page 12: Summary

    172mm long x 82mm wide x 30mm high Weigh 260 grams Note: Maxon Europe reserves the right to alter these specifications without prior notification as part of our continuous improvement policy. 2.2 Summary This section has outlined the basic specifications of the MM6854/64.

  • Page 13: System Applications

    MM6854/64 Dual Band GSM Data Modem 3 SYSTEM APPLICATIONS Fleet Management Construction Transportation Anti-Theft Utilities Emergency Services Refrigerated Trucks Taxis Delivery Vans Courier Companies Vending Machines Surveillance Figure 3-1 - Applications Issue 1.0 ME 820047 03/00 Page 5...

  • Page 14: Gsm / Gps Application

    MM6854/64 Dual Band GSM Data Modem 3.1.1 GSM / GPS Application One example of an application is sending data and GPS information via the GSM Network. GPS Antenna GSM Antenna Terminal GSM Modem Control Unit Mobile Equipment Computer GSM Antenna GSM Modem Host Application Figure 3-2 - GSM / GPS Application...

  • Page 15: Operation

    MM6854/64 Dual Band GSM Data Modem 4 OPERATION 4.1 Introduction This section covers the simple operation of the modems. It provides the relevant information for the user to get the modem up and running. A +9V to +28VDC power supply will be required, together with a Windows 95 PC, installed with Hyper Terminal, or similar package, a CA8360 power cable, a CA8401 antenna and a CA8361 PC serial cable.

  • Page 16: Turning On The Modem

    Alternatively, fit accessory cable CA8360 and connect power between the red and black leads. Connect a suitable antenna; the Maxon CA8401 is ideal. Note: It is important that the antenna ground is not connected to the modem ground. This will not happen where through glass antennas are used.

  • Page 17: Confirming Operation

    MM6854/64 Dual Band GSM Data Modem 4.6 Confirming Operation On Hyper Terminal, type ATD <Telephone number you want to ring> and press Carriage Return. The telephone will ring. The answer tone will be similar to the one, which you would receive, with a fax machine.
  • Page 18 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page 10 03/00...

  • Page 19: At Commands

    MM6854/64 Dual Band GSM Data Modem 5 AT COMMANDS Command Function Paragraph Switch from data mode to command mode 5.1.1 Page 12 Re-execute the last command 5.1.2 Page 12 Manual answer an incoming call 5.1.3 Page 13 Dial a telephone number 5.1.4 Page 13 ATDL...

  • Page 20: Cr> - Escape Command

    MM6854/64 Dual Band GSM Data Modem Command Function Paragraph AT+DR Data compression report 5.1.47 Page 27 AT+DS Data compression mode 5.1.48 Page 28 AT+FCLASS Select, read or test service class 5.1.49 Page 28 AT+FMI Report Manufacturer ID 5.1.50 Page 28 AT+FMM Report module ID 5.1.51...

  • Page 21: Ata - Manually Answer An Incoming Call

    MM6854/64 Dual Band GSM Data Modem 5.1.3 ATA – Manually answer an incoming call The modem does not automatically answer an incoming call (Default setting). The ATA command causes the modem to go off-hook when the modem rings: Enter Response The modem will answer the incoming call Notes: None Result codes: None...

  • Page 22: Ate - Command Echo

    MM6854/64 Dual Band GSM Data Modem 5.1.6 ATE – Command Echo This command is used to enable and disable echo. Enter Response ATE0 Disable echo. ATE1 Enable echo. Notes: None Result codes: ERROR 5.1.7 ATH – Hang up This command is used for asynchronous transmission only. If the user returns from data mode to command mode after sending an escape sequence (+++) or after disabling the DTR signal with AT&D1 option, the modem can be forced to disconnect by sending the ATH command.

  • Page 23: Ato0 - Return To Transparent Mode (Switch From Command Mode To Data Mode)

    MM6854/64 Dual Band GSM Data Modem 5.1.9 ATO0 – Return to transparent mode (switch from command mode to data mode). If you wish to interrupt the data flow only briefly, you can use the ATO0 command to return your modem to the transparent mode, i.e. the data flows once again. Enter Response ATO0...

  • Page 24: Ats2- Escape Character

    MM6854/64 Dual Band GSM Data Modem 5.1.13 ATS2- Escape character Typing ATS2? will display the decimal value of the ASCII character used as the escape character. The default value (43) corresponds to an ASCII <+>. The value 127 disables the escape process. Enter Response ATS2=127...

  • Page 25: Ats7 - Wait Time For Carrier

    MM6854/64 Dual Band GSM Data Modem 5.1.18 ATS7 – Wait time for carrier After dialling, this register sets the time that the modem must wait before hanging up if it fails to detect the remote carrier. Time is in seconds. Enter Response ATS7=60...

  • Page 26: Atx - Defines Connect Results Code Format

    MM6854/64 Dual Band GSM Data Modem 5.1.23 ATX – Defines CONNECT results code format This command is used to define the result code for CONNECT. Enter Response ATX0 Modem returns only the CONNECT code as soon as a ATX1 satisfactory connection has been set up. Modem returns only the CONNECT<SPEED>...

  • Page 27: At&F - Restore Default Configuration

    MM6854/64 Dual Band GSM Data Modem 5.1.27 AT&F – Restore default configuration This will force the modem to load the default configuration. Enter Response Notes: None. Result codes: ERROR 5.1.28 AT&V – Display current configuration The modem will display the current configuration. Enter Response Notes: None.

  • Page 28: At+Cbsts,M,P - Select Bearer Service Type

    MM6854/64 Dual Band GSM Data Modem 5.1.30 AT+CBSTs,m,p – Select bearer service type Selects the bearer service to be used when data calls are originated. Speed Not supported 300bps / V.21 1200bps / V.21 1200/75bps / V.21 2400bps / V.22 bis 2400bps / V.26 ter 4800bps / V.32 9600bps / V.32...

  • Page 29: At+Cmgf - Message Format

    MM6854/64 Dual Band GSM Data Modem 5.1.33 AT+CMGF – Message format This command allows you to define the input and output format of the short message. Enter Response AT+CMGF=0 Set to PDU mode, a complete SMS message including all header information is passed as a binary string. AT+CMGF=1 Set to text mode, all commands and responses are in ASCII characters.

  • Page 30: At+Cmgr - Read Messages

    MM6854/64 Dual Band GSM Data Modem 5.1.35 AT+CMGR – Read messages This command is used to read SMS messages. Enter Response AT+CMGR=<index>,<data> Where <index> Integer indicating the location of the SMS to be read. <data> TP user data GSM 03.40 Notes: None.

  • Page 31: At+Cmgw - Write Messages To Memory

    MM6854/64 Dual Band GSM Data Modem 5.1.37 AT+CMGW – Write messages to memory This command is used to store a SMS message into the memory. Enter Response In text mode: AT+CMGW=<oa/da><CR><t ext to be stored>CtrlZ/esc In PDU mode: AT+CMGW=<length><CR>< pdu is given>CtrlZ/esc Where <da>...

  • Page 32: At+Cnmi - New Message

    MM6854/64 Dual Band GSM Data Modem 5.1.39 AT+CNMI – New Message This command allows you to determine how the modem shall notify the user when a SMS message is received from the network operator. Enter Response AT+CNMI=<mode>,<mt>,<b Set message indication mode. m>,<ds><bfr>...

  • Page 33: At+Cpin - Enter Pin And Query Blocks

    MM6854/64 Dual Band GSM Data Modem 5.1.40 AT+CPIN – Enter PIN and query blocks This command is used to validate the PIN code, or to validate the PUK code. Enter Response AT+CPIN? Displays the current status of the PIN code. AT+CPIN=<puk>,<new_pin>...

  • Page 34: At+Crlp - Radio Link Protocol Parameters

    MM6854/64 Dual Band GSM Data Modem 5.1.43 AT+CRLP – Radio Link Protocol parameters This command lets you change parameters for the radio link protocol, used only for NON-transparent data transmission. Enter Response AT+CRLP=<up-window size>,<down window size>,<acknowledgement timer>,<retransmissions attempts>,<reset allowed>,<re-sequencing time> AT+CRLP? Displays the current settings.

  • Page 35: At+Csmp - Set Text Mode Parameters

    MM6854/64 Dual Band GSM Data Modem 5.1.46 AT+CSMP – Set text mode parameters This command is used to select additional values, when a SMS is sent to the network, or placed in storage, when text format. Enter Response AT+CSMP=<fo>,<vp> +CSMP<fo>,<vp> Where <fo>...

  • Page 36: At+Ds - Data Compression Mode

    MM6854/64 Dual Band GSM Data Modem 5.1.48 AT+DS – Data compression mode This command is used to determine the possible data compression mode between the modem and the compression negotiation with the remote modem after call set-up. Enter Response AT+DS=<p0>,<n>,<p1>,<p2 >...

  • Page 37: At+Fmm - Report Module Id

    MM6854/64 Dual Band GSM Data Modem 5.1.51 AT+FMM – Report module ID This command provides the name of the module. Enter Response Notes: None Result codes: ERROR 5.1.52 AT+FMR – Report revision This command provides the version of the module and the software creation date. Enter Response Notes: None...

  • Page 38: At+Fth - Transmit Hdlc Data With Carrier

    9600bps AT+FTM=? Displays supported values Notes: None Result codes: ERROR 5.1.57 AT+GMI – Request manufacturer ID This command provides the name of the manufacturer, i.e. Maxon. Enter Response Notes: None Result codes: ERROR 5.1.58 AT+GMM – Request model ID This command provides the model name, i.e. MM-6854.

  • Page 39: At+Gmr - Request Revision Id

    MM6854/64 Dual Band GSM Data Modem 5.1.59 AT+GMR – Request revision ID Enter Response Notes: None Result codes: ERROR 5.1.60 AT+ICF – Character framing This command is used to determine the start-stop (asynchronous) character framing that the modem shall use. Enter Response AT+ICF=<format>,<parity>...

  • Page 40: At+Ifc - Local Flow Control

    MM6854/64 Dual Band GSM Data Modem 5.1.61 AT+IFC – Local flow control This command is used to control the operation of local flow control between the modem and equipment interfacing the modem. Enter Response AT+IFC=<DCE_DTE>,<DTE _DCE> Where <DCE_DTE> None Xon/Xoff local Xon/Xoff global Where <DTE_DCE>...

  • Page 41: Cme Error

    MM6854/64 Dual Band GSM Data Modem 5.1.64 CME ERROR<n> <n> Phone failure Operation not allowed Operation not supported SIM not inserted SIM PIN required SIM PUK required SIM failure Incorrect password Dial string too long No network service 5.1.65 CMS ERROR<n> <n>...

  • Page 42: S Register Summary

    MM6854/64 Dual Band GSM Data Modem 5.1.66 S Register Summary Register Function Default Value Rings to auto answer Ring counter Escape character CR character termination character LF character Backspace character Pause before blind dialling Wait time for carrier Sets number of seconds to wait when comma dial modifier encountered in dial string Wait time before disconnection Escape code guard time...

  • Page 43: Summary

    MM6854/64 Dual Band GSM Data Modem 5.2 Summary This section has listed all of the AT commands, which are used by the modem. Issue 1.0 ME 820047 03/00 Page 35...
  • Page 44 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page 36 03/00...

  • Page 45: Debugging & Indicator Lights

    Missed calls, low battery, Two Flashes, Off, Two Flashes SMS messages etc. Alert Incoming call Four Flashes, Off, Four Flashes 6.1 Summary This section has described the indicator functions on the MM-6854 modem. Issue 1.0 ME 820047 03/00 Page 37...
  • Page 46 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page 38 03/00...

  • Page 47: Installation

    The power supply should be in the range of +9V to +28VDC. Maxon can supply, as an accessory, a mains power supply which is capable of powering MM-6854 modems. This power supply has the part number CA6823 and is a 12V, 1A power supply. 7.4 Fusing It is strongly suggested that fuses for the data modem, and any associated equipment, are located in a place away from the main fusebox.

  • Page 48: Cabling

    If possible, run RF cables separately from other cables and keep RF cables apart from one another to avoid interference / coupling. 7.6 Fixing We recommend that the MM-6854 data modem is securely fixed to a surface, either directly, or with a suitable bracket. The fixing hole dimensions are shown below: 163mm 2 off holes 6.7mm dia.

  • Page 49: Connections

    Reserved for future use Reserved for future use Reserved for future use Table 7-2 - 25 pin D-type plug connections 7.8 Summary This section has briefly covered the installation of the MM-6854 data modem. Issue 1.0 ME 820047 03/00 Page 41...
  • Page 50 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page 42 03/00...

  • Page 51: Appendices

    MM6854/64 Dual Band GSM Data Modem 8 APPENDICES 8.1 Setting up Windows Modem interface Follow these step-by-step instructions to set up the Windows Modem interface for use with TAPI interface software (such as WinFax Pro). 8.1.1 Open up the Control Panel 8.1.2 Double click on the modem icon Issue 1.0 ME 820047...

  • Page 52: Highlight The Don't Detect My Modem Box

    MM6854/64 Dual Band GSM Data Modem 8.1.3 Highlight the don’t detect my modem box 8.1.4 Select the standard 19200 modem ME 820047 Issue 1.0 Page 44 03/00...

  • Page 53: Select The Appropriate Com Port

    MM6854/64 Dual Band GSM Data Modem 8.1.5 Select the appropriate COM port 8.1.6 Set the location information Issue 1.0 ME 820047 03/00 Page 45...

  • Page 54: Finish Installation

    MM6854/64 Dual Band GSM Data Modem 8.1.7 Finish Installation 8.1.8 Select Properties ME 820047 Issue 1.0 Page 46 03/00...

  • Page 55: Select Connection

    MM6854/64 Dual Band GSM Data Modem 8.1.9 Select Connection 8.1.10 Set Data Bits, Parity and Stop bits Select Advanced Issue 1.0 ME 820047 03/00 Page 47...

  • Page 56: Select Flow Control And Software (Xon/Xoff)

    MM6854/64 Dual Band GSM Data Modem 8.1.11 Select Flow Control and Software (XON/XOFF) Note: Some applications do not use Software Flow Control, therefore set flow control to Hardware. In whichever case, the hardware or the software must provide flow control otherwise data will be lost. 8.1.12 RS-232 In order to turn on the modem, Pin 4 (DTR) must be pulled high.

  • Page 57: Setting Up Hyper Terminal

    MM6854/64 Dual Band GSM Data Modem 8.2 Setting up Hyper Terminal Hyper Terminal is a very simple terminal package which can be used to send simple commands to / from the modem. 8.2.1 Select Hyper Terminal from Programs Menu Issue 1.0 ME 820047 03/00 Page 49...

  • Page 58: Select Hyper Terminal

    MM6854/64 Dual Band GSM Data Modem 8.2.2 Select Hyper Terminal Double click to open Hyper Terminal. 8.2.3 Select Properties ME 820047 Issue 1.0 Page 50 03/00...

  • Page 59: Set Port

    MM6854/64 Dual Band GSM Data Modem 8.2.4 Set Port 8.2.5 Port Settings Issue 1.0 ME 820047 03/00 Page 51...

  • Page 60: Properties

    MM6854/64 Dual Band GSM Data Modem 8.2.6 Properties Set Beep, if required. 8.2.7 ASCII settings Append line feeds, send line ends and wrap lines, if required. ME 820047 Issue 1.0 Page 52 03/00...

  • Page 61: Setting Up Win Fax Pro

    MM6854/64 Dual Band GSM Data Modem 8.3 Setting up Win Fax Pro The following section illustrates how to set up Win Fax Pro. Other Fax software is available and this section should not be taken as an endorsement of Win Fax Pro. 8.3.1 Communication Setup Ensure that the computer modem settings are set to 19200,8,n,1, see Sections 10.1.9 and 10.1.10.
  • Page 62 MM6854/64 Dual Band GSM Data Modem Check Modem is Standard 19200, if not, go to 10.1.4. Select Properties Check that the following setting are made: ME 820047 Issue 1.0 Page 54 03/00...

  • Page 63: Accessories

    MM6854/64 Dual Band GSM Data Modem 8.4 Accessories Description of Accessory Maxon Part Number 5 metre Power Lead CA8360 9 way D-type Male to Female RS-232 Interface Lead CA8361 Dual-band GSM Antenna for in-vehicle mounting CA8401 12V 1 Amp Mains Power Supply fitted with Euro connector...
  • Page 64 MM6854/64 Dual Band GSM Data Modem ME 820047 Issue 1.0 Page 56 03/00...

  • Page 65: Glossary

    MM6854/64 Dual Band GSM Data Modem 9 GLOSSARY Abbreviation Meaning Hayes AT modem serial command set commonly used for land line modems Command Interpreter. Data Terminal Equipment Data Terminal Ready Global Positioning System Global System Mobile Input / Output Light Emitting Diode Subscriber Identity Module Short Message Service SMSC...
