Vinotemp VT-100 WINEDISP4 Owner's Manual

88-bottle dual-zone wine cooler & dispenser
Hide thumbs
Table of Contents

Advertisement

Quick Links

A P R O
U D H E R I T A G E O F E X P E R I E N C E &
Q U A L I T Y
8 8 - B o t t l e D u a l - Z o n e
W i n e C o o l e r & D i s p e n s e r
V T - 1 0 0 W I N E D I S P 4
O
W N E R ' S
M A N U A
L
W W W . V I N O T E M P . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT-100 WINEDISP4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vinotemp VT-100 WINEDISP4

Summary of Contents for Vinotemp VT-100 WINEDISP4

  • Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y 8 8 - B o t t l e D u a l - Z o n e W i n e C o o l e r &...

  • Page 2: Your Wine Cellar

    Your Wine Cellar This cooler can be used for storing and serving wine. The unit has glass doors and soft interior lights that elegantly display your wine. Serving Wine Storing wine at the proper temperature is important. To preserve them as long as possible, wine should be stored at approximately 55°F.
  • Page 3 Upon receipt and inspection of unit, the power cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. Let the unit rest, UNPLUGGED for 24 hours once you have it placed in your home READ AND SAVE THESE INSTRUCTIONS BEFORE USING APPLIANCE To register your product, visit: http://www.vinotemp.com/Warranty.aspx...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS........5  ELECTRICAL CONNECTION............6  GAS CYLINDER SAFE HANDLING..........7  KEY FEATURES................8  PARTS & SPECIFICATIONS............9  INSTALLATION INSTRUCTIONS..........11  CONTROL PANEL................14  STORING YOUR WINE..............16  DISPENSING OPERATION............20  CARE INSTRUCTIONS..............24  TROUBLESHOOTING GUIDE.............26  WIRING DIAGRAMS..............29  TERMS OF SALE AND WARRANTY...........31  SERVICE & IMPORTANT NOTICE..........32  W W W .

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Improper use of the power cord plug can result in the risk of electrical shock, property damage and personal injury or death. • Do not operate this appliance with a damaged, frayed or cracked power cord. • To protect against electric shock, do not immerse appliance, plug and cord in water or other liquids.

  • Page 6: Electrical Connection

    • Destroy or recycle carton, plastic bags and any exterior wrapping materials if you don’t need them. These items may cause suffocation. • Risk of child entrapment and suffocation - Before you throw away this or any old appliance, remove the doors and leave the shelves in place, so that children may not easily climb inside.

  • Page 7: Gas Cylinder Safe Handling

    GAS CYLINDER SAFE HANDLING CAUTION: Gas cylinders are under very high pressure, follow these safety instructions. Refillable Cylinder (Optional Item) • Gas cylinder contents are under high pressure. • Ensure contents of cylinders are properly identified. • Do not destroy or remove identification tags or labels. •...

  • Page 8: Key Features

    KEY FEATURES • VT-100WINEDISP4 keeps opened wine fresh from oxidization for weeks through use of noble gas such as argon and nitrogen. • The combined dispensing and storing design displays and dispenses up to 4 opened wine bottles, while chilling 34 and 54 additional bottles in the independent upper and lower zones.

  • Page 9: Parts & Specifications

    PARTS & SPECIFICATIONS Model No VT-100WINEDISP4 Upper Zone Display Capacity 4 Bottles Upper Zone Storing Capacity 30 Bottles Lower Zone Storing Capacity 54 Bottles Inside Temperature Range 40-65°F Ambient Temperature Range 55-90°F Dispensing Gas Pressure 3-5 (PSI) Electrical Rating 120V/60Hz/1PH/2.5 A Unit Dimensions 23.5”W x 23.875”D x 63.625”H Leveling Leg Range...
  • Page 10 Product Dimensions • The width of the unit from edge to edge is 23 1/2”. • The depth from the front of the door to the back of the unit is 22 3/8” • The depth of the unit, less the door, is 20 1/2” •...

  • Page 11: Installation Instructions

    INSTALLATION INSTRUCTIONS Location Requirements • Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc). This unit is intended for indoor, household use only. Do not install the unit in moist areas. • Do not install the unit where the ambient temperature range will be below 55°F or above 90°F.
  • Page 12 Flush Door Installation (Leveling Legs Fully Extended) Outstanding Door Installation (Leveling Legs Fully Extended) W W W . V I N O T E M P . C O M...
  • Page 13 Door Opening • Allow 1/2” clearance (24 5/8”) on each side for 90° opening if flush door installation. • Allow 1” clearance (25 5/8”) on each side for 150° opening if flush door installation. • Clearance is not required for door opening if it is freestanding door installation. Flush Door Installation Freestanding Door Installation 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1...

  • Page 14: Control Panel

    CONTROL PANEL Do not attempt to turn the unit on within 5 minutes after being unplugged, turned off or if a power failure has occurred. Otherwise, the compressor won’t start. Display NOTE: The inside temperature may differ from the set temperature when unit is first turned on or bottles are being loaded.
  • Page 15 • ON/OFF POWER To turn the unit on/off, press and hold button for 5 seconds. This on/off switch does not disconnect the unit from the power outlet. • LOCK/UNLOCK BUTTON The up/down & degree buttons will be locked automatically after 2 minutes of inactivity.

  • Page 16: Storing Your Wine

    STORING YOUR WINE The unit is for adult use only. Keep out of reach of children. Keep doors locked at all times. Unlock/Lock Door To unlock the door, push the key in while you turn it counter-clockwise. To lock the door, turn it clockwise. There is a door supporter for the upper door;...
  • Page 17 Upper Zone 6 Bottle Shelf Upper Zone 3 Bottle Shelf Lower Zone 8 Bottle Shelf Lower Zone 6 Bottle Shelf 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .
  • Page 18 Placing Shelves Upper Zone Shelf Placement Lift the shelf above the stopper and align the notch to stopper, then place the shelf on the supporter. Lower Zone Shelf Placement Align the notch to stopper, move the glide’s tab into the hole at the bottom of the shelf holder, and then push down the shelf holder.
  • Page 19 Pulling Out Shelves CAUTION: Do not pull out shelves if the door is opened less than 90°. The pull-out shelves allow wine bottles to be viewed and removed easily. There are shelf stoppers that prevent the shelves from falling. Lower Zone Pull-Out Shelf 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .

  • Page 20: Dispensing Operation

    DISPENSING OPERATION CAUTION: Do not over tighten the stopper-dispenser, otherwise it may break. If there is no bottle in use, always disconnect the coupling plugs and sockets at the stopper-dispenser, otherwise gas will escape. Upper Zone Dispensing Parts W W W . V I N O T E M P . C O M...
  • Page 21 Installing the Wine Spout • Push the wine spout through the spout hole until it is engaged. Installing the Disposable Cylinder • Hold the pressure regulator and then turn the cylinder clockwise until it is tightened. • Place the assembled parts on the top of the electrical box and secure the parts using provided the zip tie.
  • Page 22 Connecting Refillable Cylinder NOTE: The refillable cylinder is shipped empty. Fill with gas before use. • Secure large cylinders with a chain or strap positioned around the upper third of the cylinder • Small cylinders may be placed in the holder at the back of the unit or may be put on their side and blocked to prevent from rolling.
  • Page 23 • Hold the stopper-dispenser and press the latch at the coupling socket to disconnect the coupling plugs. • Remove the bottle and stopper-dispenser from the rack. • Hold the stopper-dispenser and turn the thumbwheel counter-clockwise all the way to loosen it from the bottle neck. •...

  • Page 24: Care Instructions

    Keeping Spout Clean • Use the spout cap to cover it if the unit is not in use. • To remove the cap, press the release ring while pulling the cap. Replacing Stopper-Dispenser NOTE: Replace the stopper-dispenser with a new one If it is damaged, All pipe thread connections require Teflon sealant.

  • Page 25: Normal Operating Sounds

    Clean Condenser • The condenser coil is black serpentine tubing that is located behind the front grille. Condenser coil may need to be cleaned at least every 6 months. • Use a vacuum cleaner with an extended attachment to clean the condenser coil when it is dusty or dirty.

  • Page 26: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Refrigeration System Complaint Possible Causes Response Unit not running a) On/off button not turned on a) Press on/off button for 5 seconds b) Setting higher than ambient b) Lower temperature setting temperature c) Defrost or anti-short cycle mode c) Wait for time elapsing d) Power cord unplugged e) No power to unit...
  • Page 27 Not cooling but a) Bad evaporator air flow a) Check for restrictions compressor b) Bad evaporator fan b) Check for fan turning running c) Refrigerant leakage c) Call service regarding loss of refrigerant d) Refrigeration system restriction d) Call service to check restrictions Evaporator a) Bad evaporator air flow a) Check for restrictions...
  • Page 28 Dispensing System Complaint Possible Causes Response a) Gas empty a) Check pressure gauge or push the coupling plug to see if gas is escaping. b) Gas tubing blockage b) Check for kinked tubes or press dispensing button to see if gas is escaping Unit not c) Stopper/dispenser not...

  • Page 29: Wiring Diagrams

    WIRING DIAGRAMS Cooling System Wiring Diagram Dispensing System Wiring Diagram 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .
  • Page 30 W W W . V I N O T E M P . C O M...

  • Page 31: Terms Of Sale And Warranty

    Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any third party repair facility must be pre-approved before providing parts free of charge. This limited...

  • Page 32: Service & Important Notice

    Rancho Dominguez, CA 90221 www.Vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
