- Page 1 User’s Manual IP Telephony Gateway Model No.: SP5001C, SP5001D, SP5002A, SP5012A World Wide Web: www.micronet.com.tw ; www.micronet.info...
- Page 2 Provide command reference of Web Interface for advanced setting. Chapter 5. IVR/Keypad Management Provide instructions on configuring the IP Telephony gateway via Keypad on the phone set. Chapter 6. Specification List the specification of the gateway in detail. Online Upgrade Please refer to http://www.micronet.info/ for additional support.
-
Page 3: Table Of Contents
Table of Content 1. ..Introduction....................4 Key Features ....................5 Physical Description ..................6 Application....................10 2. ..Startup ....................13 Login into the System ................. 13 Network Configuration................15 SIP Configuration ..................17 VPN Configuration..................19 DDNS ......................21 3. ..Operation....................22 Make a Call .................... - Page 4 4.3.7 DMZ * ......................34 4.3.8 Virtual Server * ....................34 SIP Settings....................35 4.4.1 Service Domain ..................... 35 4.4.2 Port Settings....................35 4.4.3 Codec Settings ....................35 4.4.4 Codec ID Settings ..................36 4.4.5 DTMF Setting ....................36 4.4.6 RPort Setting ....................
-
Page 5: Introduction
1. Introduction Micronet SP5001C, SP5001D, SP5002A and SP5012A IP Telephony Gateway is designed to connect standard telephone devices to IP-based telephony networks, providing users with high-quality VoIP service. SP5001C / SP5002A provides: ● 1/2 FXS port(s) for phone set, FAX machine, or PBX’s trunk SP5001D provides: ●... -
Page 6: Key Features
1.1 Key Features Compliant with IETF SIP standards Provide 2 10/100M RJ-45 ports for WAN and LAN connection Support G.729a/b, G.711a/µ-law, and G.726 codecs Support up to 3 SIP service domains Support STUN and Outbound proxy for NAT traversal Support VAD, CNG, EC, and Adaptive Jitter Buffer Support FSK / DTMF caller ID display Support Call Hold / Call Waiting / Call Forward Support 3-way conference... -
Page 7: Physical Description
1.2 Physical Description SP5001C: SP5001C Front Panel Status Description On/Green Power On STATUS On/Amber Line Registered On/Amber Phone set off-hook On/Green Link On On/Green Link On SP5001C Rear Panel --------------------------------------------------------------------------------------------------- Factory default button. Press and hold for 5 seconds to reset... - Page 8 SP5001D: SP5001D Front Panel Status Description On/Green Power On PSTN On/Amber PSTN mode / VoIP Unregistered On/Amber Phone set off-hook On/Green Link On On/Green Link On SP5001D Rear Panel --------------------------------------------------------------------------------------------------- Factory default button. Press and hold for 5 seconds to reset RESET RJ-45 port of 10/100M for connecting to modem RJ-45 port of 10/100M for connecting to PC or hub/switch that...
- Page 9 SP5002A: SP5002A Front Panel Status Description On/Green Power On TEL1 On/Amber Line Registered TEL2 On/Amber Line Registered On/Green Link On On/Green Link On SP5002A Rear Panel --------------------------------------------------------------------------------------------------- Factory default button. Press and hold for 5 seconds to reset RESET RJ-45 port of 10/100M for connecting to modem RJ-45 port of 10/100M for connecting to PC or hub/switch that connects PCs RJ-11 port for connecting to phone set or PBX trunk...
- Page 10 SP5012A: SP5012A Front Panel Status Description On/Green Power On On/Amber Line Registered LINE On/Amber Line Registered On/Green Link On On/Green Link On SP5012A Rear Panel --------------------------------------------------------------------------------------------------- Factory default button. Press and hold for 5 seconds to reset RESET RJ-45 port of 10/100M for connecting to modem RJ-45 port of 10/100M for connecting to PC or hub/switch that connects PCs RJ-11 port for connecting to PSTN or PBX extension...
-
Page 11: Application
1.3 Application SP5001C: ● 1 RJ-11 FXS port is provided for phone set or PBX's trunk line connection ● 2 RJ-45 ports of 10/100M are provided for WAN and LAN connection ● The IP telephony gateway can share Internet access with LAN clients SP5002A: ●... - Page 12 SP5001D: ● 1 RJ-11 FXS port is provided for phone set or PBX's trunk line connection ● 1 RJ-11 PSTN port is provided to tranceive PSTN calls as backup even if VoIP fails ● 2 RJ-45 ports of 10/100M are provided for WAN and LAN connection ●...
- Page 13 VPN (Virtual Private Network) The IP telephony gateway series supports PPTP client for VPN function. It can establish VPN tunnel with PPTP server, and get access to the peer private network as if it is located in the same LAN. For special condition that SIP proxy server is located in the private network of CO site, the gateway can register, and request a phone call via the VPN tunnel.
-
Page 14: Startup
2. Startup 2.1 Login into the System The embedded web configuration allows you to use a web browser to manage the IP Telephony gateway. Step 1. Connect LAN port to your managing PC. Or, connect the gateway with PC by hub/switch. Step 2. -
Page 16: Network Configuration
2.2 Network Configuration By default, the gateway is in NAT mode (router mode) and can share Internet access with PCs. Go to [ Network / WAN Settings ], and configure WAN setting according to actual condition. In default IP type of DHCP client, it requests necessary IP information from your ISP automatically. - Page 17 ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- LAN Mode Bridge: pure VoIP gateway NAT: VoIP router IP Type Select Fixed IP, DHCP (default), or PPPoE IP address provided by ISP Mask Subnet mask provided by ISP Gateway ISP’s IP address gateway DNS Server1/2 IP address of primary/secondary DNS server MAC address PPPoE...
-
Page 18: Sip Configuration
2.3 SIP Configuration Go to [ ]. Each port can be configured to SIP Settings / Service Domain register 3 different service domains. ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- Phone No. Select specific port to configure Active Select “On” to activate User Name IP telephony number of the line Register Name User’s ID... - Page 19 ----------------------------------------------------------------------------------------------------- Note: Please save and reboot the system to take effect. Go to [ Save Change ] to save configuration, and the system will reboot automatically. -----------------------------------------------------------------------------------------------------...
-
Page 20: Vpn Configuration
2.4 VPN Configuration IP telephony gateway supports PPTP client for VPN. It can establish VPN tunnel with PPTP server. Go to [ ], and set PPTP Network / PPTP Settings server address, and authentication information (username, password). ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- PPTP Server Set IP address of PPTP server... - Page 21 After tunnel is established, the gateway gets one private IP address (Interface 2) from PPTP server as shown in [ Network / Status...
-
Page 22: Ddns
2.5 DDNS DDNS allows you to map the static domain name to a dynamic IP address. You must get an account, password and your static domain name from the DDNS service providers. ● DDNS makes the gateway accessible for other client to call in P2P (peer-to-peer) mode, when the IP address is dynamic. -
Page 23: Operation
Operation 3.1 Make a Call By default, call is sent via the first registrar server only. The telephone number of clients in the second/third service domain will be not accessible. Make a Call Press <telephone_number> + # ----------------------------------------------------------------------------------------------------- Note: ● Once the first registration fails, the second realm will be activated. -
Page 24: Speed Dial / P2P Call
3.2 Speed Dial / P2P call Speed dial Press <index> + # Go to [ ]. User can create 10 entries (0~9) Phone Book / Speed Dial Setting in Speed Dial Phone List. ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- Position Speed dial index, 0~9 Name Alias of the specific entry It can be…... -
Page 25: Call Forward
3.3 Call Forward Go to [ ]. There are 3 selections in Forward type. Phone Setting / Call Forward User must select the condition under which to forward calls. ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- All Forward Forward the call in any conditions ●... -
Page 26: Call Hold / Call Waiting / Conference
3.4 Call Hold / Call Waiting / Conference The IP telephony gateway provides telephony features, as call hold, call waiting, and 3-way conference. ● Call Hold: Hold a existing call Call waiting: Hold a existing call, and answer a new incoming call ●... -
Page 27: Fax
3.5 FAX Send FAX ● Press <fax_number> to connect fax machine ● Start to send FAX T.38 FAX: Go to [ ]. Click on “On” and Phone Setting / T.38 (FAX) Setting enable T.38 to tranceive FAX over IP. In-band FAX: disable T.38 and choose G.711 codec as top priority. Please refer to the section 4.4.3 Codec Settings. -
Page 28: Web Administration
4. Web Administration 4.1 Phone Book Please refer to the section 3.2 Speed Dial / P2P call. 4.2 Phone Setting 4.2.1 Call Forward Please refer to the section 3.3 Call Forward. 4.2.2 SNTP Settings User can set up the primary and second SNTP Server IP Address, to get the date/time information. -
Page 29: Block Settings
4.2.4 Block Settings User can set up the gateway to block incoming calls and the period. 4.2.5 Caller ID User can set the device to show Caller ID in your PSTN Phone. The gateway supports FSK and DTMF. 4.2.6 Dial Plan Setting User can set dialing plan and timeout to send a phone call after dialing number is input. - Page 30 ----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- Replace Prefix code On: enable “Replace rule” Off: disable “Replace rule” Replace rule Replace matched prefix with another Dial Plan If dialed numbers match the rule, numbers is sent out. If not, numbers would not be sent out. Plan with prefix “0” is invalid Auto Prefix Prepend the prefix before the dialed number is sent out...
-
Page 31: Flash Time Setting
* means: keypad＊ on the phone x means: digit 0, 1, 2~9 # means: keypad # on the phone + means: or Auto prefix: 02 (0000~9999) Input Sent out 22183656 02-22183656 82265630 02-82265630 Prefix Unset Plan: 1 + 0 + xxxxxx With prefix “0”, auto prefix “02”... -
Page 32: Fax) Setting
4.2.9 T.38 (FAX) Setting Please refer to the section 3.5 FAX. -
Page 33: Network
4.3 Network 4.3.1 Status User can check the current Network setting. 4.3.2 WAN Settings Please refer to the section 2.2 Network Configuration. 4.3.3 LAN Settings User can configure for LAN clients. -
Page 34: Ddns Settings
----------------------------------------------------------------------------------------------------- Parameter Description ----------------------------------------------------------------------------------------------------- IP address of LAN port. Default gateway IP of LAN clients in the local network Mask Subnet mask MAC address DHCP Server “On” means DCHP server enabled. By enabling the DHCP server, the router will automatically give your LAN clients an IP address Start/End IP The IP range is released by DHCP... -
Page 35: Pptp Settings
4.3.6 PPTP Settings Please refer to the section 2.4 VPN Configuration. 4.3.7 DMZ Open another page http://192.168.123.1:9999/dmzset.htm. With the function enabled, the gateway will re-direct all packets going to your WAN port IP address to a particular IP address in your LAN. will be available in the later version. -
Page 36: Sip Settings
4.4 SIP Settings 4.4.1 Service Domain Please refer to the section 2.3 SIP Configuration. 4.4.2 Port Settings User can set up SIP and RTP ports. 4.4.3 Codec Settings User can set up the Codec priority, RTP packet length, and VAD function. Please follow service provider’s suggestion to configure. -
Page 37: Codec Id Settings
4.4.4 Codec ID Settings User can set up codec ID for different codec. This ID represents the codec used to encode data in the Track. 4.4.5 DTMF Setting User can set up the method of DTMF transmission: In-band, RFC2833, or SIP Info. -
Page 38: Other Settings
Symmetric Response Routing. This behavior is not desirable in many cases. Please configure it according to your service provider. 4.4.7 Other Settings User can set up the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. ----------------------------------------------------------------------------------------------------- Parameter Description -----------------------------------------------------------------------------------------------------... -
Page 39: Nat Trans. / Stun
EF (Expedited Forwarding). ----------------------------------------------------------------------------------------------------- SIP expire time the time used to inform proxy server of the valid duration of registration information. ----------------------------------------------------------------------------------------------------- 4.5 NAT Trans. / STUN Please refer to the section 2.3 SIP Configuration. -
Page 40: Others
4.6 Others 4.6.1 Auto Config User can disable Auto Configuration or enable the function by TFTP/FTP. Please contact with your service provider for necessary information. 4.6.2 ICMP Setting User can set the gateway to reply ICMP echo request or not. Setting this function to “ON”, you will get reply when you PING this gateway. -
Page 41: System Auth
4.7 System Auth. Change system login name and password. 4.8 Save Change Click on the Save button. The system will automatically restart and the new setting will take effect. 4.9 Update 4.9.1 New Firmware User can upgrade the system via TFTP or HTTP in this page. Please upgrade the firmware by the following steps: ----------------------------------------------------------------------------------------------------- Parameter... -
Page 42: Default Setting
Click on the Update button to start upgrading. 4.9.2 Default Setting Click on the Restore button. Then, the system will restore factory default setting and automatically restart again. Changed network and SIP setting will be removed. 4.10 Reboot Press the reboot button. The system will restart automatically. -
Page 43: Ivr / Keypad Management
5. IVR / Keypad Management You can use the PSTN phone keypad to operate the IP Telephony gateway. Please follow the instruction to configure. IVR Action IVR Menu Parameter(s) Notes Choice Press 0# can pass relay to Dial out from PSTN Line, user can dial None PSTN Line... - Page 44 Use the * (star) key when entering a decimal point. Enter value-using numbers on the Set Network #113xxx*xxx*x telephone keypad. Must set Static IP first. Mask xx*xxx# Use the * (star) key when entering a decimal point. Enter IP address using numbers on the Set Gateway IP #114xxx*xxx*x...
-
Page 45: Specification
6. Specification Model SP5001C SP5001D SP5002A SP5012A Standard IETF SIP (RFC3261) Telephone Port 1 FXS 1 FXS 2 FXS 1 FXS 1 PSTN (lifeline) 1 FXO Ethernet Port 2 10/100M ports for WAN and LAN connection Voice Codec: ● G.711: 64k bit/s (PCM) ●...
