MicroNet SP5004P User Manual

Ip telephony gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's Manual
IP Telephony Gateway
Model No.: SP5004P/SP5008/SP5018/SP5058
Website:
http://www.micronet.info
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP5004P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MicroNet SP5004P

Summary of Contents for MicroNet SP5004P

  • Page 1 User’s Manual IP Telephony Gateway Model No.: SP5004P/SP5008/SP5018/SP5058 Website: http://www.micronet.info...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ................. 3 1.1 Key Features ....................... 4 1.2 Physical Description ..................5 1.3 Application ......................9 2. STARTUP...................11 2.1 Login into the System ..................11 2.2 Network Configuration ..................11 2.3 SIP/H323 Configuration ..................22 3.
  • Page 3 5. SPECIFICATION ................124...

  • Page 4: Introduction

    H.323/SIP and QoS all in one solution. A major advantage of VoIP is that it place low-cost calls to regular phones all over the world from your gateway. So, your savings are not limited to calls to other Micronet devices. SP5004P provides: 4 FXS port(s) for phone set, FAX machine, or PBX’s trunk...

  • Page 5: Key Features

    1.1 Key Features ● Dual protocols: SIP & H.323 co-existing ● 4/8 x RJ-11 FXS/FXO ports ● Provide 4 RJ-11 PSTN Lifelines (SP5004P) ● G.711A/µ-law, G.723.1, G.726 and G.729 codecs ● Support 4 service registrations ● Support multiple dial plans & call hunting group ●...

  • Page 6: Physical Description

    1.2 Physical Description Front Panel SP5008 SP5018 SP5058 SP5004P...
  • Page 7 LED Indicators Status Indication POWER On / Green The Power is on STATUS Blink / Green Booting up for self test READY Blink / Blue Gateway reg. failure Constant / Blue Gateway reg. successes PHONE On / Green Busy / Off-hook Available / On-hook LINE On / Green...

  • Page 8: Rear Panel

    Rear Panel SP5008 SP5018 SP5058 SP5004P...
  • Page 9 SP5058: FXO=P1~P8 FXS / PSTN combo RJ-11 ports. P1/L1~P4/L4 Note: Please use 2-in-1 RJ-11 cable “C702” to connect to (SP5004P) PABX’s trunk and PSTN line respectively Clear all settings and restore them to the initial values present RESET when the device was purchased. After performing the reset, make sure to redefine the IP settings for the device in the ‘Connection’.

  • Page 10: Application

    1.3 Application SP5004P/5008/5018/5058 can be used in some scenarios Scenarios A, FXS Gateway Configuration PBX Scenario, VoIP Scenarios B, FXO/FXS Gateway Configuration PBX Scenario, VoIP Scenarios C, FXO Gateway Configuration PBX Scenario, VoIP...
  • Page 11 Scenarios D, FXS/PSTN Gateway Configuration PBX Scenario, VoIP Life-line fallback to PSTN in case of power failure/ network disruption...

  • Page 12: Startup

    2. Startup 2.1 Login into the System The Gateway provide user friendly Web interface to let you configure the router function Please go to “Control Panel” → ”Network”. In the “Configure” page, choose the TCP/IP of LAN card, and press “Properties” please choose “Obtain IP Address Automatically” Launch your browser and open the WEB-UI page as http://192.168.22.1...
  • Page 13 Click “WAN” option below “System Setup” item: Please select the type of Internet connection you have and set up the router to use the IP Address Dynamic IP Address, Static IP Address , PPPoE , PPTP or L2TP connection. If your ISP has not given you an IP address, please select Dynamic IP Address (default).
  • Page 14 There are five ways to connect to the Internet. They are Dynamic IP, Static IP, PPPoE, PPTP and L2TP. The cable modem ISP usually requests you to obtain the WAN IP dynamically. Some ISPs request you to fill the host name. To do this, please go to “System/System Settings”...
  • Page 15 Clone MAC Address This button is use to detect the PC, which is browsing this page, and make its MAC address to be the MAC address to clone. BigPond: Only for AUSTRALIA Telstra Bigpond ISP. B. Static IP IP address assigned by your ISP Set the IP address that assigned by the ISP.
  • Page 16 This page is the PPPoE configuration page. Most of the ISPs request the user to connect to central office (CO) side via PPPoE, acronym of Point-to-Point Protocol over Ethernet, which provides authentication, authorization and accounting. User Name Enter the user name provided by your ISP to identify the computer using PPPoE.
  • Page 17 PPPoE MTU should be set between 546 and 1492. Maximum Idle Time (60-3600) Set a period of time to disconnect PPPoE connection, when user’s idle time greater than it. The Maximum Idle Time is only worked on the auto-connect mode. It makes no effect on manual-on mode and keep-alive mode (see Connection Mode).
  • Page 18 D. PPTP This page is the PPTP configuration page. Acronym of PPP Tunneling Protocol of Ethernet , which provides authentication, authorization and accounting .This PPTP screen is only useful if using the PPTP connection method . WAN Interface Settings The PPTP is support only for Dynamic IP and Static IP Mode can be used. Please choise your WAN settings is in which Mode .
  • Page 19 address to be the MAC address to clone. PPTP Settings PPTP Account Enter the PPTP account provided by your PPTP server to definition. PPTP Password Enter the password provided by your PPTP server to definition. Please retype your PPTP password Retype the password to make sure type correct password.
  • Page 20 MPPE: multiple PPTP E. L2TP This page is the L2TP configuration page. Acronym of Layer 2 Tunneling Protocol of Ethernet , which provides authentication, authorization and accounting .This PPTP screen is only useful if using the L2TP connection method . WAN Interface Settings The L2TP is support only for Dynamic IP and Static IP Mode can be used.
  • Page 21 make its MAC address to be the MAC address to clone. L2TP Settings L2TP Account Enter the L2TP account provided by your L2TP server to definition. L2TP Password Enter the password provided by your L2TP server to definition. Please retype your L2TP password Retype the password to make sure type correct password.
  • Page 22 This page sets the primary and secondary DNS servers, which were given by your ISP or known to you. When a domain name request received, the gateway tries to resolve to it from the Primary Domain Name Server. Resolving failed, the gateway tries the Secondary sever again.

  • Page 23: Sip/H323 Configuration

    2.3 SIP/H323 Configuration 2.3.1 Setup the Register Server—SIP Protocol /VoIP Setup/Register Server/Server If you need use this gateway to register to the H.323 gatekeeper or SIP register/proxy server, you can setup the account for register here. This gateway can register up to four Servers simultaneously.
  • Page 24 Disable Register SIP Proxy server function. d. SIP Proxy URL: Please input the IP/URL of the SIP proxy server. e. Port [1~65535]: Port number used for register to server. The SIP protocol default is 5060, please make sure you have same port number setting on the gateway and server.
  • Page 25 p. Password: Password for register to SIP server. q. Conference ID: Some SIP Server requires an ID to enable the conference function, please input the ID here to enable that. r. Enable: Enable or disable independently each line for register.
  • Page 26 2.3.2 Setup the Register Server—H.323 Protocol /VoIP Setup/Register Server/Server When Select use H.323 to register gatekeeper, please input the flow information for register: Register Method: Global: All the lines of the gateway share same account to register. Independent: Each line can set different/same account independently for register.
  • Page 27 input here. Proxy for NAT： When your gateway is installed behind the firewall or NAT, you maybe need use Proxy server to relay your call. If your gatekeeper supports this proxy function, you can enable gateway function here to use that.

  • Page 28: Basic Operations

    2. Dial the number directly and press # Examples: A. SP5018/SP5008/SP5004P extension number makes call to IP PHONE 1. Dial an extension directly on the same proxy, (e.g. 9900306), and then press the #. 2. Dial an extension directly via the URL dial. Press 9900306 # to call the party with the IP address of 9900306@192.168.1.187.
  • Page 29 C. Using IVR Pick up the analog phone Original call(voip side) make call to 9904043(FXO) then hear “voice prompt” then access the voice menu prompt by dial “8645” For example, if we upload the voice file content on Prompt voice for VoIP call in of /VoIP is “Please input the password and destination Setup/Advance Setup/Prompt Voice/ number”...

  • Page 30: Call Hold

    3.2 CALL HOLD Place a call on hold by pressing the “flash” button on the analog phone (if the phone has that button). Press the “flash” button again to release the previously held Caller and resume conversation. If no “flash” button is available, use “hook flash” (toggle on-off hook quickly). You may drop a call using hook flash.
  • Page 31 Please enable CallWaiting on the /VoIP Setup/Advance Setup/Flash & Call waiting 3.4 PSTN (SP5004P) PASS THROUGH/LIFE LINE The 2-in-1 RJ-11 line jack on the SP5004P side functions as a pass through jack when the SP5004P is out of power. The pass through/life line enables the user to use the analog phone for PSTN calls if “Timeout for Re-entry route”(...

  • Page 32: Web Administration

    4. Web Administration The VoIP router provide user friendly Web interface to let you configure your router function and VoIP function. There are a help on line content within each setting page. Please press Help hyperlink to view the on line help. There are 3 main functions for web, VoIP, System Setup (Router) &...
  • Page 33 FXO: (DAA interface) for connect to telephone line or PBX extension line. FXS: (SLIC interface) for connect to regulate phone set. Display Name: display the remote party name of this VoIP call. Status: Current status of this port. Idle: Standby for make a phone call. Signal: Waiting for DTMF press or VoIP protocol connecting.
  • Page 34 (2) VoIP/Line Configure/ Line Setting /VoIP Setup/Line Configure/Line Setting/ This page will setup the phone line information each port. Port: display the port number, e.g. 1 or 2. Interface: Telephone interface type: FXO: for connect to telephone line or PBX extension line. FXS: for connect to regulate phone set Name: Line name for this port.
  • Page 35 of this line. For example, if you want line 1 to become a hot line for VoIP call, every time when you off hook the phone connected to the line 1, it will directly call to another VoIP gateway location at 168.56.09.22 and dial 601. You can enable the line 1 as hot line, and add a routing rule on the routing table on /VoIP Setup/Routing Setup/VoIP Call Out/ to assign the AREA CODE to hl1 to handle the router rule for hot line function.
  • Page 36 (3) Line configure/ Tone Setting /VoIP Setup/Line Configure/ Tone Setting A.Call Progress Tone This page defines the tones generated to the phone connected to the phone port. The cadence of CPT is been defined here also. All lines use same tone parameters.
  • Page 37 Maximum 15 tones can be defined. Type: Dial: Define the generated dial tone. Busy: Define the busy tone for generate. Ring: Define the ring back tone for generate Low freq: Lower frequency for defined tone High freq: Higher frequency for defined tone. Each tone can define two frequencies, if only one frequency needed, please leave High Frequency to 0.
  • Page 38 (4) Line configure/ Line Feature /VoIP Setup/Line Configure/ Line Feature This page defines the feature on the phone port of the VoIP router. Dial Pause signal length(as ,)[100~3000] ms: Define the pause time (ms) of the “,” on the /Routing Setting/VoIP Call Out/. This pause time is usually for time delay when connect to PBX and used for seize the CO line.
  • Page 39 Polarity Reversal Signal. Current Drop-> 1 S: Enable FXS interface to generate one second Current Drop signal. Current Drop-> 2 S: Enable FXS interface to generate two seconds Current Drop signal. Current Drop-> 3 S: Enable FXS interface to generate three seconds Current Drop signal.
  • Page 40 as ANI. Configure/Line Setting/ PSTN CID: Use the received Caller ID number from PSTN line as ANI. G. FXS Ring Method： Define how the FXS interface to ring the phone line when VoIP call in: Free Random: Any unused available line. Line number Priority: The 1 line has high priority;...
  • Page 41 (5) Line configure/ Line Polarity /VoIP Setup/Line Configure/ Line Polarity This page defines the Polarity on the phone port of the VoIP router. If use the normal phone set to connect gateway, please select “Normal”. If use PBX or special PSTN line (support polarity invert), then please select “Invert”. Please remember to press the Modify button to take it effect.
  • Page 42 (6) Routing Setup/ VoIP Call Out Setting /VoIP Setup/Routing Setup/VoIP Call Out This page let you define the routing rule for Call out to VoIP. (User press the phone number through phone set dial pad, then VoIP Router translate the phone number by the routing table setting here to destination IP &...
  • Page 43 call out rule without needed to press # key. FirstDigitTime: Define the waiting time (seconds) for user press phone number first digit. User need to press first digits before the setting time (seconds) defined here, if VoIP Router wait for the defined seconds and there is no any digits press, the VoIP Router will stop to wait and feedback the user busy tone.
  • Page 44 Remark: Remark for this routing rule. Please use UNDERLINE to replace the SPACE due to HTTP protocol limitation. Area Code: Define the Prefix number fit this rule, any phone number prefix digits matched with the rule will call out by this rule define. Please Notify there is a compare order rule on this routing table.
  • Page 45 setting (/VoIP Setup/Gatekeeper/) in advance. For example: gk1 for gatekeeper 1. gk2 for gatekeeper 2. gk for all the gatekeepers available ( search sequence: gk1 > gk2 > gk3 > gk4). Gk3_2_1 will try gk3 first, then gk2, then gk1. All the setting above can be added by port number, for examples: 168.56.9.22:8495 will call to 8495 port.
  • Page 46 Strip: the number of digits will be ignored by user input. For example, if user press the number is 886212345678 and the STRIP field is setting to 4, the first 4 digits 8862 will be truncated and actually call out number will be 12345678.
  • Page 47 C.Setting Examples Here is some VoIP call out routing table setting examples below: Define wait time and digits for destination phone number MaxDigits: FirstDigitTime(Sec): OtherDigitTime(Sec): In this case, when user picks up the phone, the VoIP router will generate 30 seconds (defined on FirstDigitTime) dial tone for user press DTMF for destination phone number, After user press first digit DTMF from phone set (for example, 0, the VoIP router will wait 5 seconds (defined on OtherDigitTime) to press the rest...
  • Page 48 Port Message Display Port Type Status Connected IP Caller ID Start Time End Time Talking Sec Dialed number Release by name 2004/02/19 2004/02/19 Idle 172.16.7.1 (146)onHangup 13:55:10 13:55:43 Idle Call by Domain name: Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile...
  • Page 49 Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete Take_All 10.1.1.1 Never_Used 8621 20.1.1.1 Strip and Prefix User is easy to combine using Strip and Prefix define to modify the phone number from phone to real call out phone number, for example, if the VoIP router is installed on Taipei and use another Gatekeeper to service global service.
  • Page 50 Area Index Remark IP Address Strip Prefix Profile Delete Code Digits Digits Via_GK2 Delete GK2_3_1 gk2_3_1 Delete GK_ALL Delete By Index 1, if user input any phone number with prefix code is 1, The VoIP Router will call out via Gatekeeper 2. By Index 2, if user input any phone number with prefix code is 2, The VoIP Router will try to call out by Gatekeeper 2 ( if register to Gatekeeper 2 is successful), if Gatekeeper 2 is not available, it will check Gatekeeper 3, then check Gatekeeper...
  • Page 51 Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete UsePF1 Delete UsePF2 10.1.1.2 Delete UseDefaultPF Gate.proxy.com Delete H.245 DTMF T.38 Package Q.931 Index Name CODEC Tunneling Relay FAX Relay Frame Fast Start Delete G.723.1 Out band 00001 H.323 1001...
  • Page 52 (8) VoIP Call In Routing Table Setting /VoIP Setup/Routing Setup/VoIP Call In/ This page let you define the routing rule for Call in from VoIP. (VoIP Router got a VoIP call required form Network, and then translates the phone number passed from remote side VoIP Router to the real dial out number &...
  • Page 53 Index Area Code Strip Prefix Maximum Minimum From To LineNo Gatekeeper Alert Profile Forward Delete Delete 8862 Delete Auth：Authorization IP check enable. Enable IP range authorization function. When Enable, the gateway will check the remote caller IP range setting on /VoIP Setup/Routing Setup/Authorization/, if it is within the authorization, the gateway will allow the call out, but if the remote caller’s IP is not in the range, it will refuse to call out and terminate this call.
  • Page 54 to PSTN, the wait time for one , can be set on /VoIP Setup/Line Configure/Line Feature/). This example is especially for speed dial function. Index Area Code Strip Prefix Maximum Minimum From LineNo Gatekeeper Alert Profile Forward Delete 0,12345678 Delete Ex: VoIP Call in number is 90 and real dial out number is 0,12345678 by stripe 2 digits and add 0,12345678 prefix, so the real dial out number is 0,12345678.
  • Page 55 To: Define the ending line number for service this area code VoIP call. Index Area Code Strip Prefix Maximum Minimum From To LineNo Gatekeeper Alert Profile Forward Delete Delete Delete Delete Ex. Any VoIP Call in number with prefix 601 will ring the line 1, and Any VoIP Call in number with prefix Call in number 602 will ring the line 2.
  • Page 56 to put through. Call Waiting：Enable or Disable the call waiting function。 Enable: During Talk, you can answer another phone call and hold the original conversation. When some one call in when you are busy on another phone call , you will hear a du-du call waiting signal, please use flash key on your phone to hold the original call and answer the incoming call, press again flask key will switch back the original call party.
  • Page 57 Index Area Code Strip Prefix Maximum Minimum From To LineNo Gatekeeper Alert Profile Forward Delete Delete Delete Delete H.245 DTMF T.38 Package Q.931 Index Name CODEC Tunneling Relay FAX Relay Frame Fast Start Delete G.723.1 Out band 00001 H.323 1001 E.164 Delete G.723.1...
  • Page 58 Other: 10.1.1.1/104 No. Name Always OnBusy No Answer No Answer Sec Delete hk.big.com/301 Delete assist.big.com assist.big.com/610 Delete In this case, when the VoIP router received a VoIP call in number with prefix 501 ( not 601 or 602 prefix defined on Call In Routing table), it will forward this call to the IP &...
  • Page 59 (8) VoIP Call In IVR Setting /VoIP Setup/Routing Setup/VoIP Call In IVR/ When Enable the [Prompt Voice for VoIP Call In function on /VoIP Setup/Advance Setup/Prompt Voice/ , all the remote party of VoIP caller will hear the customization upload voice file and need press the destination number. All the input number will be checked the number length and be strip/add prefix defined on this page.
  • Page 60 A. Time & Digits wait for user The VoIP Router wait user input the number digits & time parameters as below: Time & Digits wait for user Press. MaxDigits: Define the maximum digits wait for user press for all VoIP Call Out, if user press digits match the number defined here.
  • Page 61 Min Digits: define the minimum digits wait for user press for number fit this rule, if user press digits less the number defined here. It will keep waiting for input until exceed the FirstDigitTime defined time. If user press digits more then Min Digits here, the VoIP Router will wait time defined on OtherDigitTime then go to translate for call out rule without needed to press # key.
  • Page 62 (9) VoIP Routing Profile Setting /VoIP Setup/Routing Setup/Routing Profile/ This page defines the optional special VoIP parameters when making/received a VoIP call. For define some special parameters for different VoIP equipment or authorize purpose, please add a profile at /VoIP Setup/Routing Setup/ Routing Profile/ and use the same name as the profile on the Call in Routing Table (/VoIP Setup/Routing Setup/VoIP Call In/) or Call out Routing table (/VoIP Setup/Routing Setup/VoIP Call Out/).
  • Page 63 DTMF Relay: When select In band to transfer the DTMF during VoIP, the user pressed DTMF tone will be treat as general voice and been compressed then transmit to remote side to decompress play back, it maybe cause some problem on duplicate or missing DTMF receive. When select Out band to transfer the DTMF during VoIP, the user pressed DTMF tone will be decode by local VoIP Router then transmit as signal, after received on received remote VoIP Router, it will be...
  • Page 64 Delete: Delete this rule item on routing table. To add new profile item on routing table, please assign the number you want to insert before, input profile NAME then press ADD button to add it on the list. Then modify the necessary information on the routing table list. Please remember to press the modify button to take it effect.
  • Page 65 (10) VoIP Forwarding Profile Setting /VoIP Setup/Routing Setup/Forwarding/ This page defines the forwarding behavior include: get an unmatched prefix number for VoIP call in, Line busy No answer Please add a profile at /VoIP Setup/Routing Setup/Routing Profile/ and put the name of profile on the Call out Routing table (/VoIP Setup/Routing Setup/VoIP Call Out/).
  • Page 66 answer over the time No Answer Sec , an incoming VoIP call will forward to IP assigned here when ring time over the defined on No Answer Sec. No Answer Sec. Defined the wait seconds for redirect forward to another IP(or URL).
  • Page 67 CF1, and in CF1 profile, the Always field is set to hk.big.com/301, that mean any call number with prefix 601 will always be forward to another VoIP Router locate at hk.big.com and dial out number is 301. When the line 2 is busy and another VoIP with prefix 602 Call in, it will forward it to the assist.big.com with same number (defined on OnBusy).
  • Page 68 (11) VoIP Authorization Setting /VoIP Setup/Routing Setup/Authorization/ When this gateway has been used for outbound call, it can enable to check the remote caller gateway’s IP to decide accept or refuse the call. If define the IP range here and enable the [Auth] option on the/VoIP Setup/Routing Setup/VoIP Call In/ , only the IP in range will allow to call out by this gateway.

  • Page 69: Register Status

    4.2 Register Status /VoIP Setup/Register Server/Register Status You Can check the register status of this gateway on this page. a. MAC: this gateway’ MAC Address。 b. RS1-4: Indicate the status of 4 server register. SIP&H323: The protocol used for registering the server, this gateway supports both H.323 and SIP protocol.
  • Page 70 number”. Please setup each register parameters at /VoIP Setup/Register tatus/Server#1~4/。...

  • Page 71: Auto Provision Function

    4.3 Auto Provision function To use the auto provision function, the system have to install a dedicate Auto Provision Server for keep all parameters for installed gateways. When Enable the Auto Provision function, the System administer can modify all the Parameters of each gateway on the local Provision Server, and remote gateway will automatic download all the parameters from Provision Server.
  • Page 72 /VoIP Setup/Provision/ Provision Set:：Enable or Disable auto provision function on this gateway. When Enable, all the function parameters will download from remote Provision server. Provision Sever1~5 : Provision server connection status. It will indicate the status of linking to each Provision Servers. The gateway will link to one of the five setting Provision Server each time.
  • Page 73 Internet connection. Provision Server IP: User can manual add a new Provision Server by add its IP here and press Link .Please remember enable auto provision function before you input the new Provision Server IP. For store back to flash memory, please press Save Modification (/System Maintenance/Save Modification/).

  • Page 74: Advance Setup

    4.4 Advance Setup (1) NAT Traversal /VoIP Setup/Advance Setup/NAT Traversal If your VoIP gateway is installed behind NAT, you may need a special configuration and server to establish the VoIP communication, this gateway support several method for NAT Traversal as below: By Outbound Proxy: User can appoint an Outbound Proxy Server to handle the NAT traversal on VoIP Setup/Register Sever/Server #/...
  • Page 75 (2) Listen Port /VoIP Setup/Advance Setup/Listen Port In this page, user can define the usage port for setup the VoIP communication. Both side of gateways need use the same port for begin VoIP communication. SIP Listen Port : Define the listen port for SIP protocol, the default port is 5060, input range from 1024 to 65535.
  • Page 76 (3) VoIP Package /VoIP Setup/Advance Setup/VoIP Package User can define the parameters relative about VoIP package on this page. Jitter Buffer(ms): Define the Jitter buffer size, input range is from 20 to 200ms. VoIP DTMF Relay Mode: Define the relay mode for DTMF signal: In band: When local gateway detects a DTMF signal, it will not decode it .
  • Page 77 by SIP:RFC2833 (SIP protocol) or H.323:H.245 (H.323 protocol) by SIP INFO (SIP protocol) or Q.931 (H.323 protocol) RFC2833: Payload number for DTMF[96~127]: Define the DTMF token on RFC2833, input range form 96 to 127. Silence Detection / Suppression: Enable or disable the Silence Detection/VAD function. When Enable, if local gateway detect a silence situation ( no talk), it will send a VAD package rather than a full voice package for remote side to active CNG ( Comfort Noise Generation) to save the bandwidth.
  • Page 78 (4) RTP Packet Summary /VoIP Setup/Advance Setup/RTP Packet Summary On this page, user will know the RTP package summary about last VoIP call. Line#: number of line Using CODEC: ex.: G.723.1, G.729a Source IP: Remote side IP Source Port: Remote side port Packet Interval: interval time between 2 packets.(ms) Packet Send: number of packets sent.
  • Page 79 (5) Flash & Call waiting /VoIP Setup/Advance Setup/Flash & Call waiting On this page, user can define the parameters relative to the FLASH key and Call Waiting function. These functions usually work with PBX Token for flash key on VoIP(!): Define the token for flash key during VoIP protocol ( use “! “...
  • Page 80 (6) Gain /VoIP Setup/Advance Setup/Gain This page defines different function gain on the gateway. Gain when Dial tone phase： When phone off hook, user will hear the dial tone generated from the gateway, sser can adjust the play/record gain during this phase for stable DTMF detection. After connection, the gains setting here is no use, the gateway will adjust the gain setting on /Line Configure/Line setting/ Transmit gain from network to line.
  • Page 81 (7) QoS /VoIP Setup/Advance Setup/QoS User can define the ToS field on the VoIP packet for Quality of Service control. The ToS field is included these 2 parameters: Precedence: bit 0,1,2 DSCP(Diffserv Code Point): bit 3~7 User can select inptut either IP Precedence or DSCP value. Or input the ToS binary code directlly.
  • Page 82 (8) CDR /VoIP Setup/Advance Setup/CDR The Gateway can export all the CDR (Call detail Record) to external CDR server by HTTP protocol. The gateway supports up to 2 CDR servers for keep the record. Export to CDR Server: Please install and enable this function if you want to keep CDR of this gateway.
  • Page 83 (9) FoIP /VoIP Setup/Advance Setup/FoIP User can define the parameters relative FAX Over IP function. Maximum FoIP Rate (bps) Appoint the maximum FAX transceiver rate during FoIP: Disable: Only the VoIP function is supported on the gateway. FoIP is disabled. Auto: Gateway will negotiation the maximum speed for FoIP with FAX machine..
  • Page 84 (10) Prompt Voice&Beep /VoIP Setup/Advance Setup/Prompt Voice & Beep This gateway can use voice or beep to prompt the user different situation. User can download/upload their own prompt voice wave files also. For prompt beep enable function, it can be enable by: VoIP Call out Beep: When enable, the gateway will generate a beep for call out for VoIP VoIP Call out Failure twice Beep...
  • Page 85 Use a customize voice file to replace the dial tone Warming Prompt after VoIP out failure: Annunciate a customize voice file when VoIP call failure. No PSTN Line Connected : Annunciate a customize voice file when there is no trunk connected to the PSTN port and failure to call via PSTN line.

  • Page 86: Application

    4.5 Application (1) Ping test /VoIP Setup/Application/Ping Test User can use the Ping Test function to test the network status or remote device Ping Destination:Ping: Target device IP for ping test. Number of Ping[1-100]Ping 次數: Number of ping test, maximum is 100. Ping Packet Size[56-5600 bytes]: Size of ping test packet, input range is between 56 to 5600 bytes。...
  • Page 87 (2) Telnet & SNMP /VoIP Setup/Application/Telnet & SNMP User can enable and set the user account for the SNMP and Telnet function of this gateway on this page。 Enable telnet server Enable: Enable telnet service function, user can telnet this gateway. Disable: Disable telnet service function.

  • Page 88: System

    4.6 System (1) System Status This page reveals the status of the gateway including WAN, LAN and some hardware information. Internet This sub-block shows the Internet information of your home gateway. It depends on the WAN mode connecting to your ISP. The different items correspond to each WAN mode will be revealed after the common part of the Internet status sub-block.
  • Page 89 Common Part: Refresh Clicking this button, the browser refreshes the Internet status page to get the most update information. Cable/DSL This field indicates the Internet connection status. Its value is Connected , Disconnected or Connecting. WAN IP Connected to the Internet through Cable or ADSL modem, the ISP will offer the home gateway a WAN IP address to communicate with other hosts in the Internet.
  • Page 90 This is the secondary DNS to use when the primary DNS does not work. Domain Name Domain name is a name, which identifies one or more IP addresses. This field represents the domain name obtained from your ISP. Connection Type There are five ways to get the WAN IP address.
  • Page 91 This field shows how many clients in the LAN clients connect to the home gateway. Runtime Code Version Shows the version of runtime code. Boot Code Version Shows version of boot code. LAN MAC Address Short for Media Access Control address, a hardware address that uniquely identifies each node of a network.
  • Page 92 (2) System Settings This page is used to configure the names given by the ISP, if any, to represent the gateway, and also to set the local time zone. Host Name Some ISPs request the host name to represent the home gateway. Fill the host name given by the ISP, or you may not be able to access the Internet successfully.
  • Page 93 This page is used to setting the system time of VoIP gateway; it can define the correct time by which ways.
  • Page 94 (4) Administrator Setting This page allows you to change the user and administration password used to manage this router for security reasons.
  • Page 95 (5) System Log The system log page shows the gateway’s activity logs such as the Internet connectivity, hacker attack, intrusion detection and the wireless association. The log helps you to do fault analysis or regular statistics. Download Save the log to a local file. Clear Clear the log.
  • Page 96 Remote Log Settings Remote Log Check this file and the gateway will send the log message to the “Send Log to” remote host. Send Log to Set the IP address to send log. Email Log When the log buffer is full, the gateway will check whether this item is enabled. If enabled, the gateway will send all the log messages to the “Send Email to”...

  • Page 97: Route Function

    4.7 Route Function (1) Setting WAN connection: System Setup/Connection /System Setup/WAN/Connected Type Connection Type There are five ways to connect to the Internet. They are Dynamic IP, Static IP, PPPoE, PPTP and L2TP. The cable modem ISP usually requests you to obtain the WAN IP dynamically. Some ISPs request you to fill the host name.
  • Page 98 You can specify the IP address you desired. But the ISP has the right to neglect it and provides you a different one. MTU (576-1500) You can specify the MTU (maximum transmission unit) of your home gateway. The default value is 1500 bytes and in normal case, you don’t have to change. MAC Cloning Some ISPs will identify the MAC address registered by the user.
  • Page 99 ISP Gateway Address Set the ISP’s gateway IP address. This address routes packets to Internet. C. PPPoE This page is the PPPoE configuration page. Most of the ISPs request the user to connect to central office (CO) side via PPPoE, acronym of Point-to-Point Protocol over Ethernet, which provides authentication, authorization and accounting.
  • Page 100 to worry about the MTU size, the gateway routing engine will handle the MTU differences between PPP and the LAN Ethernet side. But for some old PPPoE server, you have to make the MTU size of the PPPoE side smaller than the default value, or some Web side is not able to access.
  • Page 101 This page sets the primary and secondary DNS servers, which were given by your ISP or known to you. When a domain name request received, the gateway tries to resolve to it from the Primary Domain Name Server. Resolving failed, the gateway tries the Secondary sever again.
  • Page 102 (2) LAN Settings /System Setup/LAN/LAN Settings/ The home gateway is an IP sharing device, which provides the home users share the same public IP address. While in the LAN side, each network device must have one private IP address to do network communication. This page is to set the configuration of the LAN interface of the gateway.
  • Page 103 IP Pool Ending Address The ending address provided by DHCP sevice. Lease Time Set the lease time of the IP address to renew. DNS Proxy The home gateway acts as a DNS Proxy. In this case, the DHCP service will set LAN interface IP address as the DNS server address, and inform the clients in the DHCP renew process.
  • Page 104 This column shows the MAC Address of the DHCP clients. Static Check this item to make the IP address static, and every time the client connect to the home gateway, it will get the same IP address all the way. Refresh Click this button, the browser request the DHCP client list from the home gateway and refresh the page again.
  • Page 105 (3) NAT Virtual Server This is the virtual server page, which set the rules translate the private IP/private port pairs to the public ports. Private IP Set the IP address of the virtual server. Private Port Set the port of the virtual server to connect to Internet. Type Set the protocol of the virtual server.
  • Page 106 Special Application Trigger Port To define the TCP/UDP port range to monitor, when initiating from the home network, the public ports configured in this entry will be activated. Trigger Type Defines the protocol type: TCP, UDP or both of the trigger ports. Public Port This column defines the public ports opened when the trigger ports were seen.
  • Page 107 The Port Mapping page does a port range mapping. Server IP Set one of LAN client’s IP address to do port mapping. Mapping Ports Set the ports to mapping from WAN to LAN. You can enter multiple ports, delimited by comma, or a range of port by dash.
  • Page 108 Some applications have to do Application Level Gateway (ALG) to monitor the transaction or monitor the payload of the packet. This page let you setup them. We use mnemonic nouns to describe the specific ALGs. The checked entries will be enabled by the ALG processing.
  • Page 109 Public IP MZ table Address Select among the WAN IP addresses of the home gateway. IP Address of Virtual DMZ Host Fill the client in the LAN side as the associated DMZ host. Add this entry to virtual DMZ host table. Delete Delete this entry from virtual DMZ host table.
  • Page 110 (4) Firewall Firewall Options Enable Hacker Attack Protect The hackers always try to break into you system or crack down your network. The gateway provides hacker attack protect modules to protect your home network. Discard PING from WAN side “Ping” is the most widely used tool to diagnose the network. Hackers use “ping” to discover your gateway firstly and try to hack your home network later.
  • Page 111 Allow to Scan Security Port (113) Some Linux email servers will try to detect the security TCP/UDP port (113). If you drop it, the Linux email servers will not allow you to log into. Allow it can solve such kind of problem. Discard NetBios Packets The NetBios protocol is widely used by the MS Windows Network Place, which should only be use in the home network and should not be used in the Internet...
  • Page 112 Enable Client Filter Check this box and all the entries below will take effect. Block the IP addresses ranged to connect to Internet. Port Set the port range, within which is not allowed to connect to Internet. Type Set which protocol, TCP/IP/Both, of this entry to inhibit. Block Time Two options are provided for this column, the “Always”...
  • Page 113 URL Filtering Enable URL Filter Check this box and all the entries below will take effect. The IP addresses ranged will be the candidate to check the URL when they use web browser to access the Internet. URL filter string The specific URL string to block.
  • Page 114 MAC Control MAC Control MAC Address Control Check this item to enable MAC control service. Filter out or only accept the following MAC address connect to Internet Select “Filter out”, the MAC addresses list in the following table will be block out to access the Internet.
  • Page 115 (5) Routing To set this Destination LAN IP This field indicates the destination IP of this route entry. Subnet Mask This field indicates the Subnet Mask of this route. Gateway If a packet’s destination IP address do “bit and” operation with the “Subnet Mask” equals to the “Destination LAN IP”, the packet will send to the Gateway.
  • Page 116 Static Routing Destination LAN IP This field indicates the destination IP of this route entry. Subnet Mask This field indicates the Subnet Mask of this route. Gateway If a packet’s destination IP address do “bit and” operation with the “Subnet Mask” equals to the “Destination LAN IP”, the packet will send to the Gateway.
  • Page 117 (6) UPnP Settings UPnP Enable UPnP Check this item to enable UPnP. UPnP Port Number Set UPnP port number to announce to the UPnP control points. The UPnP control points use this TCP port to send request to the home gateway. Advertise Time (60-1800) Set the time interval after which the home gateway sends advertisement packets.
  • Page 118 Port Mapping Remote Host This field lists remote host that connect to LAN client. External Port This field lists the port of the remote host connect to LAN client. Internal Client This field lists LAN client connect to the Internet. Internal Port This field lists port of LAN client connect to the Internet.
  • Page 119 (7) DDNS Enabled Check this item to enable the DDNS settings Disabled Check this item to disable the DDNS settings Host Name Set your host name that need to do DDNS update. DDNS Server Set the DDNS server that updates your IP address. User Name The DDNS server requires you to supply a name and password to update your IP address.

  • Page 120: Backup/Restore

    4.8 Backup/Restore (1) Configuration /Backup-Restore/Configurations/ This page let you backup / Restore all of your configuration parameters on the VoIP Router. It is very good idea to back up all of your VoIP Router configuration parameters after install. To Backup, press Download setting backup file, and input the file name you want and file location to save.
  • Page 121 (2) VoIP Module /System Maintenance/Backup-Restore/Configurations/ This page displays the current firmware module version and let you backup / Restore all of your VoIP firmware module on the VoIP Router. Please use this page to update the VoIP module firmware if necessary. To Restore from local file, press the Browse button the select the VoIP module file to upload then press Restore .
  • Page 122 firmware and upgrade automatically. *** Caution: Never power off the VoIP Router when during Restore configure or upgrade VoIP module or System, it will cause permanent damage when power off during writing Flash inside VoIP Router.
  • Page 123 (3) Reboot System /Reboot System Use the Reboot button on this page to reboot your VoIP Router, before you reboot, please make sure you have to press the Saved modification to save your current configuration to Flash ROM, otherwise all the change will be disappear after reboot.

  • Page 124: Save Modification

    4.9 Save Modification /Save Modification/ Most of the VoIP Router parameters will take effective after you modify, but it is just temporary stored on RAM only, it will disappear after your reboot or power off the VoIP Router, to save the parameters into Flash ROM and let it take effective forever, please remember to press the Save Modification button after you modify the parameters.
  • Page 125 5. Specification Model SP5004P SP5008 SP5018 SP5058 Standard ITU-T H.323 and IETF SIP standards Interface 4 x FXS 8 x FXS 4 x FXS 8 x FXO 4 x PSTN 1 x WAN 4 x FXO 1 x WAN 1 x WAN...
  • Page 126 • External auto-provision system Environment Temperature: 0 to 45 degree C (Operation) -20 to 75 degree C (Storage) Humidity: up to 90% non-condensing Power Supply DC12V, 1.5A Certificate CE, FCC Date: 2007 / 6 / 27...
