MicroNet SP5050 User Manual

Ip telephony gateway, fxo interface
Hide thumbs Also See for SP5050:
Table of Contents

Advertisement

Quick Links

User's Manual
SP5050/SP5052/SP5054
IP Telephony Gateway, FXO Interface
Website:
http://www.micronet.info

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP5050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MicroNet SP5050

Summary of Contents for MicroNet SP5050

  • Page 1 User’s Manual SP5050/SP5052/SP5054 IP Telephony Gateway, FXO Interface Website: http://www.micronet.info...

  • Page 2: Table Of Contents

    1. INTRODUCTION ............................3 1.1 F ......................... 3 EATURES AND SPECIFICATION 1.2 A ............................4 PPEARANCE 2. SYSTEM OPERATING PROCEDURE ....................6 2.1 S ..........................7 YSTEM EQUIREMENT 2.2 T ......................7 ELEPHONE EQUIREMENT 2.3 IP E ........................7 NVIRONMENT ETTING 2.4 H ........................

  • Page 3: Introduction

    1. Introduction The Micronet SP5050 Series FXO gateway provides voice/fax service over IP network with H.323 v3 protocol. By connecting to your existing ADSL or cable modem service, which allows the use of a single, network for voice and fax services with consequent saving in network infrastructure and greatly reduced telephone charges.

  • Page 4: Appearance

    Management Features: Console port: RS-232C port TELNET HTTP Brower (e.g. Internet Explorer) 1.2 Appearance Front panel: The LED light provides system message of Micronet SP5050 Series. Front panel of SP5050 Power : Light on means Micronet SP5050 Series is power on. L1-L6 : Light on means the line is in use.
  • Page 5 PIN 1, 2: Transmit PIN 3, 6: Receive COM: RS232 console port (9-pin Male connector, as the same as the computer). Male connector (as the same as the PC) 9 PIN D-SUB MALE at the VoIP FXO gateway Name Description Receive Data Transmit Data ─...

  • Page 6: System Operating Procedure

    2. System Operating Procedure START 2.1 System Requirement 2.2 Telephone Line Requirement 2.3 IP Environment Setting 2.4 Hyper Terminal Setting...

  • Page 7: System Requirement

    2.1 System Requirement 1. One PC (a) Pentium 100 or above, 64 MB DRAM, Windows 98 or above. (b) Network card (RJ-45) & COM port 2. One standard RS-232 straight cable with two female connectors depended on the different model. 3.
  • Page 8 2. Define a name such as ‘SP5050 Gateway’ for this new connection. 3. After pressing OK button, the next window popping up is necessary to connect choose COM Port.
  • Page 9 Note: Some connection failed is derived the PC COM Port. If user cannot open the com port, for example com 1, please try another com port, ex.com port 4. Configure the COM Port Properties as following: (1) Bits per second : 9600 (2) Flow control : None Press ‘OK’...

  • Page 10: Initializing Voip Fxo Gateway Setting

    3. Initializing VoIP FXO Gateway Setting 3.1 Gatekeeper Mode START (a) Configure VoIP FXO gateway Password (b) Configure VoIP FXO gateway IP Address (c) Gatekeeper Mode Settings (d) Save VoIP FXO gateway Configuration & Reboot VoIP FXO gateway...
  • Page 11 (a) Configure VoIP FXO gateway Password It is important for the first time user to follow the operation procedure. 1. Power on the VoIP FXO gateway and the sentence “Please wait while system is initializing…………S” is displayed. Attached TCP/IP interface to cpm unit 0 Attaching interface lo0...done Please wait while system is initializing ..

  • Page 12: Peer-To-Peer Mode

    (b) Configure VoIP FXO gateway IP Address Use “ifaddr” command to set up VoIP FXO gateway’s IP address and related network information. An example is demonstrated below: usr/config$ ifaddr –ip 10.1.1.1 –mask 255.2555.255.0 –gate 10.1.1.254 Note: this is to assign VoIP FXO gateway an IP address of “10.1.1.1”, subnet mask “255.255.255.0”, and default IP gateway “10.1.1.254”.

  • Page 13: Behind Ip-Sharing

    Note: mode 1 is for Peer-To-Peer (non-gk) mode, while mode 0 is for GK mode. 2. Configure Phonebook, using “pbook” command. Users can refer to chapter 5.11 [pbook] command for more information. usr/config$ pbook –add name TEST1 ip 10.1.1.1 e164 10 Note: The command is to add a record onto Phonebook.
  • Page 14 Dynamic IP Address –usr/config$ ifaddr –ipsharing 1 Note: With Dynamic WAN IP Address, a Gatekeeper with a valid IP address for VoIP FXO gateway is a must. In other word, it is not workable in Peer-to-Peer mode while dynamic WAN IP Address. IP Sharing device must have a function to do IP/Port mapping.

  • Page 15: Disconnect Tone Configuration

    4. Disconnect Tone Configuration This application note is going to describe the procedures of configuring the disconnect tone on VoIP FXO gateway in order to release LINE ports of VoIP FXO gateway after PSTN/PBX caller party is hung up. 4.1 What is Disconnect Tone IP Side PSTN or IP-Network...

  • Page 16: Adjust Tone Table Parameters Manually

    Otherwise it may be released after one minute or lock this LINE permanently. The tone table parameters are shown as follows. LowFreq 480 : Low frequency is 480 HZ HighFreq 620 : High frequency is 620 HZ LowFreqLevel 8 : Low frequency level received range from PSTN/PBX HighFreqLevel 8 : High frequency level received range from PSTN/PBX TOn1 50 : Disconnect tone cadence ON time is 0.5 seconds...

  • Page 17: Adjust Input Tone Level

    620/480, take the following procedures. 620/479 620/480 620/481 621/479 621/480 621/481 619/479 619/480 619/481 If the line port of gateway was locked, please use “hangup 0” command to release LINE 1, “hanhup 1” to release LINE 2…etc. 4.4 Adjust Input Tone Level Sometimes the disconnect tone level is too low to be detected by VoIP FXO gateway.

  • Page 18: Command Lists

    5. Command lists 5.1 [help] command Type help or man or ? to list all the available command. usr/config$ ? help help/man/? [command] quit quit/exit/close debug show debug message reboot reboot local machine flash clean configuration from flash rom commit commit flash rom data ifaddr internet address manipulation...

  • Page 19: Reboot] Command

    Open debug message will show up specific information while VoIP FXO gateway is in operation. After executing the debug command, it should execute command debug -open as well. One example is demonstrated below. usr/config$ debug -add h323 vp usr/config$ debug -open Parameters Usage: -status Display the enabled debug flags.

  • Page 20: Commit] Command

    Warning: Once users execute flash –clean, all the configurations of VoIP FXO gateway will be cleaned. This can only be executed by user who log in with root 5.6 [commit] command Save changes after configuring the VoIP FXO gateway. usr/config$ commit This may take a few seconds, please wait..

  • Page 21: Time] Command

    ifaddr -timezone 8 Parameters Usage: -print print current IP setting assigned IP address for VoIP FXO gateway -mask internet subnet mask -gate IP default gateway -dhcp Dynamic Host Configuration (1 = ON; 0 = OFF) -sntp Simple Network Time Protocol (1 = ON; 0 = OFF) When SNTP function is activated, users have to specify a SNTP server as network time source.

  • Page 22: Greetrd] Command

    no answer from 210.54.23.129 usr/config$ ping 192.168.4.121 PING 192.168.4.121: 56 data bytes 64 bytes from 192.168.4.121: icmp_seq=0. time=5. ms 64 bytes from 192.168.4.121: icmp_seq=1. time=0. ms 64 bytes from 192.168.4.121: icmp_seq=2. time=0. ms 64 bytes from 192.168.4.121: icmp_seq=3. time=0. ms ----192.168.4.121 PING Statistics---- 4 packets transmitted, 4 packets received, 0% packet loss round-trip (ms) min/avg/max = 0/1/5...
  • Page 23 Please wait for Writing...block 1 Please wait for Writing...block 2 Replay New Greeting Voice?(y/n): Disconnect Tone Analysis : please follow instructions on screen (Selection 2). First call in line1 of VoIP FXO gateway from PSTN side (now can’t hear greeting), hang up the phone and press “enter” to start record disconnect tone. Finally, choose “y/n”...

  • Page 24: Pbook] Command

    3.exit. -------------------------------------------------- Please input function(1~3): 3 Are you sure to EXIT?!(y/n): y usr/config$ 5.11 [pbook] command Phone Book function allows users to define their own numbers, which mapping to real IP address. It is effective only in peer-to-peer mode. When adding a record to Phone Book, users do not have to reboot the machine, and the record will be effective immediately.
  • Page 25 phone number. Note: <index number> means the sequence number in phone book. If users do not request a specific index number in phone book, VoIP FXO gateway will give each record a automatic sequence number as index. -add add a new record to phone book. When adding a record, users have to specify name, ip, and e164 number to complete the command.

  • Page 26: Pppoe]

    5.12 [pppoe] Display PPPoE related information. PPPoE device information and configuration Usage: pppoe [-print]|[-open]|[-close] pppoe [-dev on/off][-id username][-pwd password] -print Display PPPoE device information. -dev Enable(=1) or Disable(=0) device. -open Open PPPoE connection. -close Disconnect PPPoE connection. Connection user name. -pwd Connection password.
  • Page 27 -idto The duration of two pressed digits in dial mode -eod Digit type of end of dialing. ( 0:No end of dialing, 1:[*] button, 2:[#] button ) -seizure Choose line seizure mode (None/UCD). -2nddial Config GW to accept 2nd dtmf set. In this mode, device from IP side needs to dial GW's E164, wait for PSTN dialtone, and then dial out.
  • Page 28 1 (Direct In Line Service): This feature must be implemented in a pair of FXO products in Gatekeeper mode and set bureau –table command. In Direct In Line Service VoIP FXO gateway will connected via gatekeeper to pre-defined E.164 number. For example: $bureau –table 1 192.168.4.184 123 (please refer to 5.21 bureau command) If L1 of VoIP FXO gateway is assigned to pre-defined E.164...
  • Page 29 value is set to enable all ports. - idto The duration of two pressed digits in dial mode - eod: Digit type of end of dialing. ( 0:No end of dialing, 1:[*] button, 2:[#]button ) - seizure line seizure mode. None (0): When calling from IP side, choose L1 every time if it is available.

  • Page 30: H323] Command

    for response. If the other party cannot respond the message in 10 seconds, VoIP FXO gateway will regard the opposite party as IDLE state and disconnect the call. When CallAlive is deactivated, RoundTripDelay message will not be sent during connection. - keypad keypad type when relay DTMF signal.
  • Page 31 -gwtype Register as Gateway (1) or Terminal (0) type -ras Gatekeeper RAS port (1024~65535). -range Dynamically allocated port range (1500~65535). -respto Max waiting time for 1st response to a new call (1~200). -connto Max waiting time for call establishment after receiving 1st response of a new call (1~20000).

  • Page 32: Gk] Command

    -e164 e164 number, which is registered as phone number in gatekeeper. -alias h323 ID, a identification in h323 world for other parties’ recognition. The field might be used as a key of authorization or accounting in some VoIP application. It is recommended to assign a special name, or it might conflict with other devices.

  • Page 33: Voice] Command

    Usage: gk [-add type1 [[type2]...]] [-delete h323] [-ttl value [-enable 0/1] [-security enable/disable] -print Display the enabled debug flags. -enable Enable simple gatekeeper -ttl Set TTL value -add Add dynamic endpoint (h323 ID, E164, IP, port, type) -delete Delete dynamic endpoint -security enable Enable security check -security disable...
  • Page 34 usr/config$ voice Voice codec setting information and configuration Usage: voice [-send [G723 ms] [G711A ms] [G711U ms] [G729A ms] ] [-volume [voice level] [input level] [dtmf level]] [-nscng G723 used] [-echo used] [-mindelay t1] [-maxdelay t2] [-optfactor f] voice -print voice -priority [G723] [G711A] [G711U] [G729A] -print Display voice codec information and configuration.

  • Page 35: Tos] Command

    -nscng silence suppression and comfort noise generation setting (1 = ON; 0 = OFF). It is applicable to G.723 codec only. An example is demonstrated below: usr/config$ voice -nscng g723 1 -mindelay the minimum jitter buffer size. (Default value= 90 ms) -maxdelay the minimum jitter buffer size.

  • Page 36: Tone] Command

    -rtptype configure TOS type of RTP packets from 0 to 7 -rtcptype configure TOS type of RTCP packets from 0 to 7 -sigdelay configure signaling packets as normal delay or low delay -rtpdelay configure RTP packets as normal delay or low delay -rtcpdelay configure RTCP packets as normal delay or low delay -sigthruput...

  • Page 37: Group] Command

    -t38 T.38(FAX) enabled/disabled. -fstart Fast start enabled/disabled. -tunnel H245 Tunneling enabled/disabled. -h245fs H245 separate channel after faststart. Example: support -fstart 1 support -tunnel 0 support -h245fs 1 Parameter Usages: -print print current setting in support command. -t38 to switch ON/OFF (1 = ON; 0 = OFF) T.38 function.T.38 function is for FAX.

  • Page 38: Bureau] Command

    -enable Enable PSTN Grouping -disable Disable PSTN Grouping -number Set number of divided groups -pattern Set number of members in each group -e164 Set E.164 number for each group Example: group -print group -enable group -disable group -number 2 -pattern 3 3 -e164 01 02 group -pattern 3 1 -e164 100 200 group -e164 11 22 Parameter Usages:...
  • Page 39 -table Set Hot line/Line To Line information. (Port range: 1~2) Note: Hotline feature should be used together with: $sysconf -service 2 (HotLine service) $sysconf -2nddial 0 (2nddial off) $h323 -mode 1 (peer-to-peer mode) Line To Line feature should be used together with: $sysconf -service 2 (HotLine service/Line To Line ) $sysconf -2nddial 1 (2nddial on) $h323...

  • Page 40: Prefix] Command

    5.22 [prefix] command This function can do digits replacement of incoming call from IP side or PSTN side. usr/config$ prefix Prefix setting information and configuration Usage: prefix [-pstnrule index oldnumber newnumber (index = 1 ~ 6)] [-iprule index oldnumber newnumber (index = 1 ~ 6)] prefix -print -print Display prefix information and configuration.
  • Page 41 -dspcore update DSP kernel code(optional) -dspapp update DSP application code(optional) -rbpcm update RingBack Tone PCM file(optional) -htpcm update Hold Tone PCM file(optional) -greeting update Greetings PCM file(optional) -askpin update AskPin file(optional) IP address of TFTP/FTP server (mandatory) file name(mandatory) -method download via TFTP/FTP (TFTP: mode=0, FTP: mode=1) -ftp specify username and password for FTP...

  • Page 42: Passwd] Command

    asking for pincode. to specify TFTP server’s IP address when upgrading ROM files. to specify the target file name, which will replace the old one. -method to decide using TFTP or FTP as file transfer server. “0” stands for TFTP, while “1” stands for FTP. -ftp if users choose FTP in above item, it is necessary to specify pre-defined username and password when upgrading files.

  • Page 43: Upgrade The Voip Fxo Gateway

    6. Upgrade the VoIP FXO gateway VoIP FXO gateway supports remote download via TFTP for updating the new ROM file. Regarding new version release, please contact local distributor for more information. TFTP/FTP server It is necessary to prepare the TFTP/FTP server program on the host PC as TFTP/FTP server.
  • Page 44 -method to decide using TFTP or FTP as file transfer server. “0” stands for TFTP, while “1” stands for FTP. -ftp if users choose FTP in above item, it is necessary to specify pre-defined username and password when upgrading files.

  • Page 45: Appendix: Web Configuration

    Appendix: Web configuration Web management simple user guide The initial version for HTTPD web management interface provides user to configure easily rather than command operating method through RS-232 / TELNET. The configuration function and step are similar with the way through command line. Please refer to the manual for more information.
  • Page 46 Step 2. Input the login name and password Login name: root / administrator Password: None (just press Enter in default value) The web interface main screen...
  • Page 47 Step 3. Start configure Most of all commands displayed in console / telnet are transfer to web interface. The most important commands are Network Interface, H323 Information, Commit Data and Reboot System. The method is as the same as command mode. 1.1 Network Interface IP Address: Set IP Address Subnet Mask: Set the Subnet Mask...
  • Page 48 1.2 H323 Information Mode: Select GK mode or Peer-to-Peer mode Gatekeeper IP Address: Set Gatekeeper IP Address Gateway Type: Set Register Type to GK (Gateway / Terminal) Registered Prefix: Set Prefix Number as E.164 number Registered Alias: Set Registered Alias as H323 ID Gatekeeper Discovery , RTP Port, Time to Live (TTL), Gatekeeper finding port, RAS Port, Response Timeout, Connection Timeout: For Advanced User Only...
  • Page 49 1.3 System Config Keypad Type: Select different DTMF Keypad Type (For Advanced User) Dial Plan: Set DTMF digit limitation (0 is for any digits) Inter Digit Time: Set the DTMF inter digit time (second) End of Dial: Digit type of end of dialing. ( 0:No end of dialing, 1:[*] button, 2:[#] button ) 2nddial: This command is necessary for setting one time dial method use.
  • Page 50 1.4 Voice Setting (For Advanced User) Frame Size: It got wrong order with “Codec Priority”. Select the Codec Priority. (For Advanced User) Codec Priority: It got wrong order with “Frame Size”. Select the packet size in sending process. (For Advanced User) G.723 Silence Suppression: Enable / Disable (For Advanced User) Volume: Adjust the volume in “Voice”...
  • Page 51 1.5 Phone Pattern (For Advanced User)
  • Page 52 1.6 Support Functions (Both side must support) T.38: Enable for T.38 FAX Fast Start: Enable to do Fast Start H.245 Tunneling: Enable to open H.245 Tunneling...
  • Page 53 1.7 Phone Book (For Peer-to-Peer mode only) Input the Name, IP Address and E.164 No. for the destination device. Please Note: The E.164 No. will be carried together to the destination side.
  • Page 54 1.8 Type Of Service Adjust the parameter in IP Header for router identity purpose. If the version has PPPoE function, ToS is not available.
  • Page 55 1.9 Hot Lines Select HOST Port and set Destination Address. The Remote Number is subject to the Destination’s configuration.
  • Page 56 1.10 PPPoE...
  • Page 57 1.11 Password First select login name as root or administrator, then enter current password , new password and confirm new password again.
  • Page 58 1.12 ROM Upgrade TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Server IP Address: Set FTP server IP address FTP Login: Set FTP login name and password Target File Type: Select which sector of Gateways to upgrade...
  • Page 59 1.13 flash Clean Press CLEAN will clean all configurations of Gateways and reset to factory default value. Once execute this function, user must re-configure all other commands except IP Address.
  • Page 60 1.14 Commit Data After configuration, user has to commit data then reboot machine. It is an important step after every configuration.
  • Page 61 1.15 Reboot System After commit configuration, user has to REBOOT device. It is an important step after every configuration.
