Do not disassemble the Network Do not drop the Network Camera. Camera. Do not insert sharp or tiny objects into the Network Camera. Package Contents IP8130 IP8131 Power Adaptor (+12V, 1A) Camera Stand Software CD Warranty Card Quick Installation Guide Screws...
Physical Description Front Panel IP8130 Status LED Lens Microphone MicroSD/SDHC/ SDXC Card Slot IP8131 Lens Status LED IR LEDs Microphone Item LED status Description Steady Red Power on and system boot Red LED off Power off Blink Green every 1 sec.
Back Panel The back panels are identical for both models. Reset Button Power Cord General I/O Socket Terminal Block Ethernet 10/100 RJ45 Socket Audio GND Audio Out Audio out cable is user-supplied. EN - 3...
Install Camera to Stand Attach the camera to stand and orient the shooting angle. If preferred, use the included screws to secure the the camera stand to a mounting surface. Network Deployment LAN Connection 1. If you have external devices such as sensors and alarms, make connections from general I/O terminal block.
“Next” button to continue the program. Installation Wizard 2 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN. 4. After a brief search, the main installer window will pop up. Double-click on the MAC address that matches the one printed on the camera label or the serial number on the package box label to open a browser management session with the Network Camera.
