Vivotek IP8130 Specification

Cube Network Camera
IP8130/31/30W/31W
1MP • Compact Size •
802.11n WLAN / WPS (IP8130W/31W)
VIVOTEK IP8130/31/30W/31W are compact cube cameras
designed for indoor surveillance. The elegant design makes it
an ideal solution for offices, shops and homes. A built-in
microphone further increases the level of surveillance by
r e c o r d i n g s o u n d w i t h i n a 6 m e t e r r a d i u s . M o r e o v e r, t h e
IP8131/31W are equipped with IR LEDs and IR-cut filter,
providing clear video in completely dark environments.
The IP8130/31/30W/31W support t he industry-standard H.264
compression technology, drastically reducing file sizes and
c o n s e r v i n g v a l u a b l e n e t w o r k b a n d w i d t h . M o r e o v e r, t h e
I P 8 1 3 0 W / 3 1 W b o a s t 8 0 2 . 11 b / g / n c o m p a t i b l e w i r e l e s s
connection, making installation easier and more cost-efficient.
T h e W P S f u n c t i o n o f I P 8 1 3 0 W / 3 1 W m a k e s w i r e l e s s
configuration easy and straightforward. Together with the
multi-lingual 32-channel recording software ST7501, users can
s e t u p a n e a s y - t o - u s e I P s u r v e i l l a n c e s y s t e m w i t h e a s e .
VIVOTEK also provides the smart phone application iViewer,
both on iPhone and Android phones, enable users to monitor
live video off-site.
Features
● 1-Megapixel CMOS Sensor
● Compact Design
● Real-time H.264 and MJPEG Compression (Dual Codec)
● 30 fps @ 1280x800
● Two-way Audio
● Removable IR-cut Filter for Day and Night Function
(IP8131/31W)
● Built-in IR Illuminators, Effective up to 6 Meters
(IP8131/31W)
● Built-in MicroSD/SDHC Card Slot for On-board Storage
● Built-in IEEE 802.11b/g/n WLAN (IP8130W/31W)
● Wi-Fi Protected Setup (WPS) for Easy and Secure
Wireless Network Connection (IP8130W/31W)
Built-in Microphone
Home
On-board Storage
Office
