Knowing Your Design espresso ADvAnceD –
BArisTA eDiTion
A
B
C
D
E
F
G
A. Automatic Dosing: Select between single or double
filter basket.
B. Mechanical Clutch Protection
C. Grind Size Selector: 19 grind settings from fine to
coarse.
D. POWER Button: Surround illuminates when machine is
switched on.
E. Grind Amount Dial: Controls the amount of fresh
ground coffee dosed into the filter basket.
F. Integrated Removable Tamper: For consistent
tamping control.
G. Grinding Cradle: For directly dosing into portafilter.
H. Cup Warming Tray
i. CLEAN ME Light: Indicates when a cleaning cycle is
required.
J. Steam Light /Hot Water: Illuminates to indicate that
the steam or hot water function is selected.
K. Group Head
L. Extra-Tall Cup Height For Coffee Mugs
M. Removable Wet And Dry Coffee Separator
Drip Tray
N. Drip Tray Full Indicator
O. 250g Bean Hopper Capacity
P. Integrated Conical Burr Grinder: Stainless steel
conical burrs maximise ground coffee surface area for full
espresso flavour.
Q. Pressure Gauge: Monitors espresso extraction pressure.
R. PROGRAM Button: Personalise your espresso shot
volumes & also accesses Advanced Temperature functions.
40
H
i
J
K
L
M
N
