Program menu

Program switching times

MENU
PROGRAM
CHOOSE
CHANNEL
STANDARD
EXTRA
PROGRAM
PROGRAM 1
NEW
SWITCH TIME
PULSE
ON
SET HOUR
SET MINUTE
ON 7.30
EVERY DAY
14
EXTRA
DELETE
PROGRAM 2
CHANNEL 1
ALL
CYCLE
MONDAY
TUESDAY
COPY
SAVE
ADD TUESDAY
SAVED
SAVE
SAVED
Example: Switch on sports hall lighting from Mon-Fri, 7:30 to 12:00 hrs
Program standard program P0 switching times.
1. Press MENU. PROGRAM is displayed.
2. Confirm by pressing OK.
CHOOSE CHANNEL is displayed.
3. Confirm CHANNEL 1 by pressing OK.
STANDARD PROGRAM P0 is displayed.
4. Confirm by pressing OK.
NEW is displayed.
5. Confirm by pressing OK.
SWITCH TIME is displayed.
6. Confirm by pressing OK.
Select ON (for switch-on times).
7. Confirm by pressing OK.
The display shows SET HOUR.
Repeat all steps for the switch-off time however instead of selecting ON with
enter 12:00 for hour and minute.
8. Use the
or
keys to enter hour,
minute, (07:30) and confirm
by pressing OK.
EVERY DAY is displayed.
Press
to select MONDAY.
9. Confirm by pressing OK.
COPY is displayed.
10. Confirm by pressing OK.
ADD TUESDAY is displayed.
11. Confirm by pressing OK and also confirm
the days Wednesday, Thursday and Friday
by pressing OK.
12. Continue with
to SAVE is displayed.
Confirm by pressing OK.
select OFF and
GB
15
