Example: The standard program switches
on the street lighting independent of the
astro times. A night time interruption is
programmed from 23:00 hrs to 04:00 hrs.
Extra program 1 is active within the date range
from April 30, 12:00 hrs until May 12:00 hrs.
To ensure that the street lighting remains
switched on all night no night time
interruption is programmed in the extra
program 1.
Extra program P15
• Function: Fix ON
• Active in the programmed date ranges
Extra program P16
• Function: Fix OFF
• Active in the programmed date ranges
24
Example: The car park lighting is switched
ON and OFF at fixed times on Monday to
Friday according to astro times. The extra
program P 16 Permanently Off ensures that
the car park lighting is not switched ON, on
any public holidays.

Simulation menu

The Simulation allows you to manually step
through all the programmed events. A total
channel request is displayed during the
simulation. All channel switching programs
entered (standard and special program,
switching times, pulse and cycle programs) are
displayed in the time sequence in which they
are applied.
In the case of an astronomical channel
all astronomical switch-ONs and fixed
switch-ONs/switch-OFFs are displayed in
their time sequence.
MENU
SIMULATION
CHOOSE
CHANNEL
START YEAR
2013
21 01 2013
START MONTH
21 01 2013
START DAY
21 01 2013
SWITCH TIME
1. Switching
On 10:00
NEXT
Press MEnU. Using
select SIMULATION
and follow the indications on the display in
order to request all the switching applied
(see figure).
GB
25
