  • Page 1 Radio/Navigation TravelPilot RNS 149 Installation instructions...

  • Page 2: Installation Instructions

    Installation instructions Information on proper For other vehicles with vehicle ISO Safety information plugs, use the vehicle-specific ISO functioning – Faulty installation or servicing of this adapter cables, e.g. for Audi, Skoda, equipment may result in malfunc- To ensure that the TravelPilot functions VW with active antennas (Order-No.
  • Page 3 For vehicles without a DIN compart- the right and left (you will hear a loud cable (Order-No. 7 607 621 129) from ment, Blaupunkt offers vehicle-specif- click). your dealer. You will find information ic installation kits for 50/52 mm units...
  • Page 4 Installation instructions pressure on the side of the plug (see 5. Connection diagrams Fig. 7). Power connection to the Note: Once the handles have locked vehicle ISO standard plug ..Fig.1/2 into place, they cannot be removed Power connection to the vehicle-specific plug ....
  • Page 5 Installation instructions 7 607 621 126 4 Ohm 4 Ohm 4 Ohm 4 Ohm Tel.-Mute (active low) Fig.1 Fig.4 7 607 621 129 GPS antenna Bracket Fig.2 Fig.5 GPS antenna Fig.3 Fig.5 Radio antenna...
  • Page 6 Installation instructions Fig.6 Fig.6a 90° O.K. Fig.7 90° Fig.8...
  • Page 7 Installation instructions 7 10 13 16 19 9 12 15 18 Gala/Tacho Speaker out RR+ 8 11 14 17 20 — Tel.-Mute (active low) Speaker out RR- — — RFLS Speaker out RF+ — Permanent +12V Speaker out RF- — Aut.
  • Page 8 Installation instructions Control cable (Power Antenna +) The control cable is the connected positive output for auxiliary components e.g.: power antennas, (maximum load < 150 mA). Important! Do not connect the control cable to terminal 15 (Plus connected) or terminal 30 (continuous plus). Relais Wheel sensor (required for vehicles without...
