TravelPilot RGN 08
7 612 001 147
8 622 401 437 (GB)3.98
7 612 001 147
Installation notes for authorired service
workshopsIn
8 622 401 437/02.98
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TravelPilot RGN 08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blaupunkt TravelPilot RGN 08

  • Page 1 TravelPilot RGN 08 7 612 001 147 8 622 401 437 (GB)3.98 7 612 001 147 Installation notes for authorired service workshopsIn 8 622 401 437/02.98 - 1 -...
  • Page 2: Table Of Contents

    Table of contents Safety information ................3 Installation and connection regulations ..............3 Product information ....................3 Notes on the operation of the equipment ..............3 Preparing for installation .................... 3 Installing the navigation unit (Fig.1) ..........3 Mounting location for the navigation unit ..............3 Positive connection ....................
  • Page 3: Safety Information

    CD into the CD drive. Use the enclosed installation ma- Product information terial in order to mount the navigation unit. See Fig. 1 The TravelPilot RGN 08 navigation system is equipped with an integrated gyroscope. Following the entry and activation of Positive connection...
  • Page 4: Important Instructions For Connecting The Speedometer Signal

    The connection is made with the back-up light signal cable, If necessary, use protective sheathing to protect the antenna see parts included in the delivery, item :, yellow plug to yel- cable from being pinched. low jack of the sensor adapter cable (item 8) to the vehicle The adherent surface of the antenna must be free of dirt, snow, back-up light.
  • Page 5: Installation Tolerances For The Wheel Sensor

    be free of rust, dirt, grease and water. Clean the inside of the wheel rim thoroughly. To ensure that the glue adheres properly, the rim must be at room temperature. After thoroughly cleaning the rim and perhaps allowing it to warm up, glue the magnetic strip onto the marked spots over the entire circumference parallel to the outer edge of the rim, Fig.
  • Page 6: Rgn 08 Service Menu

    Activating the service menu AUXILIARY MENU 1. Turn on the car radio and press the AUX key to enter the NAVI AUX menu. 2. Now press the following keys one after another: 9, 5 and 7. After approximately 8 sec. the service menu will appear on the screen.
  • Page 7: Scope Of Delivery

    Scope of delivery 1 Navigation unit with integral gyro and GPS receiver 2 GPS-antenna 3 Fixings 4 8 618 841 985 Adapterkabel voor sensor- interface, ca. 25 cm 5 8 618 841 412 DC cable, 6 m 6 8 618 842 033 Reversing light cable, 4.5 m (RFLS) 7 8 618 841 988 8 618 841 105...
  • Page 8: Technical Data

    gelb weiß Technical data Basic navigation unit 8 618 841 994 with integrated gyro, GPS receiver and CD-ROM player Rated voltage (Urat) 14 V DC Rated current (I) Typically 0.55 A (Imax 1.05 A) Stand-by current Typically 0.35 A Speech output/volume Max.
  • Page 9: Fig.1-4

    Fig.1 Fig. 2 Fig. 4 Fig. 3 8 622 401 437 - 9 -...
  • Page 10 Fig.12 2 914 551 015 Sensor-middle max. 10 Magnetic strip Fig.13 Fig.10 Fig.14 10˚ max. 25 mm Interface Fig.15 90 mm Wheel rim 8 618 841 475 (1,5 m) Magnetic strip Fig.16 max. 20 max. 20 Metal holder max. 25 mm Magnetic strip Fig.18 a Fig.11...
  • Page 11: Connecting Of The Sensors

    Connection of the sensors GPS antenna, Navigationsgrundgerät 8 618 841 994 brown can- cable KL. 15 yello orange black white KL. 30 RC 07 RFLS Reversing light signal, Reverse = 12 V 12 V Info IN 4,5 m cinch -cable (NF) 6m Bremen/New York Sped impuls can-adapter cable...
  • Page 12: Connecting Rgn 08+Cdc F07+Rc 07

    RGN 08 + CDC F07 + RC 07 NF - Navi can - cable 6m or 2m CDC F07 1 2 V Bremen New York Opto connection wiring CDC Fo7 RC 07...
