Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS Built-in Oven OB76SD & OB76DD models NZ AU 590586C 07.14... -
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Electrical shock hazard To avoid hazard, follow these instructions carefully before installing or using this appliance. Before carrying out any work on the electrical section of the appliance, it must Please make this information available to the person installing the appliance - doing so could be disconnected from the mains electricity supply. -
Page 3: Prior To Installation
If, after following the instructions given, correct performance cannot be achieved, please contact your nearest Fisher & Paykel Authorised Service Centre, Customer Care, or contact us through our local website listed at the end of this document. PARTS SUPPLIED Screws (2) for OB76SD (4) for OB76DD Spacers (2) for OB76SD... -
Page 4: Product Dimensions - Single Ovens
PRODUCT DIMENSIONS - SINGLE OVENS FRONT SIDE Product dimensions (mm) overall height of product overall width of product overall depth of product (excluding handle and dials) height of chassis width of chassis depth of chassis depth of oven frame and control panel (=distance between front of chassis and front of oven door, excl. - Page 5 CABINETRY DIMENSIONS - SINGLE OVENS 16-20 mm 39 mm Electrical supply min. 2 mm PROUD INSTALL 16-20 mm 39 mm min. 2 mm SIDE FLUSH INSTALL Important! Important! Make sure the cavity is completely sealed FLUSH INSTALLATION with no gaps. The depth of the control panel (G) is larger than This is to ensure the oven cooling system conventional ovens.
-
Page 6: Product Dimensions - Double Ovens
PRODUCT DIMENSIONS - DOUBLE OVENS FRONT SIDE Product dimensions (mm) overall height of product 1232 overall width of product overall depth of product (excluding handle and dials) height of chassis 1218 width of chassis depth of chassis depth of oven frame and control panel 16-20 mm (=distance between front of chassis and front of oven door, excl. - Page 7 CABINETRY DIMENSIONS - DOUBLE OVENS 16-20 mm 39 mm Electrical supply min. 2 mm PROUD INSTALL 16-20 mm 39 mm min. 2 mm FLUSH INSTALL Important! Important! Make sure the cavity is completely sealed FLUSH INSTALLATION with no gaps. The depth of the control panel (G) is larger than This is to ensure the oven cooling system conventional ovens.
- Page 8 DISCARD PACKAGING RESPONSIBLY Single model shown for illustration purposes only Important! When you remove the oven from the carton be careful not to damage the lower trim. The trim is important for both ventilation and to ensure the door opens fully without obstruction. lower trim Make sure you remove the Long Trim from the packaging.
-
Page 9: Secure The Oven To The Cabinetry
This oven must be connected to the mains power supply only by a suitably qualified person. This oven must be earthed. Model code Max Power Voltage (V) (kW) OB76SD 4.25 50 Hz 220 - 240 V~ OB76DD 8.50 50 Hz... - Page 10 REFIT THE DOOR(S) Important! Do not lift the oven by the door handle. Refit the door following the sequence in Step 7 in reverse order. Double oven models only: Refi t both doors. FLUSH INSTALLATION ONLY - REPLACE THE LOWER TRIM WITH THE SUPPLIED LONG TRIM Unscrew and remove the installed lower trim Replace with the...
-
Page 12: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Installer’ s name: Make sure the oven is level and securely fitted to the cabinetry. Installer’ s signature: Check the lower trim is undamaged. Installation company: Open the (lower) oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim.
