Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS Built-in Oven OB76SD & OB76DD models NZ AU www.fisherpaykel.com 590586E 10.15... -
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Electrical shock hazard Save these instructions for the local inspectors use. ● ● Before carrying out any work on the electrical section of the appliance, it To avoid hazard, follow these instructions carefully before installing or using this appliance. ●... -
Page 3: Parts Supplied
PARTS SUPPLIED Screws Long Trim (1) (2) for Single oven models (to be fitted in a flush installation) (4) for Double oven models Spacers (2) for Single oven models (4) for Double oven models PRIOR TO INSTALLATION The benchtop and oven cavity are square and level, and are the required dimensions. ●... -
Page 4: Product Dimensions - Single Ovens
PRODUCT DIMENSIONS - SINGLE OVENS FRONT PROFILE OB76SD PRODUCT DIMENSIONS Overall height of product Overall width of product Overall depth of product ( excludes handle and dials) Depth of oven front and control panel ( excludes handle and dials) Depth of chassis... - Page 5 PLAN min. 2 mm IMPORTANT! FLUSH INSTALLATION The depth of the control panel (D) OB76SD CABINETRY DIMENSIONS is larger than conventional ovens. Ensure you have created a 39 mm recess in cabinetry. Minimum inside width of cavity If flush installing, you need to...
-
Page 6: Product Dimensions - Double Ovens
PRODUCT DIMENSIONS - DOUBLE OVENS FRONT PROFILE OB76DD PRODUCT DIMENSIONS Overall height of product 1232 Overall width of product Overall depth of product ( excludes handle and dials) Depth of oven front and control panel ( excludes handle and dials) Depth of chassis (does not include oven front) Height of chassis... - Page 7 CABINETRY DIMENSIONS - DOUBLE OVENS PROUD INSTALL 16-20 mm 39 mm Electrical supply min. 2 mm FLUSH INSTALL 16-20 mm 39 mm PLAN min. 2 mm IMPORTANT! FLUSH INSTALLATION The depth of the control panel (D) is larger than conventional ovens. Ensure you have created a 39 mm recess in cabinetry.
- Page 8 DISCARD PACKAGING RESPONSIBLY Single model shown for illustration purposes only Oven may vary IMPORTANT! When you remove the oven from the carton be careful not to damage the lower trim. The trim is important for both ventilation and to ensure the Lower trim door opens fully without obstruction.
-
Page 9: Secure The Oven To The Cabinetry
This oven must be earthed. ● ● MODEL MAX POWER (KW) VOLTAGE (V) CODE OB76SD 4.25 50 Hz 220 - 240 V~ OB76DD 8.50 50 Hz 220 - 240 V~ We recommend that the power outlet is located in the right rear corner of the Nameplate cabinet cavity. - Page 10 REFIT THE DOOR(S) IMPORTANT! Do not lift the oven by the door handle. 1 Refit the door following the sequence in Step 7 in reverse order. Double oven models only: Refit both doors. FLUSH INSTALLATION ONLY - REPLACE THE LOWER TRIM WITH THE SUPPLIED LONG TRIM Unscrew and remove the Replace with the installed lower trim...
-
Page 11: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the (lower) oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. - Page 12 www.fisherpaykel.com Copyright © Fisher & Paykel Appliances 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
