INSTALLATION AND OPERATION MANUAL
EPA Certified
Wood-Burning
Fireplace Insert

Save These Instructions

For Future Reference
P/N 900105-00, Rev. NC, 12/2013
P900105-00
A French manual is available upon request. Order P/N 900106-00.
Ce manuel d'installation est disponible en francais, simplement en faire la demande. Numéro de
Report No. 050-S-10b-4
• Hot! Do not touch! The glass and surfaces of this appliance will
• Carefully supervise children in the same room as appliance.
la pièce 900106-00.
This appliance must be properly installed and operated in order to prevent the
possibility of a house fire. Please read this entire installation and operation
manual before installing and using your wood stove. Failure to follow
these instructions could result in property damage, bodily injury or
Portland
even death. Contact your local building or fire officials to obtain
US
be hot during operation and will retain heat for a while after
shutting off the appliance. Severe burns may result.
Wood Fireplace Insert
Model Canyon™ C310
a permit and information on any installation requirements
and inspection requirements in your area.
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Canyon C310 and is the answer not in the manual?

Questions and answers

Summary of Contents for IronStrike Canyon C310

  • Page 1: Save These Instructions

    INSTALLATION AND OPERATION MANUAL EPA Certified Wood-Burning Fireplace Insert Save These Instructions For Future Reference P/N 900105-00, Rev. NC, 12/2013 P900105-00 Wood Fireplace Insert Model Canyon™ C310 A French manual is available upon request. Order P/N 900106-00. Ce manuel d’installation est disponible en francais, simplement en faire la demande. Numéro de la pièce 900106-00.
