- Page 1 OWNER’S MANUAL ES-500T Series Soundbars...
- Page 2 ES-500T Series Soundbar Owner's Manual pg.2 www.snapav.com Support: 866.838.5052...
-
Page 3: Recommended Amplifier Power
ES-500T Series Soundbar Owner's Manual OVERVIEW Welcome to Episode Speakers. We appreciate your purchase and are committed to providing the highest- ® quality products possible. The Episode Soundbar models are a superb choice for almost every type of home theater or home ®... -
Page 4: Installation
ES-500T Series Soundbar Owner's Manual INSTALLATION SPEAKER PLACEMENT The ES-500T-SNDBR is designed to be the Left, Center, and Right speakers of a home theater surround system. For most applications, placement should be below a flat screen TV on a cabinet top or shelf. Other options for placement include On-Wall using the included bracket, or attached to a Flat Panel mount using the optional Strong mount bracket. -
Page 5: Attaching The Feet
ES-500T Series Soundbar Owner's Manual Attaching the Feet Non-Inverted Inverted To ensure that the Soundbar will not slip when using the Kickstand Kickstand kickstands, (2) rubber feet have been included. The feet must be installed when using the kickstand. Place the feet 3”... -
Page 6: Attaching The Wall Bracket
ES-500T Series Soundbar Owner's Manual Attaching the Wall Bracket Note: For ease of installation of the bracket and the Soundbar, we recommend that the TV be removed from the mount. This allows for the Soundbar to be placed properly. Before Installing the Mount • Locate and install the TV mount. - Page 7 ES-500T Series Soundbar Owner's Manual Installing on a Flat Panel Mount The ES-500T-SNDBR can be mounted directly to a Flat Panel Mount with the Strong™ SM-SBAR-BKT (available separately). Using the Flat Panel mount bracket allows for the speaker to move with the TV when mounted to articulating arm mounts.
-
Page 8: Connecting And Calibrating
WARRANTY Limited Lifetime Warranty Episode Soundbar Speakers have a Lifetime Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified or disassembled. -
Page 9: Specifications
ES-500T Series Soundbar Owner's Manu SPECIFICATIONS Model ES-500T-SNDBR-40 ES-500T-SNDBR-50 Woofer Construction 4" anodized aluminum cone w/ 4" anodized aluminum cone w/ High Temp Voice Coil High Temp Voice Coil Woofer Magnet Diameter 35mm OD Neo magnet 35mm OD Neo magnet Voice Coil Size 35mm (1.25") - Page 12 130121-1350 © 2013 Episode...
