Model:
SOHO-B-CEB
SOHO-N-CEB
SOHO-P-CEB
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT spray aerosols in the vicinity of this
appliance while it is in operation.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This is a room sealed appliance and no other ventilation is
required than what is provided.
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11
NOTICE
• Leave this manual with
party responsible for use
and operation.
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• DO NOT place articles on or against this appliance.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
These instructions are only valid if the following country symbol is
on the appliance. If this symbol is not present on the appliance,
it is necessary to refer to the technical instructions which will
provide the necessary information concerning the modifi cation
of the appliance to the conditions of use for the country.
These instructions are valid for the following countries: GB
Owner's Manual
Installation and Operation
0086
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOHO-N-CEB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Heat & Glo SOHO-N-CEB

  • Page 1 This is a room sealed appliance and no other ventilation is required than what is provided. These instructions are valid for the following countries: GB Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 2 Save this manual for future reference. Heat & Glo, a brand of Hearth & Home Technologies, Inc. 7571 215 Street West, Lakeville, MN 55044 Copyright 2011 • Printed in U.S.A. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 3: Congratulations

    Consult instructions before installa- tion and use of this appliance. XXXXXXXX Serial: DO NOT REMOVE OR COVER THIS LABEL. XXXX-XXX Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 4: Table Of Contents

    D. Blower ........48 A. Vent Termination Minimum Clearances ....22 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 5 E. Contact Information ......72 = Contains updated information. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 6: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645C 12-29-10 Page 1 of 2 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 7 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645C 12-29-10 Page 2 of 2 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 8: Listing And Code Approvals

    Columns highlighted in gray = The gas control valve supplied with this product is approved for a maximum inlet pressure of 37 mbar. For pressures over 37 mbar, an in line pressure regulator must be installed upstream from the gas control valve. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 9: User Guide

    DECORATIVE DOORS (NOT SHOWN) SECTION 2.D. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 9.B. MANTEL SECTION 5.D HEARTH CLEAR SPACE SECTION 2.C. GRATE Figure 2.1 General Operating Parts Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 10: Clear Space

    For more information refer to the instructions supplied with your decorative door or front. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 11: Control Module Operation

    SELECTOR SWITCH MODULE RESET STATUS INDICATOR LED SWITCH FLAME HI/LO SWITCH NG/LP SETTING Figure 2.5 Location of Module Reset Switch - DF-Soho-CE Front Figure 2.3 Control Module Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 12: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 13: After Fireplace Is Lit

    Wall above appliance feels hot to No action necessary. This appliance ships with a non-combustible material attached. Specifi ca- the touch. tions of the attached non-combustible material are listed in Section 1.E. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 14: Maintenance And Service

    • Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 15: Maintenance Tasks-Qualifi Ed Service Technician

    11.A for information related to the gas valve and gas sary. Refer to Section 14.E for log placement instructions. pressure settings. • Verify correct log placement and no fl ame impingement causing sooting. Correct as necessary. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 16 • Verify that there is not a short in fl ame sense circuit by checking continuity between pilot hood and fl ame sensing rod. Replace pilot as necessary. Figure 3.1 IPI Pilot Flame Patterns Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 17: Installer Guide

    IN CEILING JOISTS (SECTION 8.C) OPTIONAL WALL SWITCH SECTION 12.C. MANTEL AND MANTEL LEG (SECTION 5.D) SURROUND HEARTH EXTENSION GAS LINE (SECTION 11) Figure 4.1 Typical System Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 18: Design And Installation Considerations

    Reciprocating saw Manometer Flat blade screwdriver Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female connection (for optional fan). Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 19: Framing And Clearances

    1,3 cm ALCOVE INSTALLATION TOP VENT, ONE 90º ELBOW MINIMUM Centimeters 84,1 74,0 118,7 89,2 Figure 5.1 Appliance Locations Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 20: Constructing The Appliance Chase

    Opening Opening Platform to Ceiling Floor Flooring Appliance Appliance Appliance (Flue Pipe) (Height) (Depth) (Width) Height 21,9 111,8 29,2 75,2 71,1 91,4 Figure 5.2 Clearances to Combustibles Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 21: Mantel And Wall Projections

    Combustible Mantel Legs or Wall Projections 1,3 cm TOP VIEW MINIMUM 7,3 cm MINIMUM UNLIMITED Figure 5.4 Clearances to Mantel Legs or Wall Projections (Acceptable on both sides of opening.) Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 22: Termination Locations

    53.1°-56.3° ............2 13 56.3°-59.0° ............2 29 59.0°-60.3° ............2 44 *.91 M minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 23 All gravity air intakes within .91 m of a termination cap must be a minimum requirements. of .30 m below the termination cap. Figure 6.3 Minimum Clearances for Termination Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 24: Vent Information And Diagrams

    45º elbows (see Figure 7.1). • Horizontal runs of vent do not require vertical rise; horizontal runs may be level. Vertical 8-1/2 in. (21,6 cm) Horizontal Figure 7.1 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 25 11 ft. 3,35 m 5 ft. 1,52 m 14 ft. 4,27 m Maximum = 38 ft. (11,58 m) Maximum = 14 ft. (4,27 m) INSTALLED HORIZONTALLY Figure 7.4 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 26 = 6 ft. (1,83 m) Maximum *H = 12 ft. (3,66 m) Maximum = 32 ft. (9,75 m) Maximum = 36 ft. (10,97 m) Maximum Figure 7.5 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 27 Failure to keep insulation or other material away from vent pipe may cause over heating and fi re. For alternative installations, other than depicted, contact your dealer for further information. Figure 7.6 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 28 If venting over 18 feet (5,49 m), the break away portion should be left in place and the small hole should be used. VERTICAL TERMINATION BAFFLE Figure 7.7 BREAK AWAY PORTION Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 29: Flue System Approvals And Installations

    SUPPORT PIPE LENGTH WALL FIRESTOP 90 DEGREE ELBOW WALL BRACKET CEILING FIRESTOP Flue system termination kits SLP SERIES SLP-TRAP2 SLP-TVHW DVP-FBHT Figure 7.8 Flue Components and Terminations Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 30 7 ft. 2,13 m 5 ft. 1,52 m 14 ft. 4,27 m Maximum = 38 ft. (11,58 m) Maximum = 14 ft. (4,27 m) INSTALLED HORIZONTALLY Figure 7.10 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 31: Vent Clearances And Framing

    * Shows center of fl ue framing hole. The center of the hole is 2,54 cm above the center of the horizontal fl ue pipe. Figure 8.2 Wall Penetration Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 32: Install The Ceiling Firestop

    BEFORE OR AFTER INSTALLATION OF VENT SYSTEM 3 FASTENERS PER SIDE CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.4 Installing the Attic Shield Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 33: Install Attic Insulation Shield

    • Bend all tabs inward 90º around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 34: Appliance Preparation

    Figure 9.5 This is a view from the front of the unit when not using an 90 degree elbow directly off the top of the unit. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 35: Installation Of Non-Combustible Facing Material

    Hearth & Home Technologies. 96 cm 81 cm Figure 9.6 Complete Installation of Non-combustible Facing Material NON-COMBUSTIBLE FACING MATERIAL SUPPLIED LEFT SIDE OF APPLIANCE Figure 9.7 Attaching Non-combustible Facing Material Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 36: Securing And Leveling The Appliance

    • Secure the appliance to the fl oor by inserting two screws through the pilot holes at the bottom of the appliance. Figure 9.8 Proper Positioning, Leveling and Securing of a Appliance Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 37: Covers Removal For Servicing

    • Unscrew the brackets at both ends of the burner and (1,3 cm) the top two screws locating the pilot bracket (see Figure Full open SOHO-B-CEB 9.10). Slide the burner away from the burner orifi ce. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 38: Installing Vent Pipe (Slp Pipe)

    Use care when removing termination cap from slip pipe. If slip section seals are bro- ken during removal of the termination cap, vent may leak. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 39: Assemble Slip Sections

    • Only outer pipes are sealed, sealing the inner fl ue is not required. • All unit collar, pipe, slip section, elbow and cap outer fl ues shall be sealed. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 40: Disassemble Vent Sections

    Figure 10.8. • Pull carefully to separate the pieces of pipe. Figure 10.7 Rotate Seams for Disassembly Figure 10.8 Align and Disassemble Vent Sections Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 41: Install Support Brackets

    • The pipe opening of the fi restops MUST BE placed Figure 10.11 Hole and New Framing Members towards the bottom of the fi restop. • Continue the fl ue run through the fi restop. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 42: Flue Termination

    • The small leg in the shield rests on top of the fl ue to properly space it from the pipe section (see Figure 10.14). Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 43: Heat Shield Requirements For Horizontal Termination

    • Caulk the perimeter of the fl ashing where it contacts the roof surface. See Figure 10.17. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 44: Assemble And Install Storm Collar

    Figure 10.18 Assembling the Storm Collar SCREWS CAULK Figure 10.20 Figure 10.20 Figure 10.19 Assembling the Storm Collar Around the Pipe Figure 10.19 Assembling the Storm Collar Around the Pipe Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 45: Gas Information

    Columns highlighted in gray = The gas control valve supplied with this product is approved for a maximum inlet pressure of 37 mbar. For pressures over 37 mbar, an in line pressure regulator must be installed upstream from the gas control valve. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 46 fl ame. Fittings and connections could have loos- Figure 11.1 ened during shipping and handling. WARNING! Risk of Fire! DO NOT change valve settings. This valve has been preset at the factory. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 47: Electrical Information

    TO OPTIONAL COMPONENTS OPTIONAL ON/OFF WALL SWITCH ORANGE GREEN (PILOT) BLACK (MAIN) BATTERY PACK 6V DC (C X 4) BROWN GROUND Figure 12.1 IPI Wiring Diagram /RC300CE Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 48: Blower

    fi replace. The access hole for connecting the service wires is found on the right exterior side of the unit. E. Control Module Operation See Section 2.I for Control Module Operation. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 49 The RC300CE is approved for interior installation and should not be used in exterior applications. • Keep remote control out of reach of children. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 50 Figure 12.7 Remote in Housing Figure 12.5 Temperature Scale 5. Close the housing door. See Figure 12.8. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 51 7 min. ON, 12 min. OFF FAN CORD FAN CORD LEARN BUTTON Figure 12.11 Programming RC300CE AUX 300 AUX 300 MODULE MODULE Figure 12.10 Plug Fan into AUX300CE Module Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 52 Use the SELECT button to select the current Select feature. Use the UP and DOWN arrows to toggle through the menu functions and value selec- tions in the submenus. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 53 AUX2 settings will be restored to the previous setting. NOTICE: The system will remember the previous FLAME HEIGHT setting and will automatically adjust after 10 seconds. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 54 • Press and hold the MENU and UP arrow buttons simul- taneously for 4 seconds to enable or disable the child lock feature. NOTICE: No functions will be usable until child lock feature is disabled. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 55 At control module, turn off fi replace by sliding the ON/OFF/ Remote control or control REMOTE switch to OFF. Warning! Risk of Burns! Fireplace is module failure hot. Use caution when accessing module. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 56: Finishing

    fl ow through louvers, operation of louvers or doors, or access for service. • Facing and/or fi nishing materials must never overhang into the glass opening. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 57: Framing And Finishing Instructions

    fi nished with paper tape. Let the Taping Coat properly cure before applying subse- quent Finish Coats. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 58: Appliance Setup

    Hearth & Home Technologies-approved optional acces- sories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty. DO NOT MODIFY THIS APPLIANCE Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 59: Log Placement Instructions

    Step 3. Place Log #3 (SRV2111-702) so the top rests on Log #1 against Log #2. The base slot on Log #3 will fi t over the locating tab on the front right hand side. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 60: Install Media Rock Kit

    fi replace and sliding it back until it contacts the back of the fi replace. See Figure 14.7. FIREBOX LINER BASE PAN Figure 14.9 LOCATING TABS 6. Reinstall the glass frame and front. Figure 14.7 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 61: Ipi Module Reset Switch

    Figure 14.12 TWO SCREWS Figure 14.10 2. Bend metal bracket as indicated in Figure 14.11. Bend at location shown Figure 14.11 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 62: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. d. Module voltage output / Valve/Pilot Verify battery voltage is at least 5.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 5.7. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 63 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 64: Reference Materials

    GAS LINE ELECTRICAL ACCESS ACCESS Location Centimeter Location Centimeter 74,0 29,2 64,3 29,2 94,5 27,9 74,2 14,2 10,5 16,8 94,6 11,5 83,2 58,6 Figure 16.1 Appliance Dimensions Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 65: Maintenance Tasks

    4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and fl ashing remains intact. Remote controls 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 66: Vent Components Diagrams

    51 - 152 SLP-PIPE SLP-WS SLP12A 5 - 30 51 - 305 Wall Shield Firestop SLP-FS SLP-HVS Ceiling Firestop Horizontal Pipe Support Figure 16.2 SLP Series Vent Components Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 67 Support Box-Black Termination Cap SLP-DCF-BK SLP-WT-BK SL-2DVP Ceiling Firestop Wall Thimble-Black Adapter Black 35,2 cm 24,1 cm 35,6 cm DRC-RADIUS Cap Shield Figure 16.3 SLP Series Vent Components Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 68 38,1 cm 26,7 cm 27,6 cm SLP-HRC-SS SLP-HRC-ZC-SS HORIZONTAL TERMINATION CAP 30,5 cm 17,8 cm 39,4 cm SLP90 SL-2DVP DVP-FBHT DVP-FBHT Figure 16.4 SLP Series Vent Components Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 69 Refer to Valve page Glass Assembly GLA-SOHOCE Mesh Assembly 2077-011 Decorative Front DF-SOHOCE-BK Module Heat Shield 2111-166 Reset Switch Assembly 2111-060 Additional service part numbers on the following page. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 70 Burner Orifi ce B (#61C) 582-861 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 500mA~10A 3/4" long Additional service part numbers on the following page. Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 71 Black MEDIA-BK-GEMS Rock Media White MEDIA-WH-GEMS River Rock MEDIA-STONES Black SohoCE-ONYX Rock Media with Liner and Flame pan White SohoCE-OPAL River Rock SohoCE-Rock Wireless Wall Switch RC100-HNG Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
  • Page 72: Contact Information

    5647340, 5890485, 5941237, 5947112, 5996575, 6006743, 6019099, 6053165, 6145502, 6170481, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729 or other U.S. and foreign patents pending. 2000-945 Printed in U.S.A. - Copyright 2011 Heat & Glo • SOHO-B-CEB, SOHO-N-CEB, SOHO-P-CEB • 2111-980 Rev. F • 8/11...
