Heat & Glo SOHO24B Service Parts
  1. Manuals
  2. Brands
  3. Heat & Glo Manuals
  4. Indoor Fireplace
  5. SOHO24B
  6. Service parts
Heat & Glo SOHO24B Service Parts

Heat & Glo SOHO24B Service Parts

24 x 24 direct vent fireplace
Hide thumbs Also See for SOHO24B:
1
2
3

Advertisement

Quick Links

Download this manual See also: Owner's Manual
10
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
ITEM
1
Heat Shield
2
Non-combustible Board (Outside)
Bracket Non-combustible Board
Non-combustible Board (Inside)
3
Surround
4
Heat Shield Retainer
5
Refl ective Panel
6
Stone Placement Jig
7
Pilot Cover (Outer)
8
Pilot Cover (Inner)
9
Base Pan
10
Glass Door Assembly
11
Valve/ Burner Assembly
12
Junction Box
13
Wire, Wall Switch
Additional service part numbers appear on following page.
Service Parts
24 x 24 Direct Vent Fireplace
4
5
6
7
8
9
DESCRIPTION
Beginning Manufacturing Date: Aug 2007
1
2
3
11
COMMENTS
SOHO24B
Ending Manufacturing Date: Active
13
12
Stocked
at Depot
PART NUMBER
2137-138
2111-148
2111-128
2077-148
2077-112
2137-134
2137-135
2137-140
2137-137
2137-136
2137-129
GLA-SOHO24B
Refer to valve page
4021-013
2045-024
Y
Y
Y
08/12
