Soho-N-AU
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This is a decorative room sealed appliance and no other ventila-
tion is required than what is provided.
This appliance may exhibit slight carbon deposition.
• CAREFULLY SUPERVISE children in same room as
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer if the barrier is not present or help is needed
to properly install one.
These instructions are only valid if the following country symbol is
on the appliance. If this symbol is not present on the appliance,
it is necessary to refer to the technical instructions which will
provide the necessary information concerning the modifi cation
of the appliance to the conditions of use for the country.
These instructions are valid for Australia.
Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09
Installer's Guide
Installation and Operation
A G A
C E RT IF IE D
7509
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
fi replace.
materials away.
0063-06
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo Soho-N-AU

  • Page 1 This appliance may exhibit slight carbon deposition. These instructions are valid for Australia. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 2 We recommend that you record the following pertinent information about your appliance. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location on appliance: ____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ _____________________________________________________________________________________________ Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 3: Table Of Contents

    D. Contact Information ......41 = Contains updated information. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 4: Listing And Code Approvals

    This appliance must be installed in accordance with the materials. rules in force. NOX Class 5 for G20, NOX Class 5 for G31 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 5: Getting Started

    Any such action may cause a fi re hazard. Noncorrosive leak check solution One 1/4 inch female connection (for optional fan). 1/2 - 3/4 inch length, #6 or #8 Self-drilling screws Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 6: Framing And Clearances

    In addition to these framing dimensions, also reference the following sections: • Clearances and Mantel Projections (Sections 3.C and 11.B). • Flue Clearances and Framing (Section 6). Figure 3.1 Appliance Locations Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 7: Constructing The Appliance Chase

    Sides of Front of Opening Opening Opening Opening Platform to Ceiling Floor Flooring Appliance Appliance Appliance (Flue Pipe) (Height) (Depth) (Width) Height 1118 1330 Figure 3.2 Clearances to Combustibles Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 8: Termination Locations

    In a staggered installation with both gas and wood terminations, the wood termination cap must be higher than the gas termination cap. Figure 4.1 Minimum height from roof to lowest discharge opening Figure 4.3 Staggered Termination Caps Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 9 2.7 m below the termination cap. 3. All gravity air intakes within 2.7 m of a termination cap must be a minimum of .31M foot below the termination cap. Figure 4.4 Minimum Clearances for Termination Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 10: Flue Information And Diagrams

    45º runs, 305 mm of diagonal is equal to 216 millimeters horizontal run and 216 millimeters vertical run. A length of straight pipe is allowed between two 45º elbows (see Flue diagrams). Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 11: Flue Diagrams

    1.8 m 910 mm 2.7 m 1.2 m 3.7 m 1.5 m 4.6 m V + H Maximum = 11.9 m Maximum = 4.6 m INSTALLED HORIZONTALLY Figure 5.4 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 12 1.2 m 910 mm 1.8 m 910 mm 1.8 m 1.2 m 2.4 m 1.2 m 2.2 m = Maximum = 11.9 m Maximum = 4.6 m Figure 5.5 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 13: Vertical Termination

    910 mm 610 mm 1.2 m 910 mm 1.8 m 1.2 m 2.4 m 1.8 m 4.6 m + H Maximum = 11.9 m Maximum = 4.6 m Figure 5.7 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 14 610 mm 610 mm 910 mm 910 mm 1.5 m 1.2 m 2.1 m 1.5 m 4.3 m Maximum = 11.9 m Maximum = 4.3 m INSTALLED HORIZONTALLY Figure 5.8 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 15: Flue Clearances And Framing

    Non-Combustible Wall Penetration If the hole being penetrated is surrounded by noncombustible materials such as concrete, a hole with diameter 254 mm greater than the pipe is acceptable. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 16: Vertical Penetration Framing

    • Field construct additional shield height if insulation is deeper than height of attic ATTIC SHIELD INSTALLED ATTIC SHIELD INSTALLED shield. BELOW CEILING ABOVE CEILING Figure 6.4 Installing the Attic Shield Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 17: Appliance Preparation

    • Secure the appliance to the framing by using nails or screws through the nailing tabs. 1118 mm NAILING TABS Figure 7.1 Proper Positioning, Leveling and Securing of a Appliance Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 18: Installing Flue Pipe

    (2) Improper support may allow fl ue to sag or separate. sheet metal screws. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 19: Installing Firestops And Horizontal Termination Cap

    fl ue section found on the termination cap. Note: Where required, an exterior wall fl ashing is available. When penetrating a brick wall, a brick extension kit is avail- able for framing the brick. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 20: Install Roof Flashing And Vertical Termination Cap

    Explosion Risk. Inspect external fl ue cap regularly. • Ensure no debris blocks cap. • Combustible materials blocking cap may ignite. • Restricted air fl ow affects burner operation. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 21 Figure 8.7 Assembling the Storm Collar Around the Pipe until it rests on the roof fl ashing. Caulk around the top of the storm collar (see Figure 8.5). Figure 8.6 Assembling the Storm Collar Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 22: Gas Information

    9.8 MJ/h (Min. rate) during shipping and handling. Max. Input (NETCV) 4.0 kW Burner Injector DMS 50 (Ø1.78mm) Pilot Injector Primary Aeration Setting Log Effect 11 mm Open Rocks/Pebbles 7 mm Open Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 23: Electrical Information

    BATTERY PORT (4 AA BATTERIES) THERMOCOUPLE BLOCK (CONNECTED TO ON/OFF BACK OF VALVE) SWITCH VALVE PILOT GAS LINE CONNECTED TO BACK OF VALVE Figure 10.1 Electronic Ignition Wiring Diagram Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 24: Finishing

    OPENING OF FIREPLACE • See Section 1 for combustible/non-combustible defi nitions. Figure 11.2 Minimum vertical and maximum horizontal dimensions of combustibles above appliance when using the DF-SOHOCE-BK dress guard. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 25: Appliance Setup

    • Use this material to give the appliance a realistic ash bed. • Save the remaining ember materials for use during appliance servicing. The embers provided should be enough for multiple applications. Figure 12.1 Ember Placement Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 26: Positioning The Logs

    Step 3. Place Log #3 (SRV2111-702) so the top rests on Log #1 against Log #2. The base slot on Log #3 will fi t over the locating tab on the front right hand side. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 27: Install Media Rock Kit

    F. Install Media Rock Kit 4. Set the rock tray on top of the base pan. See Figure 12.8. This kit is used in place the logs in a SOHO-N-AU. Alter- nate media and refl ective fi rebox liner is provided.
  • Page 28: Glass Assembly

    Replace the glass door on the appliance. Pull out and latch the two glass assembly latches into the groove on the glass frame on the bottom and top edges. GLASS ASSEMBLY BOTTOM LATCH Figure 12.10 Glass Assembly Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 29: Operating Instructions

    • Glass door MUST be in place and sealed before operating appliance. • Only use glass door certifi ed for use with appliance. • Glass replacement should be done by qualifi ed technician. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 30: Lighting The Fireplace

    2. Remove batteries from receiver. fuel or fuel combustion. Keep burner and control compart- ment clean. See installation and operating instructions accompanying fi replace. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 31: After Appliance Is Lit

    Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the appliance. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 32: Troubleshooting

    Verify that spark gap from ignitor to pilot hood is .430 mm. large. Module is not Verify control box is securely grounded to metal chassis of fi replace. grounded. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 33: Maintaining And Servicing Appliance

    444 Swan Street Richmond VIC 3121 Phone: 03 9429 5573 Fax: 03 9427 0031 Jetmaster Australia 10 Martin Avenue Arncliffe NSW 2205 Phone: 02 9597 7222 Fax: 02 9597 7622 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 34 4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and fl ashing remains intact. Remote controls 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 35: Reference Materials

    Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. ØN GAS LINE ELECTRICAL ACCESS ACCESS Appliance Dimensions Table Location Millimeter Location Millimeter Figure 16.1 Appliance Dimensions Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 36: Log Set Assembly

    SOHO-N-AU Service Parts List Beginning Manufacturing Date: June 2009 Service Parts Diagram Ending Manufacturing Date: Active Log Set Assembly 13 Rock Media Option Part number list on following page. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 37: Service Parts List

    Mineral Wool Embers 050-721 Rope Ring 045-455 Surround 2077-112 Remote Control REM-DLX-CE Junction Box (Optional) 2078-025 6 V Adaptor (Optional) 2098-144 Additional service part numbers on the following page. Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 38 2111-186 Thermocouple block 2098-146 Valve N 2098-138 Flex Ball Valve Assembly 2098-022 Module 2098-142 Block Control Wire 2098-148 Switch Assembly 2098-145 Control Cable 2098-143 Burner Orifi ce (#50C) 582-850 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 39: Limited Lifetime Warranty

    C. Limited Lifetime Warranty Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 40 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
  • Page 41: Contact Information

    6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408; (Australia) 543790;586383; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2009 Heat & Glo • SOHO-N-AU • 2197-900 Rev. C • 9/09...
