Technical Specifications
Environmental Specifications
Note: Your SAS Expander Card requires adequate airflow to operate reliably. The
recommended airflow is 200 LFM (linear feet per minute) minimum, to avoid operating
above the maximum ambient temperature. Additionally, when chassis mounting the
SAS Expander Card with screws (rather than installing in a PCIe slot), airflow must run
horizontal to the fins of the heat sink. Forced airflow is required. Contact Adaptec
Support for more information about the chassis mount option.
• The thermal and atmospheric characteristics are:
Ambient temperature with forced airflow
Relative humidity
Altitude
• The storage and transit environment conditions are:
Ambient temperature with forced airflow
Relative humidity
Mean Operating Time Between Failures number (MTBF): electrical
components
Note: Ambient temperature is measured 1" from the expander processor.
DC Power Requirements
Bus Type
PCIe
Current Requirements
Product
SAS Expander Card AEC-82885T
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00301-01-A Rev A, Issue
Serial Attached SCSI (SAS) Expander Card Installation and User's Guide
Description
DC Voltage
Typical Current
1.34A @ 12 VDC
0 °C to 55 ° C
20% to 80%, non-condensing
Up to 3,000 meters
-30 °C to 80 ° C (dry bulb)
5% to 90%, non-condensing
1M hours at 40 ° C
Requirements
12V ± 8%
24
