  • Page 2 All other brand or product names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies or organizations. Version as of: 15 February 2011 Part number: 02.9665.0001 0 VL1100CD ERS Luminaire User’s Manual ©2003 - 2011 Vari-Lite, a Philips group company. All Rights Reserved.
  • Page 3 OREWORD How To Obtain Warranty Service A copy of the Vari-Lite Limited Warranty was included in the shipping package for this VARI❋LITE product. To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548) or +1-214-647-7880 or via e-mail at entertainment.service@philips.com request a Return Material Authorization (RMA) for warranty service.
  • Page 4 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Compliance Notice This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.

  • Page 5: Safety Notice

    WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST FIRE 1. VARI❋LITE luminaires have been designed for use with specific lamp types. The VL1100CD ERS luminaire requires a Philips lamp - 315W ceramic discharge, long-life lamp. Installing another type of lamp may be hazardous.
  • Page 6 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE TO UV RADIATION 1. Many VARI❋LITE luminaires use a lamp that produces UV radiation. DO NOT look directly at lamp. 2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired.
  • Page 7 OREWORD Sicherheitshinweise Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein.
  • Page 8 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL WARNUNG: HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG 1. Viele VARI❋LITE-Scheinwerfer verwenden die Lampentyp, der UV-Strahlen abgibt. SCHAUEN SIE NICHT direkt in die Lampe. 2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch sichtbare...
  • Page 9 OREWORD Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
  • Page 10 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL AVERTISSEMENT: DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE AUX RAYONS UV 1. Plusieurs luminaires VARI❋LITE utilisent une lampe qui produit des rayons UV. NE PAS fixer son regard sur la lampe.
  • Page 11 OREWORD Aviso sobre Seguridad Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto. Los símbolos de seguridad usados en este manual son los siguientes: CUIDADO, indica posibles daños al producto.
  • Page 12 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL ADVERTENCIA: INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN EXCESIVA DE RADIACIÓN ULTRA VIOLETA 1. Muchas luminarias VARI❋LITE usan un tipo de lámpara que produce radiación UV. NO mire directamente a la lámpara.
  • Page 13 OREWORD 02.96 65.000 1 0 15 Feb ru ary 201 1...
  • Page 14 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 15: Table Of Contents

    Standard Features ......................4 Model Specific Features....................4 Components Included Items......................5 Luminaire Overview ....................6 Accessories VL1100CD ERS Replacement Items/Accessories............7 Chapter 2. Installation Power and Data Cabling Requirements AC Power........................10 Current vs. Voltage....................10 Data Cables ........................ 11 Recommended Cable Types/Manufacturers............
  • Page 16 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Control Channel Functions ..................28 DMX Data Display ....................29 DMX Mapping Color Mixing......................30 Rotating Gobo Wheel....................31 Index/Rotation......................31 Shutter Mechanism ....................32 Luminaire Timing Timing Channel Information..................33 Updating Software USB Download and Programming Luminaires ............

  • Page 17: Introduction

    LCD Menu Display read-out. Example: Press [Up] / [Down] arrows until LAMP appears. Additional Documentation A service manual for Authorized VARI❋LITE Service Centers and technicians of the VL1100CD ERS luminaire is available in electronic (PDF) format: • VL1100CD ERS Luminaire Service Manual (02.9665.0010) - Testing, Troubleshooting, Component Replacement and Illustrated Parts Breakdown.

  • Page 18: Customer Service

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Note: Performing maintenance procedures may void the product warranty. Refer to the Vari-Lite Limited Warranty card included in the product shipping package for more information. For more information regarding DMX512 systems, refer to the following document available from United States Institute for Theatre Technology, Inc.

  • Page 19: Chapter 1. Description

    HAPTER Description This chapter contains descriptions of luminaire features and components, along with a list of accessories which are available. • Features • Components • Accessories 02.96 65.000 1 0 15 Fe bru ary 201 1...

  • Page 20: Features

    “Technical Specifications” on page Model Specific Features Each individual configuration has the following specific features: VL1100CD ERS Luminaire (20.9665.0001.02 - Black / 20.9665.0001.02.02 - White) • Four-blade shutter framing system. VL1100CD ERS Luminaire (20.9665.0001.03 - Black / 20.9665.0001.03.02 - White) •...

  • Page 21: Components

    The following illustration shows the included components for all models. Included Items Warranty Card Product Support Unpack & Quick 315W CDM Lamp Sheet Start Guide VL1100 CD ROM Product Neutrik PowerCon (User’s Manual) Registration AC Input Connector VL1100CD Luminaire 02.96 65.000 1 0 15 Feb ru ary 201 1...

  • Page 22: Luminaire Overview

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Luminaire Overview The following illustration shows the external luminaire components and controls. Base Provides hook mounting Input Panel holes and safety cable Power Input Provides DMX In and connection. Connector Thru, and AC Power connections.

  • Page 23: Accessories

    71.2568.0315 315W CDM Lamp - Philips 41.6010.XXXX VL1000 Gobo (specify pattern from Vari-Lite catalog to complete P/N). Note, VL1100CD luminaires use the same size gobos as VL1000 luminaires. ❋ Contact your Authorized VARI LITE Dealer or Vari-Lite customer service for assistance.
  • Page 24 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Notes 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 25: Chapter 2. Installation

    HAPTER Installation This chapter contains instructions for installation of all version of the VL1100CD ERS Luminaire. It includes connecting power and data, along with instructions for powering up the luminaire for the first time and addressing it within your system.

  • Page 26: Power And Data Cabling Requirements

    Power and Data Cabling Requirements AC Power WARNING: Do not power a VL1100CD ERS Luminaire from a dimmed circuit - even in "Non- Dim" mode. Dimmer and non-dim modules are not suitable sources of power because their output modifies the AC wave form. This may work for a short time, but will eventually result in power problems, luminaire mis-operation and/or failure.

  • Page 27: Data Cables

    NSTALLATION OWER AND ABLING EQUIREMENTS Data Cables The luminaire is equipped with two, 5-pin XLR connectors for DATA IN and DATA THRU (out) applications. DATA IN requires a 5-pin, female XLR connector and DATA THRU requires a 5-pin, male XLR connector. When purchasing or constructing data cables, it is important that not only the correct cable type be used, but also quality cable to ensure a reliable DMX512 system.

  • Page 28: Recommended Cable Types/Manufacturers

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Recommended Cable Types/Manufacturers These are only a few of the suitable cable types. Any quality EIA485, twisted pair, 120 ohm, shielded cable will also work. ∗ Type Pairs Jacket Temp (F) ZΩ...

  • Page 29: Dmx Termination Connector

    NSTALLATION OWER AND ABLING EQUIREMENTS DMX Termination Connector A male XLR DMX termination connector is required at the last luminaire (or "far end of the line") to prevent signal reflections. Signal reflections may cancel out the signal at certain line lengths, resulting in errors. The terminator is also necessary for software downloads and running tests on multiple luminaires.

  • Page 30: Installation Procedures

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Installation Procedures Installing Lamp In the event the lamp was packed separately during shipment, it will be necessary to install before use. WARNING: Ensure that power is completely removed from luminaire when installing lamp.
  • Page 31 CAUTION: with bare fingers. Socket Lamp Install lamp, firmly pressing into place. Figure 2-3: Installing VL1100CD Lamp in Socket Step 4. Re-install backcap, ensuring that alignment studs and holes are aligned (Figure 2-2). Step 5. Align lamp. (Refer to “Align Lamp For Maximum Beam Irradiance” on page 23.)

  • Page 32: Accessory Frame Holder

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Accessory Frame Holder An accessory frame holder is provided for the addition of a top hat or gel frame with silks, frosts or color correction if required. The frame holder is designed to fit a standard 7.5-inch gel frame or top hat.

  • Page 33: Hanging The Luminaire

    Step 2. Tighten hardware securely. Attach truss WARNING: hooks securely. Mega Claw Truss Hooks (not provided) VL1100CD Pan Tube Base Hook Hardware (not provided) Figure 2-5: Example VL1100CD Luminaire Truss Hook Installation 02.96 65.000 1 0 15 Feb ru ary 201 1...
  • Page 34 26.5" (67.3cm) 35.5" (90.2cm) 17.5" (44.5cm) 26" (66cm) Safety cable securing points on fixture. Figure 2-6: Example VL1100CD Luminaire Truss Hanging Installation 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 35: Connecting Data And Power

    NSTALLATION NSTALLATION ROCEDURES Connecting Data and Power A maximum of 32 luminaires may be connected in any one DMX data link. Note: This maximum limit applies to the luminaire "daisy chain" only. Your system or console may require fewer luminaires on a single data link path. Consult your console documentation for more information.

  • Page 36: Powering Up

    Power-Up and Configuration Overview First Power-Up When powering up a VL1100CD ERS Luminaire for the first time, the lamp type and shutter settings must be configured. This procedure will usually happen prior to delivery. However, in the event that it has not been done or if the Main Controller Board has been replaced, it will be necessary.

  • Page 37: Standard Power Up Procedure

    NSTALLATION OWERING Standard Power Up Procedure Use this procedure when powering up a luminaire that has already been configured. (Refer to “Power- Up and Configuration Overview” on page 20.) Note: Refer to Chapter 4: Menu System for detailed instructions on menu functions. CAUTION: Before applying power, be sure the luminaire is hung or positioned so that the head and yoke can move freely without restriction.

  • Page 38: Power Up And Configuration Procedure

    Step 2. For unconfigured luminaires, menu will display LampType. Press [Enter] to move to next level. Step 3. Press [Up]/[Down] to toggle options. For VL1100CD luminaires, you must choose CD option. Set selection by pressing [Enter]. Note: When CD is selected, the menu system will update to include the Dimmer, DMX, and Manual commands.

  • Page 39: Align Lamp For Maximum Beam Irradiance

    Figure 2-8: Lamp Alignment Screws Note: The nature of the CDM lamp used in the VL1100CD ERS Luminaire prevents it from restriking when it is hot after use. It takes approximately 15 minutes for the lamp to cool enough to restrike.

  • Page 40: Addressing

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Addressing Program Starting Address The DMX starting address is entered using the Menu Display. This address will be retained even if the power is removed. Note: Refer to Chapter 4: Menu System for detailed instructions on menu functions.

  • Page 41: Chapter 3. Operation

    HAPTER Operation This chapter contains instructions for operating the luminaire using DMX control and for updating the internal software. • DMX Operation • DMX Mapping • Luminaire Timing • Updating Software 02.96 65.000 1 0 15 Fe bru ary 201 1...

  • Page 42: Dmx Operation

    33032 (ccw min) - 65535 (ccw max) Beam 0 (small) - 255 (open) Focus Time 0-255 Color Time 0-255 Beam Time 0-255 Control 0-255 * Dimmer refers to an internal dimmer for VL1100CD Iris models. 15 Feb ru ary 201 1 02 .9 665.00 01 0...
  • Page 43 0 (open) - 255 (closed) Rotate Frame 0-255 128 center Focus Time 0-255 Color Time 0-255 Beam Time 0-255 Control 0-255 * Dimmer refers to an internal dimmer for VL1100CD Shutter models. 02.96 65.000 1 0 15 Feb ru ary 201 1...

  • Page 44: Control Channel Functions

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Control Channel Functions Control channel functions allow special actions such as reset, lamp on/off and partial recalibration. These must be executed with zero time transition or with timing disabled. Discrete values must be used;...

  • Page 45: Dmx Data Display

    512 bytes. It shows only the number of channels used for the given luminaire model in 16- bit enhanced mode. For example, a VL1100CD (shutter model) luminaire with an address of 40 will show DMX Channels 1-27 which would correlate to DMX Channels 40-66.

  • Page 46: Dmx Mapping

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL DMX Mapping Color Mixing The color mixing mechanism is a CYM subtractive color mixing system made up of a graduated color system for cyan, yellow, and magenta. Table 3-4: DMX Map For Cyan...

  • Page 47: Rotating Gobo Wheel

    : DMX M PERATION APPING Rotating Gobo Wheel Note: Gobos are sold separately. Contact your Authorized VARI❋LITE Dealer or visit the Vari-Lite web site, www.vari-lite.com, for available gobo patterns. The function operates in two modes: INDEX Mode and ROTATE Mode. The DMX values corresponding to these modes are as follows: •...

  • Page 48: Shutter Mechanism

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Shutter Mechanism For units with a shutter mechanism, the shutter is comprised of four frame blades that move independently or in unison. The entire assembly operates in a smooth, time-continuous motion using stepper motors (two per frame blade and one to rotate the entire shutter mechanism).

  • Page 49: Luminaire Timing

    PERATION UMINAIRE IMING Luminaire Timing Timing Channel Information Timing channel control improves the timed moves of certain groups of parameters. We provide three timing channels, one for Focus (Pan and Tilt), one for color parameters and one for beam parameters. Timing channels support time values of up to six minutes.
  • Page 50 Timing channels can be set in either % or 0-255 (DMX) modes, with the following values assigned: Table 3-11: VL1100CD Timing Channels Map % Value...
  • Page 51 PERATION UMINAIRE IMING Table 3-11: VL1100CD Timing Channels Map % Value = Seconds 10.2 10.4 10.6 02.96 65.000 1 0 15 Feb ru ary 201 1...
  • Page 52 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Table 3-11: VL1100CD Timing Channels Map % Value = Seconds 15 Feb ru ary 201 1 02 .9 665.00 01 0...
  • Page 53 PERATION UMINAIRE IMING Table 3-11: VL1100CD Timing Channels Map % Value = Seconds 02.96 65.000 1 0 15 Feb ru ary 201 1...
  • Page 54 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Table 3-11: VL1100CD Timing Channels Map % Value = Seconds 15 Feb ru ary 201 1 02 .9 665.00 01 0...
  • Page 55 PERATION UMINAIRE IMING Table 3-11: VL1100CD Timing Channels Map % Value = Seconds 02.96 65.000 1 0 15 Feb ru ary 201 1...
  • Page 56 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Table 3-11: VL1100CD Timing Channels Map % Value = Seconds Follows Cue Data 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 57: Updating Software

    PERATION PDATING OFTWARE Updating Software USB Download and Programming Luminaires You can upgrade Vari-Lite luminaire operating software using the USB Luminaire Programming Kit (Vari-Lite part number 28.8500.0054, sold separately) for desktop computers and newer laptops equipped with USB 2.0 ports. The USB Luminaire Programming Kit can be ordered directly from your Authorized VARI❋LITE Dealer.

  • Page 58: Transferring Software From Luminaire To Luminaire

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Lists specific versions of downloaded software (on PC) Device Connection Status and USB Downloader Controls Click to download specific software version to connected luminaire(s) Click logo to go to Vari-Lite web site...
  • Page 59 PERATION PDATING OFTWARE A termination connector is used in this process. Refer to page 10 for more information regarding the construction of this connector. Master luminaire containing Luminaire 1 Luminaire 2 software version to download requiring update requiring update Data Thru Data Thru DMX Termination Connector Loopback Connector...
  • Page 60 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Notes 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 61: Chapter 4. Menu System

    HAPTER Menu System This chapter contains instructions for operating the luminaire using the Menu Display feature. • Menu Operation • Menu Functions • Self Tests 02.96 65.000 1 0 15 Fe bru ary 201 1...

  • Page 62: Menu Operation

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Menu Operation What Is the Menu System? The menu system is a programmable set of commands used to configure, address, operate, and test the luminaire. The menu system is controlled at the Menu Display available at the yoke leg.

  • Page 63: Menu Shortcuts

    YSTEM PERATION After 5 minutes of inactivity, the menu display will switch to its off state. Menu Shortcuts A few button combinations are provided as shortcuts for frequently used menu functions. These are as follows: • Lamp On - Press and hold [Up], then press [Enter]. (Arc and CD models only.) •...

  • Page 64: Menu Functions

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Menu Functions Menu System Overview The following is a graphic representation of the entire menu system. Manual value Address value Tilt value Dimmer* value Blue value Setup LampType Amber value...

  • Page 65: Menu System Function Chart

    YSTEM UNCTIONS Menu System Function Chart 1st Level 2nd Level 3rd Level 4th Level 5thLevel Address DMX DMX Address XXX Address value Setup LampType Incand Shutter? Config LAMP Lamp Options Power Lamp Power ON (default) System (Arc & CD Models Only) Configuration Power Up Lamp Power-up State Lamp OFF Lamp...
  • Page 66 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL 1st Level 2nd Level 3rd Level 4th Level 5thLevel Fixture Status Status/Error Display Scrolls error messages or displays OK Re-Cal Recalibrate Model Luminaire Model Type VL1100XX Model Type Lum Id Luminaire ID...
  • Page 67 YSTEM UNCTIONS 1st Level 2nd Level 3rd Level 4th Level 5thLevel Test ALL Test All Motors RUN TEST Run-Test in Progress Press [Menu] to System Test stop tests Pan/Tilt RUN TEST Run-Test in Progress Dimmer (Arc Only) RUN TEST Run-Test in Progress Blue RUN TEST Run-Test in Progress Amber...

  • Page 68: Menu Function Definitions

    Calibration On Configures arc luminaire so that lamp will strike after calibration procedure is complete. VL1100CD Model Sets menu option to VL1100CD luminaire (VL1100CD models only) Chan XXX DMX Channel Specifies DMX channel for display of current data value. Clear Clear Clears stored parameters and re-calibrates luminaire.
  • Page 69 YSTEM UNCTIONS Display Definition Purpose Inv Tilt Invert Tilt Reverses tilt action for special focus requirements. Lamp Lamp Accesses lamp power up options and information (Config). Lamp 1 Lamp Specifies test lamp operation (Test). Lamp 2 Lamp Specifies test lamp operation (Test). Inserts magenta to 30%. Lamp OFF Lamp is Off Configures arc luminaire so that lamp will not strike upon power up.
  • Page 70 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Display Definition Purpose Version Version Displays current software version (Date and Time in two pages). Specifies that the luminaire contains the shutter accessory. Zoom Zoom Function Specifies zoom function for manual control (Manual) or for testing (Test).

  • Page 71: Self Tests

    YSTEM ESTS Self Tests Running Parameter Tests The luminaire is capable of running self tests by using the TEST menu functions. Note: If a DMX data stream is present on the luminaire’s DMX input connector, Self Test and Manual control is overwritten by the DMX command protocol and neither (Self Test and Manual) will operate. When running tests on multiple luminaires, a loopback connector is required at the master luminaire (first in link) and a male termination connector is required at the last luminaire in the link.
  • Page 72 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Movement Disable The Movement option allows pan and tilt to be disabled so that the luminaire can be placed in any position for testing without movement occurring. In order to regain full control of the luminaire, Movement will need to be enabled after testing.

  • Page 73: Appendix A. Troubleshooting And Maintenance

    PPENDIX Troubleshooting and Maintenance This appendix provides instructions for troubleshooting and performing routine maintenance which may be necessary during the life of the luminaire. • Troubleshooting • Routine Maintenance WARNING: All routine maintenance procedures are to be performed with power completely removed from the luminaire.

  • Page 74: Troubleshooting

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Troubleshooting Error Messages If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu Display will cycle through any applicable error message(s) until the end of the list is reached. To review the error messages again, it will be necessary to access them using the Status function.

  • Page 75: Troubleshooting Guide

    Lamp failed to strike after repeated attempts - Replace lamp Note: *The nature of the CDM lamp used in the VL1100CD ERS Luminaire prevents it from restriking when it is hot after use. It takes approximately 15 minutes for the lamp to cool enough to restrike.

  • Page 76: Routine Maintenance

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Routine Maintenance Cleaning Optical Lenses and Gobos WARNING: Remove power from luminaire before performing maintenance. The front lens and gobos may require cleaning after extended use. Use only isopropyl alcohol, along with a soft, lint-free cloth to clean glass components.
  • Page 77 ROUBLESHOOTING AND AINTENANCE Step 7. Re-install front cover. Inside Edge - orient toward center of wheel Rotate until open end of carrier is up CAUTION: Gear Closed End Open End Gobo MUST be oriented with the mirrored side towards the luminaire’s lamp. If not oriented properly, gobo will break.

  • Page 78: Lamp Replacement

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Lamp Replacement For lamp replacement procedure, refer to “Installation Procedures” on page 15 Feb ru ary 201 1 02 .9 665.00 01 0...

  • Page 79: Appendix B. Technical Specifications

    PPENDIX Technical Specifications Mechanical Zoom Optics Continuously variable field angle in imaging range from 19° to 36°, super zoom angles to 70° is programmable over a timed range of 2 seconds to 20 minutes. Color Mixing System A fully cross-fading CYM color system. All motors utilize a noise reducing, 50kHz. drive system that quiets operation during movement and also while static.

  • Page 80: Operational

    ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Reflector Precision glass reflector with dichroic cold mirror coating. Operational Power Requirements 3 to 6 Amps depending upon input voltage. 100 - 240 VAC 50/60 Hz. Operational Temperature -20° to 122°F (-29° to 50°C) Cooling Free convection cooling when hung.
  • Page 81 ROUBLESHOOTING AND AINTENANCE Photometric VL1100CD ERS Luminaire - 315 CDM Lamp (All data taken with a seasoned light source at 20 hours of life.) FIELD ANGLE FIELD DIAMETER BEAM ANGLE BEAM DIAMETER CANDELA (degrees) (degrees) (cd) 19.0 .335 13.0 0.228 99,700 26.0...
  • Page 82 ❋ VARI LITE - VL1100CD ERS L ’ UMINAIRE ANUAL Notes 15 Feb ru ary 201 1 02 .9 665.00 01 0...
  • Page 84 Vari-Lite 10911 Petal Street Dallas, Texas 75238 USA 1-877-VARI-LITE ❋ 1-214-647-7880 www.vari-lite.com. ©2011 Vari-Lite, a Philips group company. All Rights Reserved.
