Silicon Graphics 750 Quick Start Guide
6
Table 2 describes the rear panel I/O ports and features that are indicated in Figure 1.
Table 2 Rear Panel I/O Ports and Features
Number Item
1 9-pin serial port
2 PS/2-compatible mouse connector
3 PS/2-compatible keyboard connector
4 USB ports (2)
5 Line input port
6 Line output port
7 LAN (10baseT/100baseTX Ethernet)
8 Cooling fans
9 AC power input socket
10 Disk adapter: QLogic 12160 PCI SCSI HBA (LVD 160 MB/s (Ultra3) or SE Fast-20)
11 Video output
Note: The Silicon Graphics 750 system has a QLogic 12160 SCSI Host Bus Adapter
installed with two external SCSI connectors accessible from the system rear panel. The
components in Figure 1 are for illustration purposes only. The actual card location may
vary slightly.
