I. Pure Bridge
The setting page displayed as below will appear while you
choose Pure Bridged mode. The gray item means it can be
operated without any configuration.
Figure 4-3 RFC2684 Bridged Connection-Application of Pure
Bridge
II. Static IP
The setting page displayed as below will appear while you
select Static IP setting mode. Please fill the corresponding field with
the IP address and network mask provided by ISP. The default
setting of route is "Disabled", and the Gateway IP address is null.
The recommended setting is to enable default route and enter the
Gateway IP address provided by ISP.
Huawei Technologies Proprietary
35
