SmartAX MT882 ADSL Router
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Huawei SmartAX MT882

Summary of Contents for Huawei SmartAX MT882

  • Page 1 SmartAX MT882 ADSL Router User Manual...
  • Page 2 HUAWEI SmartAX MT882 ADSL Router User Manual V200R001 Huawei Technologies Proprietary...
  • Page 3 Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Administration Building, Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, P. R. China Postal Code: 518129 Website: http://www.huawei.com Email: support@huawei.com...
  • Page 4 Copyright © 2005 Huawei Technologies Co., Ltd. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks , HUAWEI, SmartAX are trademarks of Huawei Technologies Co., Ltd.
  • Page 5 About This Manual Release Notes The product version corresponds to the manual is SmartAX MT882 ADSL Router V200R001C01B021. Organization 1 MT882 Overview provides a brief description of MT882 and a list of features. 2 Hardware Installation introduces the hardware installation of MT882.

  • Page 6: Intended Audience

    Courier New II. Symbols Eye-catching symbols are also used in this manual to highlight the points worthy of special attention during the operation. They are defined as follows: Caution: Means reader be extremely careful during the operation. Huawei Technologies Proprietary...

  • Page 7: Environmental Protection

    Note: Means a complementary description. Environmental Protection This product has been designed to comply with the requirements on environmental protection. For the proper storage, use and disposal of this product, national laws and regulations must be observed. Huawei Technologies Proprietary...

  • Page 8: Table Of Contents

    3.1 When to Configure the MT882..........27 3.2 Configuring IP Settings on Your Computer......28 3.3 Accessing the Web-based Configuration Manager .... 28 3.3.1 Checking for Proxy Service ........29 3.3.2 Applying the LAN IP Address of MT882....29 Huawei Technologies Proprietary...
  • Page 9 4.12 Firewall Rules..............62 4.13 RIP ..................65 4.14 Administrator Setting............67 4.15 Time .................. 69 4.16 System Setting ..............70 4.17 Firmware Upgrade ............71 4.18 Log ..................73 4.18.1 View Log..............73 4.18.2 Log Settings............74 Huawei Technologies Proprietary...
  • Page 10 5.7 RFC 2684 Route (IPoA) Configuration ....... 85 6 Troubleshooting Guide ............... 87 6.1 Quick Troubleshooting ............87 6.2 FAQs ................... 88 7 Technical Specifications............. 93 8 Appendix ..................95 8.1 Factory Default Settings............95 8.2 FCC ..................96 8.3 Abbreviations ..............99 Huawei Technologies Proprietary...

  • Page 11: Mt882 Overview

    Figure 1-1 shows the appearance of the MT882. Figure 1-1 Appearance 1.2 Parts of MT882 1.2.1 Front Panel Place the MT882 in a location where the LED indicators can be easily viewed. Huawei Technologies Proprietary...

  • Page 12: Led Status Description

    A valid LAN connection. orange light Blinking green or There is traffic over Ethernet. orange light Steady or The speed of data transfer is blinking green 10Mbit/s. light Steady or The speed of data transfer is blinking orange 100Mbps. light Huawei Technologies Proprietary...

  • Page 13: Rear Panel

    USB: USB port, connecting to PC or hub Ethernet: Ethernet port, connecting to PC or hub Reset: press this button for 3 seconds to restore the default setting. This operation will let you lose your customized setting. Please be careful when using Reset button. Huawei Technologies Proprietary...

  • Page 14: External Splitter

    Data rates up to 24 Mbps for downstream and 1.2 Mbps for upstream Friendly Web-Based graphical user interface configuration and management Supporting up to eight simultaneous virtual connections Widest range of DSLAM interoperability Built-in MIBs for SNMP management Huawei Technologies Proprietary...
  • Page 15 Upgradeable firmware through TFTP Easy to install and use Huawei Technologies Proprietary...

  • Page 16: Hardware Installation

    Web browser, such as IE, is installed. ® Web browser Microsoft Internet Explorer 5.0 or Netscape ® type Navigator 4.7 or above. Web browser Enable JavaScript settings NIC adapter Ethernet port Enable TCP/IP 2.1.2 Collecting ISP Information VPI, VCI Encapsulation type Protocol type Huawei Technologies Proprietary...

  • Page 17: Fixing Of The Mt882

    I. Install USB driver for Linux Firstly start RedHat 8.0, and then select “install all”. Log in under root. #cd /usr/src #ln –s linux-2.4.18-14 linux Copy original codes to /root/MT882. #cd /root/MT882 # make clean # make all Huawei Technologies Proprietary...
  • Page 18 Add alias eth1 VKGEther to /etc/modules.conf. # vi /etc/modules.conf Reboot linux, connect USB cable to ADSL. #cd /root/MT882 # insmod ./VKGEther #ifconfig eth0 down Huawei Technologies Proprietary...
  • Page 19 II. Install USB driver for MAC OS X 1. Install MT882 USB Driver for MAC OS X Firstly click on Installer, a screen with welcome information will be opened, shown as below: Press “Next” button to enter the Authentication screen, shown as below: Huawei Technologies Proprietary...
  • Page 20 Type in the administrator’s account and password and then press <OK> button to enter the next screen. Please read the content of License Agreement. If you agree with the License Agreement, press <Accept> button to start the installation. Huawei Technologies Proprietary...
  • Page 21 After completed the installation, click to select the option Restart now, and press <Finish> button. Your computer will be rebooted. 2. Configure MAC Network Click Apple Menu -> scroll down to select System Preference -> select Network, the opened screen as below: Huawei Technologies Proprietary...
  • Page 22 Start your Web Browser and Key in http://192.168.1.1 the URL/Address field to open up the Login Page for the user. Key in the username and password and click <OK> button to enter the Web GUI of MAC OS. Huawei Technologies Proprietary...
  • Page 23 3. Uninstall MT882 USB Driver for MAC Click and select Applications. Huawei Technologies Proprietary...
  • Page 24 Click to select MT882 Modem. Select Uninstall.app. Huawei Technologies Proprietary...
  • Page 25 Press <Next> button to start the uninstalling process. Type in the administrator’s account and password, press <OK> button. Huawei Technologies Proprietary...
  • Page 26 Restart Now and then click on <Finish> button to reboot your computer. III. Install USB driver for Mac OS 9.2 1. Install MT882 USB Driver for MAC OS 9.2 Firstly click on Installer.app, a screen with welcome information will be opened, shown as below: Huawei Technologies Proprietary...
  • Page 27 Press “Next” button to enter the next screen, shown as below: Please read the content of License Agreement. If you agree with the License Agreement, press <Accept> button to start the installation. Huawei Technologies Proprietary...
  • Page 28 After completed the installation, press <Finish> button. You can enjoy your DSL modem now! 2. Configure MAC Network Click Apple Menu -> scroll down to select System Preference -> select Network -> select TCP/IP, the opened screen as below: Huawei Technologies Proprietary...
  • Page 29 Start your Web Browser and Key in http://192.168.1.1 at the URL/Address field to open up the Login Page for the user. Key in the username and password and click <OK> button to enter the Web GUI of MAC OS 9.2. Huawei Technologies Proprietary...
  • Page 30 3. Uninstall MT882 USB Driver for MAC Click to select MT882 Modem. Huawei Technologies Proprietary...
  • Page 31 Select Uninstall.app. Press <Next> button to start uninstalling the process. Huawei Technologies Proprietary...
  • Page 32 Unplug the cable and click <OK> button. After the end of uninstalling process, select the option Restart Now and then click on <Finish> button to reboot your computer. Huawei Technologies Proprietary...
  • Page 33 To install the USB driver in Windows system, you must execute “MT882Driver.exe” contained on the CD-ROM, which is provided with the modem. Double click “MT882Driver.exe” to open the Setup Wizard window. Click <Next> button and ready to install. Huawei Technologies Proprietary...

  • Page 34: Connecting Adsl Line

    2.3.3 Connecting the Computer to the MT882 Use a straight-through cable to connect your PC and the MT882. You can connect the MT882 directly to a 10/100Base-TX Ethernet adapter card on your PC with the provided Ethernet cable as shown in Figure 2-1 Huawei Technologies Proprietary...

  • Page 35: Connecting Ethernet Lan To The Mt882

    Use a cross-over cable to connect the MT882 and the upstream port of a switch or hub. Be sure that the cable connecting the LAN to the MT882 does not exceed 100 meters. Huawei Technologies Proprietary...

  • Page 36: Powering On The Mt882

    You will see the Power LED indicator lights up, which indicates the device is powered on. After a few seconds, observe the LAN LINK indicator. Make sure the light is steady light, which indicates a valid connection between the router and your PC. Huawei Technologies Proprietary...

  • Page 37: Before Configuring The Mt882

    If network condition is changed by the modification of security, scale, line of communication, protocol and topology, for example, a Huawei Technologies Proprietary...

  • Page 38: Configuring Ip Settings On Your Computer

    MT882. 3.3 Accessing the Web-based Configuration Manager Once your PC’s IP settings allow it to access the Web-Based configuration manager, you can change the factory default settings to enable the MT882 to connect to Internet. Huawei Technologies Proprietary...

  • Page 39: Checking For Proxy Service

    The URL in the address bar should read: http://192.168.1.1. 3.3.3 Inputting the User Name and Password A new dialog box appears prompting you to input the user name and password required to access the Web-based configuration manager. Huawei Technologies Proprietary...
  • Page 40 To change this password, see 4 Web-Based Management. Note: Do not confuse the user name and password used to access the Web-based manager with the ADSL account and password needed for PPP connections to access your ISP’s network. Huawei Technologies Proprietary...

  • Page 41: Web-Based Management

    The left part of the page is wizard column, and you can enter the Web page of configuration or management through the hyperlink in wizard column. The right part of the page is the practical domain of configuration and management. Huawei Technologies Proprietary...
  • Page 42 Figure 4-1 GUI of Web-based configuration manager Huawei Technologies Proprietary...

  • Page 43: System View (Home Page)

    The System View read-only table on the Home Page displays a summary of various system settings and functions as described below. ADSL Line Status: displays the ADSL State, Data Path, DSP version, Operation Mode, and the status of Upstream and Downstream of the ADSL line. Huawei Technologies Proprietary...

  • Page 44: Wan Setting

    VPI default values of PVC. VCI: if you need any modification, please enter the VCI value provided by ISP. See the attached table for all the VCI default value of PVC. Encapsulation: you can select LLC or VC MUX. Huawei Technologies Proprietary...
  • Page 45 IP address and network mask provided by ISP. The default setting of route is “Disabled”, and the Gateway IP address is null. The recommended setting is to enable default route and enter the Gateway IP address provided by ISP. Huawei Technologies Proprietary...
  • Page 46 Default Route: this setting specifying the IP address above is used for default route of LAN. The data will be sent through WAN interface whenever a client in LAN accesses the Internet. The default setting of default route is “Disabled”. Huawei Technologies Proprietary...
  • Page 47 “Disabled”. IV. Save Click the Apply button to save the settings in the RAM. To save these configuration changes permanently, enter the Tools>System Setting page, and then click Save & Restart button to save new settings. Huawei Technologies Proprietary...

  • Page 48: Rfc2684 Routed Configuration

    VPI default values of PVCs. VCI: if you need any modification, please enter the VCI value provided by ISP. See the attached table for all the VCI default values of PVCs. Encapsulation: you can select the mode LLC or VC MUX. Huawei Technologies Proprietary...
  • Page 49 Default Gateway: enter the Gateway address provided by ISP. III. Save Click the Apply button to save the settings in the RAM. To save these configuration changes permanently, enter the Tools>System Setting page, and click Save & Restart button to save new settings. Huawei Technologies Proprietary...

  • Page 50: Ppp Configuration

    PPPoE. The parameters that need to be configured are described as below: PVC: the system provides 7 PVCs. Generally you can leave this set at the default value 0. This option is also used to create and configure new PVCs. Huawei Technologies Proprietary...

  • Page 51: Dhcp Configuration

    Tools>System Setting page, and click Save & Restart button to save new settings. 4.4 DHCP Configuration Click the DHCP of Home in the Wizard Column to set the DHCP configuration. MT882 can be set as DHCP server. Huawei Technologies Proprietary...
  • Page 52 Starting/Ending IP Address: enter the starting and ending IP address that will be provided through DHCP service. Lease Time: Select the lease time from the drop-down menu. It will determine how long your PC can use the IP address provided by DHCP server. Huawei Technologies Proprietary...

  • Page 53: Dns Configuration

    Multiple DNS addresses are useful to provide alternatives when one of the servers is down or encountering heavy traffic. ISPs typically provide primary and secondary DNS addresses, and may provide additional addresses. I. Configuration page Figure 4-9 DNS Configuration Huawei Technologies Proprietary...

  • Page 54: Nat Configuration

    Click the NAT of Home in the Wizard Column to set the NAT. NAT is enabled by default. You can enable or disable NAT by selecting the Enabled or Disabled option in the configuration page and applying the settings. Huawei Technologies Proprietary...
  • Page 55 (Universal Play and Plug). By default, it is enabled. VPN Pass-Trough: select it to enable or disable the VPN Pass-through with PPTP protocol and IPSec protocol. By default, it is enabled. III. Save Click the Apply button to save the settings in the RAM. Huawei Technologies Proprietary...

  • Page 56: Static Route

    WAN. This is used to specify that all packets destined for a particular network or subnet using a predetermined gateway. I. Configuration page Figure 4-11 Static Route Configuration II. Parameter explanation The explanation of parameters in the above windows is as below. Huawei Technologies Proprietary...

  • Page 57: Lan Setting

    (eth-0) as a node on your network; that is, its LAN IP address must be in the same subnet as the computers in your LAN. You can change the default LAN IP address and Net Mask to suit for your LAN. Huawei Technologies Proprietary...
  • Page 58 Local Domain Name: enter the local domain name if it exists. Note: The public IP address that ISP assigned is not LAN IP address. The public IP address identifies the WAN interface that the ADSL router connects to Internet. Huawei Technologies Proprietary...

  • Page 59: Virtual Server

    Global IP Address (the one assigned to your account by your ISP), using the specified TCP or UDP protocol and port number, and then redirect these requests to the server on your LAN with the Private IP address you specify Huawei Technologies Proprietary...
  • Page 60 Click Clear button to delete the entered server name. Private IP: enter the IP address of local PC providing the service of virtual server. Protocol Type: select the protocol to be applied. User can select a protocol from TCP and UDP, or both. Huawei Technologies Proprietary...

  • Page 61: Applications

    Restart button to save new settings. 4.10 Applications Click the Applications of Advanced in the Wizard Column to configure the special applications. Some special applications, such as network game, video conference, net phone, can be operated pass through the NAT. Huawei Technologies Proprietary...
  • Page 62 Trigger Port: enter the number of port which is to trigger the special application. The entered port number can be a single port, or a group of ports. Trigger Type: select the protocol while the special applications are to be triggered. Huawei Technologies Proprietary...

  • Page 63: Filters

    IP filter. Filters are used to deny or allow LAN computers to access the Internet. The unit can refuse some computers with the assigned IP or MAC addresses to access the Internet. Or it also may block users to access the restricted Web sites. Huawei Technologies Proprietary...

  • Page 64: Ip Filters

    IP address. The well-known ports are displayed on the "IP filter list". Please click the edit icon to enable them. You will only need to enter the LAN IP address of the computer(s) that will be denied to access Internet. Huawei Technologies Proprietary...
  • Page 65 I. Configuration page Figure 4-15 IP Filters Configuration Huawei Technologies Proprietary...
  • Page 66 WAN (Internet). If both are selected, then this rule will apply to packets that are being sent to PCs on both the WAN and your LAN. Schedule: select the time period for Internet user to access virtual server. Huawei Technologies Proprietary...

  • Page 67: Mac Filters

    4.11.2 MAC Filters This is to deny LAN computers to access the Internet. You can either manually add a MAC address or select the MAC address from the list of clients that are currently connected to the unit. Huawei Technologies Proprietary...
  • Page 68 Click Clear button to delete the entered name. MAC Address: the MAC address of the computer on the LAN side. DHCP Client: you may read the DHCP client's host name and MAC address listed here. Select the client computer Huawei Technologies Proprietary...

  • Page 69: Url Blocking

    Resource Locator (URL). A URL is a specially formatted text string that defines a location on the Internet. If any part of the URL contains the blocked word, the site will not be accessed and the Web page will not be displayed as well. Huawei Technologies Proprietary...
  • Page 70 URL Address: enter the URL that is to be blocked. III. Save Click the Apply button to save the settings in the RAM. To save these configuration changes permanently, enter the Tools>System Setting page, and click Save & Restart button to save new settings. Huawei Technologies Proprietary...

  • Page 71: Domain Blocking

    LAN accessing specific domains on the Internet. That is, it will deny or allow all requests such as http and ftp to a specific domain. I. Configuration page Figure 4-18 Domain Blocking Configuration II. Parameter explanation Disabled Domain Blocking: choose to it to disable Domain Blocking. Huawei Technologies Proprietary...

  • Page 72: Firewall Rules

    The Firewall enables you to protect the system against denial of service (DoS) attacks and other types of malicious accesses to your LAN. You can also specify how to monitor attempted attacks, and who should be automatically notified. Huawei Technologies Proprietary...
  • Page 73 MT882). For more information, see Managing the Black List below. Use Attack Protection: click the Allow button to use the built-in firewall protections that prevent the following common types of attacks: Huawei Technologies Proprietary...
  • Page 74 Max ICMP Count: sets the percentage of concurrent IP sessions that can be used for ICMP messages. If the percentage is exceeded, then older ICMP IP sessions will be replaced by new sessions as they are initiated. Huawei Technologies Proprietary...

  • Page 75: Rip

    Layer 3 routing devices on your local network or remote LAN. If your network does not employ another IP routing device, it will not be necessary to enable RIP. I. Configuration page Figure 4-20 RIP Configuration Huawei Technologies Proprietary...
  • Page 76 Send MultiCast: select it to enable or disable sending route information using MultiCast. III. Save Click the Submit button to save the settings in the RAM. To save these configuration changes permanently, Tools>System Setting page, and click Save & Restart button to save new settings. Huawei Technologies Proprietary...

  • Page 77: Administrator Setting

    Administrator has read/write ability on the Web page and can make some changes. You can change the Admin account password here for personal security. I. Configuration page Figure 4-21 Administrator Setting Huawei Technologies Proprietary...
  • Page 78 IP Address - enter the Internet IP address of the computer connected to the MT882. If the IP address is set to *, this allows all Internet IP addresses to access the ADSL Router. Port - the port number is used to access the MT882. Huawei Technologies Proprietary...

  • Page 79: Time

    The time can be set manually or the device can connect to a Network Time Protocol ( NTP ) server to retrieve the time. I. Configuration page Figure 4-22 System Time Setting Huawei Technologies Proprietary...

  • Page 80: System Setting

    I. Configuration page Figure 4-23 System Setting II. Parameter explanation Save: when clicking on Save, The current system settings can be saved as a file onto the local hard drive. The file will be saved as adslmodem.cfg. Huawei Technologies Proprietary...

  • Page 81: Firmware Upgrade

    MT882 to activate new changes. This button resets the device settings to the manufacturer’s default values. Any custom settings will be lost. 4.17 Firmware Upgrade Click the hyperlink Firmware Upgrade in the Wizard column to open the Firmware Upgrade page and update the system software. Huawei Technologies Proprietary...
  • Page 82 Check the file names and attempt to upload again. If the file still is not loaded, reboot the device and try again. Caution: Do not power off the MT882 during the firmware upgrade process. Otherwise, the configuration in the flash could be damaged. Huawei Technologies Proprietary...

  • Page 83: Log

    First: the first page of the log Last: the last page of the log Previous: ,moves back one log page. Next: moves forward one log page. Clear: clears the logs completely. Log Settings: brings up the page to configure the logs. Huawei Technologies Proprietary...

  • Page 84: Log Settings

    SMTP Server: the address of the SMTP (Simple Mail Transfer Protocol) server that will be used to send the logs. Log Type: select the type of activities that you want the ADSL Router to keep records. Huawei Technologies Proprietary...

  • Page 85: Save

    The diagnostics feature executes a series of test of your system software and hardware connections. Use this feature when working with your ISP to troubleshoot problems. Click the Diagnostics of Status in the Wizard Column to perform the basic diagnostics for system. Huawei Technologies Proprietary...
  • Page 86 This takes only a few seconds. The program reports whether the test passed or failed. A test may be skipped if the program determines that no suitable interface is configured on which to run the test. Huawei Technologies Proprietary...

  • Page 87: Traffic Statistics

    WAN (Wide Area Network) ports and the LAN (Local Area Network) ports. Click the Refresh button to update the counters and the Reset button to clear the counters. The traffic counter will reset when the device is rebooted. Huawei Technologies Proprietary...

  • Page 88: Service Configuration

    5 Service Configuration This section describes the configuration for six modes of SmartAX MT882 ADSL router device for ADSL online service. The contents include: Preparation for service configuration PPPoE PPPoA RFC 2684 Bridged (Pure Bridge) RFC 2684 Bridged (Static IP)
  • Page 89 VPI/ VPI/ user user name name PPPoE PPPoA Preparing passwo passwo None WAN IP None information Subnet Subnet VPI/VCI VPI/VCI None None mask mask Default Security Security Default None None gatewa Protocol Protocol gateway None None None Huawei Technologies Proprietary...

  • Page 90: Pppoe Configuration

    Configurations on the user PC IP Address It is recommended to set the mode as obtaining and Network an IP address automatically. Mask It is recommended to set the mode as obtaining a DNS server’s IP address automatically. Huawei Technologies Proprietary...

  • Page 91: Pppoa Configuration

    Configurations on MT882 It is recommended to enable the function of NAT. It is recommended to have DNS Relay function enabled. It is recommended to have DHCP Server function DHCP Mode enabled. Configurations on the user’s PC Huawei Technologies Proprietary...

  • Page 92: Rfc 2684 Bridged (Pure Bridge) Configuration

    LLC. Wan Type Select “RFC2684 Bridged”. Connection Select “Pure Bridge”. Type Configurations on the user PC PPPoE Before connecting to the Internet, the user shall Dial–up have PPPoE dial–up application installed on the Application Huawei Technologies Proprietary...

  • Page 93: Rfc 2684 Bridged (Static Ip) Configuration

    It is recommended to enable the function of NAT. It is recommended to have DNS Relay function enabled. And set DNS IP address provided by your ISP. It is recommended to have DHCP Server function DHCP Mode enabled. Huawei Technologies Proprietary...

  • Page 94: Rfc 2684 Bridged (Dhcp) Configuration

    Select “RFC2684 Bridged”. Connection Select “DHCP”. Type Default Route Select “Enable”. It is recommended to enable the function of NAT. It is recommended to have DNS Relay function enabled. And set DNS IP address provided by your ISP. Huawei Technologies Proprietary...

  • Page 95: Rfc 2684 Route (Ipoa) Configuration

    ISP. The value shall be provided by Encapsulation your ISP. Usually you can keep the default value: LLC. Select “RFC2684 Routed Wan Type (IPoA)”. IP Address The values shall be provided by and Subnet your ISP. Mast Huawei Technologies Proprietary...
  • Page 96 It is recommended to set the mode as obtaining an and network IP address automatically. mask It is recommended to set the mode as obtaining a DNS server’s IP address automatically. Note: For other advanced configurations, please refer to 4 Web-Based Management Huawei Technologies Proprietary...

  • Page 97: Troubleshooting Guide

    Adapters” is labeled with “?” or “!”. If it is, you may delete it and then click “Refresh” to reinstall. Otherwise, you may try the NIC in another slot. As a last resort, you have to replace the NIC. Huawei Technologies Proprietary...

  • Page 98: Faqs

    Q: I forget the username and password when I am to log into the Web-based Configuration Manager. Or I just can’t access the Web-based Configuration Manager. Please press reset button on the rear panel for 3 seconds to restore factory default settings of the MT882 Huawei Technologies Proprietary...
  • Page 99 Please make sure the file that you have downloaded is valid. Q: Why can’t I access the Internet by using virtual dialing through Microsoft’s Internet Gateway? Internet Gateway supports PPPoE itself. No other PPPoE terminal software shall be installed again. Huawei Technologies Proprietary...
  • Page 100 Totally two methods: 1) by the reset button on the rear panel of the device. Push it three times continuously to take the factory default setting into effect; 2) Select the option Factory Setting Reboot in the page of Save & Reboot and then click Submit button. Huawei Technologies Proprietary...
  • Page 101 Follow the figures below to complete the installation. Note that the MT882 needs the splitter for proper working. (1) Phone Socket (2~3) Phone (4) RJ-11 Tel Cable (5) Splitter (6~7) RJ-11 Tel Cable (8) Phone Jack (9) MT882 Figure 6-2 Connect Multiple Phones-1 Huawei Technologies Proprietary...
  • Page 102 (2) Phone Socket (3) Phone (4) RJ-11 Tel Cable (5) Splitter (6) RJ-11 Tel Cable (7) Phone Socket (8) RJ-11 Tel Cable (9) Splitter (10) RJ-11 Tel Cable (11) Phone Jack (12) MT882 Figure 6-3 Connect Multiple Phones-2 Huawei Technologies Proprietary...

  • Page 103: Technical Specifications

    Transfer downstream rate of 26 Mbps, and upstream rate of Rate 1.2 Mbps One RJ-11 ports for ADSL line connection External One USB port for USB cable connection Interface One RJ-45 port for 10/100 Base-T Ethernet connection Huawei Technologies Proprietary...
  • Page 104 Please make sure that your power adapter is in conformity with the sign in the rear panel (9V AC 1A or 9V DC 1A). Waterproof measures should be used during the storage, transportation and running of the equipment. Huawei Technologies Proprietary...

  • Page 105: Appendix

    PVC0 VPI =0 VCI=35 PVC1 VPI =8 VCI=35 PVC2 VPI= 0 VCI= 100 RFC 2684 Bridged PVC3 VPI =0 VCI=32 Mode PVC4 VPI =8 VCI=81 PVC5 VPI= 8 VCI=32 PVC6 VPI= 14 VCI=24 DHCP Mode Disable Enable Huawei Technologies Proprietary...

  • Page 106: Fcc

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment complies with Part 68 of the Federal Communications Commission (FCC) rules and regulations published Huawei Technologies Proprietary...
  • Page 107 REN without a decimal point (e.g., 03 is a RN of 0.3). If the terminal equipment (ADSL device) causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. However, Huawei Technologies Proprietary...
  • Page 108 If this happens, the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service. If trouble is experienced with the (ADSL device), please contact Huawei Technologies Co., Ltd. XXXXXX(phone number) for repair or warranty information.

  • Page 109: Abbreviations

    Internet Service Provider Local Area Network Media Access Module Media Access Control Management Information Base Network Interface Card Network Management Station Point to Point Protocol PPPoA PPP over ATM PPPoE PPP over Ethernet Permanent Virtual Connection Random Access Memory Huawei Technologies Proprietary...
  • Page 110 Abbreviation Description Routing Information Protocol SNMP Simple Network Management Protocol Transfer Control Protocol TFTP Trivial File Transfer Protocol User Datagram Protocol Virtual Channel Identifier Virtual Path Identifier Wide Area Network Huawei Technologies Proprietary...
  • Page 111 Huawei Technologies Co., Ltd. Administration Building, Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, P. R. China Postal Code: 518129 Website: http://www.huawei.com...
