- Page 1 (IEC 19-inch & ETSI 21-inch Cabinet) 1 U Quick Installation Guide This document applies to the installation of the ATN 910C-K/M/G, ATN 910D-A, NetEngine 8000 M1A/M1C, and OptiX PTN 916-F. Issue：01...
-
Page 2: Device Overview
Device Overview DC chassis AC chassis NOTE DC and AC power modules can be installed in any of the power module slots on the ATN 910C-K/M and ATN 910D-A. Packing list Insulation tape Serial cable Cable management frame Corrugated pipe... - Page 3 NetEngine 8000 M1A: 3.9 kg NetEngine 8000 M1A: 4.5 kg Weight without NetEngine 8000 M1C：3.8 kg NetEngine 8000 M1C：3.9 kg packaging (base ATN 910C-K: 4.0 kg ATN 910C-K: 4.1 kg configuration) ATN 910C-M: 3.8 kg ATN 910C-M: 3.9 kg [kg(lb)] ATN 910C-G: 3.9 kg...
-
Page 4: Safety Guidelines
Follow all the safety precautions and instructions provided by Huawei. The safety precautions outlined in this document are only requirements of Huawei and do not cover general safety regulations. Huawei is not liable for any consequence that results from violation of regulation spertaining to safe operations or safety codes pertaining to design, production, and equipment use. -
Page 5: Site Requirements
Site Requirements The device to be installed must be used indoors. To ensure normal operation and long service life of the device, the following requirements must be met: The device needs to be installed in a clean, dry, well ventilated, and temperature-controllable standard equipment room.In addition, the equipment room must be free from leaking or dripping water, heavy dew, and condensing. -
Page 6: Cabinet Requirements
120 mm (4.72 in.). The device must be installed in an IEC 19-inch cabinet or an ETSI 21-inch cabinet. Huawei A63E cabinet is recommended. If customers choose to purchase cabinets by themselves, the cabinets must meet the following requirements: 1. -
Page 7: Installing A Device
Installing a Device N OT E Certain steps support two installation modes. Select a proper PGND cable installation mode according to cabling requirements. The PGND cable can be connected to either the front or side face of the device. Connecting the cable to the side face is preferred. Figures in the document are for reference only, and the actual device appearance may vary depending on the exact device model. - Page 8 Installing a Device Connect the PGND cable to the front or side face of the device. Connecting the cable to the side face is preferred.
- Page 9 Installing a Device Install the device into the cabinet. CLK /TO D ATN 910 D-A 21 22 100 GE/ 50G ETH /OA M ALM /AL MO STA T BRE AKO UT GE( 8~2 3) CLK /TES T 25G E/10 GE/ 10G E/FE /(0~...
- Page 10 Installing a Device 5.2 Installing a Device in an ETSI 21-Inch Cabinet with Front Columns Install floating nuts onto the cabinet. Floating nut Installation hole Install the conversion mounting ears on both sides of the chassis.
- Page 11 Installing a Device Connect the PGND cable to the front or side face of the device. Connecting the cable to the side face is preferred. CLK /TO D ATN 910 D-A 21 22 100 GE/ 50G ETH /OA M ALM /AL MO STA T BRE AKO UT /GE (8~ 23)
-
Page 12: Connecting Cables
Installing a Device Install the device into the cabinet. CLK /TO D ATN 910 D-A 21 22 100 GE/ 50G ETH /OA M ALM /ALM STAT BRE AKO UT CLK /TES T GE( 8~2 3) 25G E/10 GE/ 10G E/FE /(0~ Connecting Cables Common Cables AC power cable... - Page 13 Connecting Cables Routing Planning N OT E To ensure that power cables are connected in order, you are advised to plan power cable routing. It is recommended that power cables and ground cables be routed on the left side of thecabinet.It is recommended that cables, such as optical fibers and Ethernet cables, be on the right side of the cabinet.
- Page 14 Connecting Cables Installing DC Power Cables Check the fuse capacity of the external power supply. Device Model Recommended Fuse Capacity Maximum Cable Size NetEngine 8000 ≥4 A M1A/M1C For hierarchical power supplying protection, the current of the circuit OptiX PTN 916-F breaker at the user side should be no less than 4 A.
- Page 15 For hierarchical power supplying protection, the current OptiX PTN 916-F of the circuit breaker at the user side should be no less than 2 A. ATN 910C-K/M ≥4 A For hierarchical power supplying protection, the current ATN 910D-A of the circuit breaker at the user side should be no less than 4 A.
- Page 16 Connecting Cables Installing Optical Fibers WARNING When performing operations such as installing or maintaining optical fibers, do not move your eyes close to or look into the optical fiber outlet without eye protection. CAUTION Before routing internal optical fibers, install fixed optical attenuators at the corresponding optical ports on devices according to the fixed optical attenuator installation table.
- Page 17 Connecting Cables Installing Optical Fibers Installing an E1 Cable N OTE This step is required only for the ATN 910C-K chassis. It is recommended that E1 cables and Ethernet cables be routed in interleaving mode.
- Page 18 Connecting Cables Installing Ethernet Cables N OTE It is recommended that the ATN 910C-K chassis use Ethernet cables crimped onsite. Bundle the network cables in a rectangle shape. Ensure that the cable ties are evenly spaced and face the same direction.
-
Page 19: Checking The Installation
Checking the Installation Check Before Power-on Check whether fixed optical attenuators have been added in accor- dance with corresponding configuration rules. Check whether the fuse capacity of the external power supply meets requirements. Check whether the external power supply voltage is normal. CAUTION If the power supply voltage does not meet requirements, do not power on the device. -
Page 20: Trademarks And Permissions
