Error Display
B2M1
Blue
SAct
B2M2
Ambr
NoSn
B2M2
Ambr
SAct
BRD1
NO
COMM
BRD2
NO
COMM
LAMP
STRK
FAIL
PAN
ENCR
FAIL
02.9 671.00 01 E
T
ROUBLESHOOTING AND
Table A-1: Troubleshooting Guide (Continued)
Description
Aux Board 2, Motor 1,
Blue,
Sensor Always Active
Aux Board 2, Motor 2,
Amber,
Sensor Not Found
Aux Board 2, Motor 2,
Amber,
Sensor Always Active
Aux Board 1
Communication Failure
Aux Board 2
Communication Failure
Lamp Strike Failure
Pan Encoder Failure
17-Sep-02
M : T
AINTENANCE ROUBLESHOOTING
Possible Cause and Remedy
Blue power not connected and Blue
aligned with sensor
- Connect Blue power at motor
Amber power not connected, motor
not moving
- Connect Amber power at motor
Amber sensor not connected
- Connect Amber sensor
Amber movement restricted or
impeded
- Remove obstruction
Amber sensor is faulty
- Replace color sensor assembly
Aux Board 2 is faulty
Replace aux board
Amber power not connected, and
amber aligned with sensor
- Connect Amber power at motors
Aux input connector (J5) not
connected to either aux board
- Connect aux input connector (J5)
to either aux board
Jumper/bridge connector (J1)
between aux boards not connected
- Install jumper/bridge connector
(J1) between aux boards
Aux input connector (J5) not
connected to either aux board
- Connect aux input connector (J5)
to either aux board
Jumper/bridge connector (J1)
between aux boards not connected
- Install jumper/bridge connector
(J1) between aux boards
Lamp failed to strike after repeated
attempts
- Replace lamp
Main board pan/tilt connector (J9)
disconnected
- Connect main board pan/tilt
connector (J9)
Pan motor disconnected
- Connect pan motor power
