Page 1: Installation Manual
Value Zentec Hybrid Air Capsulate Value Iron Filter - Sulphur Filter Installation Manual Barrie, Ontario, Canada L4N 8W8 www.excaliburwater.com... -
Page 2: Installation Procedures
EXCALIBUR VALUE IRON FILTER - SULPHUR FILTER INSTALLATION MANUAL INSTALLATION PROCEDURES: The Value Iron Filter - Sulphur Filter control valve, fittings and chemical free bypass are designed to accommodate minor plumbing misalignments. Do not use Vaseline, oils, hydrocarbon lubricants or spray silicone on the Value Iron Filter - Sulphur Filter. - Page 3 All plumbing should be done in accordance with local plumbing codes. The pipe size for Value Iron Filter - Sulphur Filter drain line should be a minimum of ½ inch. When the backwash flow rates for the Value Iron Filter - Sulphur Filter in excess of 7 GPM or length in excess of 20 feet this now requires a ¾...
-
Page 4: Bypass Valve
Do not use a pipe wrench to tighten Value Iron Filter - Sulphur Filter nuts on installation fittings. Hand tighten only. Value Iron Filter - Sulphur Filter split ring retainer holds the nut on and allows load to be spread over the entire nut surface area reducing the chance for leakage with the Value Iron Filter - Sulphur Filter. - Page 5 Programming Set Up Iron Filter - Sulphur Filter Filters On the Value Iron Filter - Sulphur Filter press next and buttons simultaneously for 3 seconds and release to take go to the Value Iron Filter - Sulphur Filter regeneration and cycle times set up screens. Step 1: The first Value Iron Filter - Sulphur Filter set up stage will have a arrow pointing to the SET on the top left and the display on the digital...
- Page 6 This is a fill cycle which is not required on the Value Iron Filter - Sulphur Filter and should be set to “OFF”. Press the Value Iron Filter - Sulphur Filter next button to go to exit and return to time. Excalibur Water Systems Iron Filter - Sulphur Filter Programming Procedures: General Operation:...
- Page 7 Filter - Sulphur Filter regeneration is to occur today, an arrow will point to regeneration on the Value Iron Filter - Sulphur Filter. For immediate regeneration simultaneously press and hold the REGEN button for 3 seconds on the Value Iron Filter - Sulphur Filter. When the Value Iron Filter - Sulphur Filter is in regeneration, step through the different regeneration cycles by pressing the Regen button on the Value Iron Filter - Sulphur Filter until complete and back...
-
Page 8: Troubleshooting Guide
EXCALIBUR WATER SYSTEMS Value Iron Filter - Sulphur Filter Troubleshooting Guide Problem Possible Cause Solution a. Transformer unplugged a. Connect power 1. Timer does not display b. No electric power at outlet b. Repair outlet or use working outlet time of day c. - Page 9 6. Control valve does not a. Transformer unplugged a. Connect transformer regenerate b. No electric power at outlet b. Repair outlet or use working outlet automatically when c. Broken drive gear or drive cap c. Replace drive gear or drive cap assembly assembly UP and DOWN buttons...
-
Page 10: Year Warranty
Warranty ~ Working Procedures If during the suitable warranty period, a part is defective, then Excalibur Water Systems will repair or replace that part at no charge to the original owner, with the exception of charges for nominal shipping, service and/or installation.
