E-Z-GO Engine Shop Rebuild Manual page 77

Item
76 GASKET, HD-CARBURETOR
77 INSULATOR
78 BRACKET, CHOKE CABLE
79 BOLT, STUD
80 CARBURETOR-AS03
81 CARBURETOR-AS07 SPEC (NOT SHOWN)
82 PLUG-PILOT JET
83 JET-PILOT #44
84 JET-PILOT #52 (NOT SHOWN)
85 JET-MAIN #106
86 JET-MAIN #104
87 JET-MAIN #102
88 JET-MAIN #100 (NOT SHOWN)
89 VALVE-FLOAT
90 FLOAT
91 PIN, FLOAT
92 GASKET, BOWEL
93 ASSY, FLOAT CHAMBER
94 GASKET, CHAMBER
95 PLUG, CHAMBER
96 BUSHING, THROTTLE ATTACH.
ILLUSTRATED PARTS BREAKDOWN
CARBURETOR/CABLE BRACKETS
Description
Kawasaki Engine Shop Rebuild Manual
E-Z-GO Part Number
603580
603581
603583
603584
607954
607955
603585
608021
607957
607956
607683
607684
607685
607686
607687
607688
607689
607690
607691
607692
608023
Quantity
GOLF UTILITY
3 3
1 1
1 1
2 2
1 -
- 1
1 1
1 -
- 1
- 1
1 -
- -
- -
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
Page F-15
