E-Z-GO Engine Shop Rebuild Manual page 71

Item
43 PLATE, OIL RELIEF
44 ASSY OIL PUMP
45 COVER-PUMP
46 ROTOR-PUMP, OUTER
47 PIPE
48 FILTER, OIL-FJ400D
49 DIPSTICK OIL, LOW-SUSP
50 DIPSTICK OIL, HIGH-SUSP (NOT SHOWN)
51 RING SNAP
52 PLUG
53 BALL
54 SPRING, OIL RELIEF
55 BOLT
56 BOLT, FLANGED
57 O RING, 16MM
58 SWITCH, OIL PRESSURE (NOT SHOWN)
* Utility vehicles may be equipped with either high or low suspension. Please be sure to select the correct dipstick P/N for
your model.
ILLUSTRATED PARTS BREAKDOWN
LUBRICATION
Description
Kawasaki Engine Shop Rebuild Manual
E-Z-GO Part Number
603550
603552
603553
603554
603555
607454
606390
606391
603556
603557
603558
603559
603560
603561
603562
608398
Quantity
GOLF UTILITY
1 1
1 1
1 1
1 1
1 1
1 1
1 1*
- 1*
1 1
3 3
1 1
1 1
2 2
1 1
3 3
- 1
Page F-9
