ENGINE BOTTOM END DISASSEMBLY

SPECIFICATIONS

Camshaft and Tappets
Cam Lobe Height:
Inlet
Exhaust
Camshaft Journal Diameter:
Crankcase Side
Crankcase Cover Side
Camshaft Bearing Inside Diameter:
Crankcase Side
Crankcase Cover Side
Crankshaft and Connecting Rods
Connecting Rod Bend
Connecting Rod Twist
Connecting Rod Big End Width
Crankpin Width
Connecting Rod Big End Inside Diameter
Crankpin Outside Diameter
Crankshaft Runout
Crankshaft Main Journal Diameter:
Crankcase Side
Crankshaft Main Bearing Inside Diameter:
Crankcase Side
Page B-4
Item
Kawasaki Engine Shop Rebuild Manual
Standard
29.95 ~ 30.05 mm
(1.179 ~ 1.183 in.)
29.95 ~ 30.05 mm
(1.179 ~ 1.183 in.)
19.967 ~ 19.980 mm
(0.78610 ~ 0.78661 in.)
49.959 ~ 49.975 mm
(1.9669 ~ 1.9675 in.)
20.000 ~ 20.013 mm
(0.78740 ~ 0.78791 in.)
50.000 ~ 50.025 mm
(1.9685 ~ 1.9695 in.)
– – –
– – –
– – –
– – –
27.4 ~ 27.7 mm
(1.08 ~ 1.09 in.)
28.0 ~ 28.2 mm
(1.10 ~ 1.11 in.)
43.004 ~ 43.015 mm
(1.6931 ~ 1.6935 in.)
42.963 ~ 42.976 mm
(1.6915 ~ 1.6920 in.)
TIR 0.02 mm
(0.0008 in.) or less
34.955 ~ 34.980 mm
(1.3762 ~ 1.3772 in.)
35.002 ~ 35.015 mm
(1.3780 ~ 1.3785 in.)
Service Limit
29.86 mm
(1.176 in.)
29.86 mm
(1.176 in.)
19.94 mm
(0.7850 in.)
49.93 mm
(1.966 in.)
20.07 mm
(0.7902 in.)
50.09 mm
(1.972 in.)
0.15/100 mm
(0.006/3.94 in.)
0.15/100 mm
(0.006/3.94 in.)
27.0 mm
(1.06 in.)
28.4 mm
(1.12 in.)
43.04 mm
(1.694 in.)
42.95 mm
(1.691 in.)
TIR 0.05 mm
(0.002 in.)
34.93 mm
(1.375 in.)
35.05 mm
(1.380 in.)
