MANUAL WHEELCHAIR
Owner's Operation and
Maintenance Manual
DEALER
This manual must be given to the user of the
wheelchair.
USER
Before using this wheelchair, read this entire manual
and save for future reference.
For more information regarding PDG products,
parts & service, please visit www.pdgmobility.com
Class 1 Medical
Advertisement
Table of Contents
Related Manuals for PDG Mobility Evelation
Summary of Contents for PDG Mobility Evelation
- Page 1 MANUAL WHEELCHAIR Owner’s Operation and Maintenance Manual DEALER This manual must be given to the user of the wheelchair. USER Before using this wheelchair, read this entire manual and save for future reference. For more information regarding PDG products, parts & service, please visit www.pdgmobility.com Class 1 Medical...
-
Page 2: Table Of Contents
page WARNING Do not operate this equipment without first reading and understanding this manual. If you are unable to understand the warnings and instructions, contact a health care professional such as a doctor or therapist who is familiar with this type of product before attempting to use this equipment. Otherwise, injury or damage may result. -
Page 3: Special Notes
page SPECIAL NOTES WARNING/CAUTION — notices as used in this manual apply to hazards or unsafe practices which could result in personal injury or property damage. NOTE — THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. INDICATIONs FOR UsE —... - Page 4 page 6 DO NOT attempt to ride over curbs or obstacles. Doing so may cause your wheelchair to turn over and cause bodily harm or damage to the wheelchair. 6 DO NOT use unauthorized parts, accessories, or adapters other than those authorized by PDG. 6 DO NOT attempt to lift wheelchair by any removable (detachable) parts.
-
Page 5: Weight Training
page 4 Replacement of a pneumatic tire or tube MUST be performed by an authorized PDG Dealer or Qualified Technician. Weight Training 6 PDG DOES NOT recommend the use of its wheelchairs as a weight training apparatus. PDG wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, PDG shall NOT be liable for bodily injury and the warranty will be voided immediately. - Page 6 page Be aware of any removable (detachable) parts. These must NEVER be used for hand-held or lifting supports, as they may be inadvertently released, resulting in possible injury to the user and/or assistant(s). When learning a new assistance technique, have an experienced assistant help before attempting it alone.
-
Page 7: Stairways
page STAIRWAYS WARNING — Do not attempt to lift a wheelchair by lifting on any removable (detachable) parts. Lifting by means of any removable(detachable) parts of a wheelchair may result in injury to the user or damage to the wheelchair. Extreme caution is advised when it is necessary to move an occupied wheelchair up or down the stairs. -
Page 8: Percentage Of Weight Distribution
page PERCENTAGE OF WEIGHT DISTRIBUTION WARNING — DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the fl oor by reaching down between your knees. Many activities require the wheelchair owner to reach, bend and transfer in and out of the wheelchair. -
Page 9: Dressing Or Changing Clothes
page DRESSING OR CHANGING CLOTHES WARNING — Your weight may shift if you dress or change clothes while seated in this chair. To reduce the risk of a fall or tip-over: Rotate the front casters until they are as far forward as possible. This makes the chair more stable. Lock anti-tip tubes in place. - Page 10 page NEVER use positioning or seat belts as a motor vehicle restraint. These types of belts are NOT intended to protect the wheelchair rider from the forces involved in a vehicle accident, and they may, in fact, cause you to be injured. PDG recommends wheelchair users ALWAYS transfer to appropriate motor vehicle seating when traveling in a motor vehicle.
-
Page 11: Pneumatic Tires
page Avoid putting weight on the footrests, as the chair may tip forward. Pneumatic Tires WARNING — Proper infl ation extends the life of your tires and makes your chair easier to use. Do not use this chair if any of the tires is under- or overinfl ated. Check weekly for proper infl ation level, as listed on the tire sidewall. -
Page 12: Standard Features
page STANDARD FEATURES Wheel Lock Wheel Lock Back Upholstery Back Upholstery Foot Plate Quick-Release Axle Front Caster Lower Frame Tilt Activator (trigger) Back Rest Rear Wheel 10 Seat Sling UNPACKING Check for any obvious damage to the carton or its contents. If damage is evident, notify your Dealer/ Carrier immediately. -
Page 13: Out Of The Box Assembly Instructions
page OUT OF THE BOX ASSEMBLY INSTRUCTIONS INSPECTION Examine exterior of the PDG Elevation for nicks, dents, scratches or other damages. Inspect all components. If damage is evident, notify your Dealer/Carrier immediately. STORAGE Store the repackaged PDG Elevation in a dry area. DO NOT place other objects on top of the repackaged wheelchair. - Page 14 page ITEM INITIALLY INSPECT/ INSPECT/ INSPECT/ ADjUST ADjUST ADjUST/ WEEKLY MONTHLY every 6 months GENERAL Wheelchair rolls straight (no excessive drag or pull to one side). Ensure all hardware is tight. WHEEL LOCKS (Procedure 6) Do not interfere with tires when rolling. Pivot points free of ware and looseness.
-
Page 15: Tools Required
page TROUBLESHOOTING Problems Solution Chair veers right Chair veers left Contact dealer for servicing. Sluggish turn or performance If pneumatic, check tires for correct/equal Casters flutter pressure. 3 of 4 wheels contating ground surface Sluggish turn or performance Casters flutter Contact dealer for servicing. -
Page 16: Suggested Maintenance Procedures
page Cleaning Periodic cleaning of all surfaces will help keep your wheelchair looking good and operating properly. All surfaces can be cleaned using warm water and a mild soap solution. Do not use abrasive cleaners on any surfaces. SUGGESTED MAINTENANCE PROCEDURES Before using your PDG Elevation, make sure all nuts and bolts are tight. -
Page 17: Seat Height
page Rear Wheel Axle Nut Adjustment The quick-release axle attaches the rear wheel to the axle receiver. When the axle is fully inserted into both the wheel and axle receiver the detent balls will lock the wheel assembly in place. By pushing the button on the quick-release axle the detent balls will be disengaged and wheel can be removed. -
Page 18: Camber Angle
page Center of Gravity/Wheel Position The rear wheel axle location is preset at the factory. Adjustments are possible by moving the axles and camber tube assembly forward or backwards. To adjust the position,. Place the camber tube at the desired position, ensure that the camber tube assembly is equally place distance on both sides by measuring from the camber tube to the rear of the wheelchair, and then fi rmly tighten the bolts. -
Page 19: Back Upholstery
page Calf Strap The calf strap is positioned behind the occupant’s lower calves to prevent the legs and/or feet slipping backwards. Adjust the Velcro strap to obtain the desired length of strap to correctly position the feet on the footrest. Warning —... - Page 20 page To adjust footrest height Using a 4mm allen wrench loosen the Socket head cap screws on the clamp. Position the footrest to the desired height and ensure it is level to the ground. Re-tighten the bolts. Warning — never attempt to adjust the footrest with the wheelchair occupied.
- Page 21 page To replace gas springs Position the chair on a solid level surface and secure the chair using the brakes. Be sure to have the gas spring in the fully extended position. Remove both socket head shoulder bolts from the frame strut mounts on the upper and lower frames using a 3mm allen wrench.
- Page 22 page Squeeze the lever on the right side and with your left hand push up on the main frame or rear wheel to raise the seat. Release the lever at the desired height. To lower seat Squeeze the lever again and the seat will slowly lower. Grab the rear wheel to assist bringing the seat down.
- Page 23 page CONTACTING YOUR SUPPLIER TO OBTAIN SERvICE PDG has trained customer service representatives in many locations. To find your nearest Customer Service Center, visit our web site at www.pdgmobility.com and click on CONTACTS. If you are uncertain about which CONTACT is most appropriate for your needs, contact PDG directly using telephone, fax, or e-mail contact information.
- Page 24 page ELEvATION WHEELCHAIR TEST CONFIGURATION Seat Width 650 mm (25.6 in) Seat Depth 407 mm (16 in) Seat Back Height 240 mm (9.45 in) Wheelchair Weight 12 kg (26.5 lbs) Seat sling Standard Sling Seat w/tension straps Back Upholstery Standard back upholstery Wheels 24”...
- Page 25 page LIMITED WARRANTY PLEASE NOTE — THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAW APPLICABLE TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975. This warranty is extended only to the original purchaser/user of our products. This warranty gives you specific legal rights and you may also have other legal rights, which vary from state to state.
- Page 26 page...
- Page 27 page...
- Page 28 PDG PRODUCT DESIGN GROUP INC. Ph: (604) 323-9220 Fax: (604) 323-9097 info@pdgmobility.com www.pdgmobility.com © PDG Product Design Group Inc. October 2013.
